Typical Installation

1.
Ensure all external system power supplies are off.
2.
Install the SMARC module into the MXM connector. Be sure to follow the manufacturer's direction
for proper heatsink/heatspreader installation and any other cooling instructions from the manufacturer.
3.
Install the necessary cables for the application. For the relevant cables, see the Cables and Accessories
section of this manual.
4.
Connect the power cable to the power supply
5.
Switch on the power supply. DO NOT power up your SMARC system by plugging in live power.

Cables and Accessories

Drawing No.
CTIC-00570
CTIC-00592
CTIC-00593
CTIC-00594
CTIC-00477
CSI Camera accessories TBD
Document: CTIM-00154
Revision: 0.00
Part No.
MSG068
5V Power Kit
CBG248
10-pin PicoBlade IO cable w/ flying leads
CBG249
6-pin PicoBlade IO cable w/ flying leads
CBG250
3-pin PicoBlade IO cable w/ flying leads
CBG136
RTC Battery Cable
Page 10 of 10
Connect Tech Inc. 800-426-8979 | 519-836-1291
www.connecttech.com
Description
SMARC 2.0 Carrier
Users Guide
QTY
1
2
1
1
1
Date: 2017-03-15
