3.3.1 PTZ (Activates analog video viewing and PTZ camera testing)
For Analog camera testing and PTZ control, click this icon:
Click the top menu bar icon to enter the video waveform testing function (PEAK level, SYNC level, and COLOR
BURST measurements)
Additional functions are on the right side of the PTZ app Toolbar. These additional functions include "Photo", "Snapshot",
"Record", "Playback", "PTZ" and "Set"
Tap the screen twice in rapid succession to zoom in on the video image.
Click or press the key to exit this application.
(1) PTZ controller parameter setting
Select and click on "PTZ" to enter the PTZ settings page：
Settings available are:
A. Protocol
Use the up and down arrow keys or tap the word "Protocols" to move the yellow cursor to "protocols" and activate this
setting. This allows for setting a matching communication protocol from the IP BUDDY+ to the PTZ camera. (Most
SecurityTronix PTZ cameras use PELCO-D)
Page.11.
