Connect Tech SMARC 2.0 Carrier User Manual page 9

Designator
S1 Boot Select Switch
P3 HDMI0
P4 HDMI1
P5 GPIO Header
P6 I2C Header
P7 Mini PCIe Slot 0
P8 Mini PCIe/mSATA Slot 1
P9 +5V Input Power
P10 RTC Header
P11 System Control Header
P12 Serial Header
P13 USB2.0 double stack, ports 0-1
P14 USB3.0 double stack, ports 2-3
P15A GBE0
P15B GBE1
