3.3.8 Cable Search

Connect a BNC cable to the "Video Out" port or connect a network cable to the UTP/SCAN port. Click the
open the Cable Search app. To switch between the different audio tones, select a number on the screen.
Use the blue Combination cable identifier and network cable tester's copper pointer to touch all the cables in the bundle
you are searching at the other end. The cable that gives off the loudest tone is the cable connected to the tester. Press the
+ or – buttons on your blue cable identifier to adjust the volume.
Note：Install two AAA batteries in your blue Cable Identifier.
Note：While the cable tracer is receiving the audio signal from the tester, it may be induced into adjacent or
crossing cables; however, the cable that makes the loudest noise is the one that's connected to the
meter.

3.3.9 Port flashing

Connect a network cable to the meter's "LAN" port, click the
IP BUDDY+ sends a unique signal to make the connected LAN port of the switch flash.
icon to open the Port Flashing app. Click "Start". The
Page.24.
