Data Monitor; Media Player - Security Tronix ST-IP-TEST User Manual

3.3.10 Data monitor

Click on the icon to use the Data monitor.
Click "Setting" to choose the baud rate of RS485/RS232; this must match the DVR, Control keyboard, or other device
under testing. The device sends its code to the tester. If the code can be read, the code will show on the upper right part of
the screen.
To clear data from the code field, press the key.

3.3.11 Media Player

Click the icon to bring up the Media Player.
The Media player can browse video and image files. It supports the video formats of MP4, H.264, MPEG4, and MKV. The IP
BUDDY+'s recorded files can play directly via the Media player. The Media player will automatically display the video files
from the SD card. Click on the desired file to play. Click RETURN to exit.
To rename or delete an existing file, press the file name for a few seconds until the screen below appears. You can then
rename or delete the file by pressing the desired option.
Page.25.
