Page 1 Model 933S UV Analyzer Operator’s Guide With Essential Health and Safety Requirements Canada A DIVISION OF AMETEK PROCESS & ANALYTICAL INSTRUMENTS Western Research PN 903-8798, Rev. A...
Page 2: Offices
Printed in Canada This manual is a guide for the use of the Model 933S UV Analyzer. Data herein has been verified and validated and is believed adequate for the intended use of this instrument. If the instrument or procedures are used for purposes over and above the capabilities specified herein, confirmation of their validity and suitability should be obtained;...
Page 3: Table Of Contents
Contents Offices ..........................ii Safety Notes ........................viii Electrical Safety ........................viii Grounding ........................viii Personnel and Equipment Safety Information ............. ix Warnings ........................ix Cautions ........................x Warning Labels ........................xi Environmental Information .................... xi UV Source Lamps Disposal ..................... xi Electromagnetic Compatibility (EMC) ................xii Special Warnings and Information ................
Page 4 Electrical Connections ....................3-12 Input/Output Signal Connections ............... 3-12 Digital Communication ..................3-13 Hardware Configuration (Modbus Serial Communication) ......3-13 Multiple-Analyzer (Multi-Drop) System Configuration........3-17 AC Power Connection and Fusing ............... 3-19 European Installation ..................3-20 North American Installation ................3-20 iv | Model 933S UV Analyzer...
Page 5 S93XS System 200 Configurator Software Installation ..........3-22 Minimum PC Requirements for Configurator Software ........3-22 Installing the S93XS System 200 Configurator Software ........3-23 Removing the Configurator Software ..............3-25 Start-Up and Verification ..................... 3-26 Powering Up the Analyzer ..................3-26 Start-Up Diagnostic Checklist ................3-36 Sample System Leak Check ..................
Page 6 Upper/Lower Electronics Enclosure Flamepaths (Joining Surfaces) ....6-59 Troubleshooting and Diagnostics ................6-60 Host Controller Board Alarm Conditions and Corrective Action ....6-62 Microcontroller Board Alarm Conditions and Corrective Action ....6-71 Analyzer Reset ......................6-80 vi | Model 933S UV Analyzer...
Page 7 CHAPTER 7 SERVICE AND PARTS ..................7-1 Technical Support ......................7-1 Returning Equipment ..................... 7-2 AMETEK SERVICE and AFTERMARKET SALES SUPPORT ......7-3 Recommended Preventive Maintenance Spare Parts ..........7-4 Optical Bench/Sample System Spare Parts ............7-4 Spare Analyzer Fuses ....................7-6 Replacement Boards....................
Page 8: Safety Notes
Grounding Instrument grounding is mandatory. Performance specifications and safety protection are void if instrument is operated from an improperly grounded power source. Verify ground continuity of all equipment before applying power. CAUTION viii | Model 933S UV Analyzer...
Page 9: Personnel And Equipment Safety Information
Personnel and Equipment Safety Information This section describes important safety information to avoid personal injury and damage to the equipment while installing, operating, maintaining, or servicing the equipment. All safety regu- lations, standards, and procedures at the analyzer location must be followed. All personnel involved with the installation, start-up, operation, maintenance, service, or trou- bleshooting of the analyzer must review and follow these Warnings and Cautions.
Page 10: Cautions
• Systems without Filterblock Assembly: 20 700 KPAG (3000 PSIG). If the analyzer is equipped with the Environmental Purge option, clean air or nitrogen can be supplied to the inlet flame arrester at a pressure of 7–70 KPAG (1–10 PSIG). CAUTION x | Model 933S UV Analyzer...
Page 11: Warning Labels
UV Source Lamps Disposal AMETEK recommends that all UV lamps – whether they are new, used, or damaged in any way – need to be disposed of in an environmentally safe manner. Most UV lamps do not contain restricted substances listed under the European RoHS 2 direc- tive.
Page 12: Electromagnetic Compatibility (Emc)
CAUTION The various configurations of the Model 933S Analyzer should not produce, or fall victim to, electromagnetic disturbances as specified in the European Union’s EMC Directive. Strict compli- ance to the EMC Directive requires that certain installation techniques and wiring practices are used to prevent or minimize erratic behavior of the Analyzer or its electronic neighbors.
Page 13: Special Warnings And Information
Special Warnings and Information Equipment Used in Class I, Division 2 Hazardous Locations Refer to Chapter 2 – Specifications for details about the suitability of this equipment in hazard- ous locations. EXPLOSION HAZARD – DO NOT DISCONNECT EQUIPMENT UNLESS POWER HAS BEEN SWITCHED OFF OR THE AREA IS KNOWN TO BE NON-HAZARDOUS.
Page 14: Eu Declaration Of Conformity
EU Declaration of Conformity EU Declaration of Conformity Manufacturer’s Name: AMETEK Canada A Division of AMETEK Process & Analytical Instruments (ISO 9001:2008 Registered) Manufacturer’s Address: 2876 Sunridge Way N.E. Calgary, Alberta, Canada T1Y 7H9 Phone: (403) 235-8400 / Fax: (403) 248-3550...
Page 15 KEMA 02ATEX2247 X Notified Body: DEKRA Certification B.V. 0344 Meander 1051, 6825 MJ Arnhem The Netherlands ____________________________ Randy Meads Quality Assurance Manager Calgary, Alberta, Canada June 28, 2017 Canada A DIVISION OF AMETEK PROCESS & ANALYTICAL INSTRUMENTS Western Research Page 2 of 2 Contents | xv...
Page 16: Warranty And Claims
Process photometric analyzers, process moisture analyzers, and sample systems are warranted to perform the in- tended measurement, only in the event that the customer has supplied, and AMETEK has accepted, valid sample stream composition data, process conditions, and electrical area classification prior to order acknowledgment. The photometric light sources are warranted for ninety (90) days from date of shipment.
Page 17: Chapter 1 Overview
This system separates and eliminates interfer- ing species to ensure an accurate analysis of the gas. The microprocessor- based Model 933S Analyzer minimizes the complexity of these tasks and simplifies operation of the analyzer system. Overview | 1-1...
Page 18: About The Analyzer
About the Analyzer The Model 933S Analyzer is comprised of (see Figure 1-1): • Two ultraviolet light sources (source lamps) • Chopper Wheel (Filter Wheel) containing up to six interference filters • Beam Splitter • Front-surfaced mirrors • Gas Measuring Cell •...
Page 19 Figure 1-2. Sample flow diagram (Plumbing Schematic).  Figure 1-2 illustrates a Sample Flow Diagram (plumbing schematic) for a typical European style analyzer. See Appendix A for a North NOTE American style drawing, or see the Final “As-Built” drawings, if ordered, in the analyzer Documentation Package.
Page 20: About The Analyzer Sample System
About the Analyzer Sample System The sample system is mounted to the Model 933S Analyzer backpan. The purpose of the system is to maintain constant pressure and temperature, and to condition the sample to obtain correct analysis. The sample system consists of (see Figures 1-2 and 1-3):...
Page 21 PROCESS INSTRUMENTS CAUTION: RISK OF ELECTRIC SHOCK ATTENTION: CONSULT USER MANUAL 0344 II 2 G PROCESS INSTRUMENTS Western Research Model 933 Analyzer Certificate No: KEMA 02ATEX2247, EEx d IIB T3 (T amb. 0°C...50°C) Year. _______ Serial No. __________________ Caution Do not open when an explosive gas atmosphere is present. Power Dissipation Input <210W...
Page 22: Working In This Manual
These reminders indicate related information about the topic, certain actions that See also “Digital are necessary before continuing with the current procedure, or information that Communication” in Chapter 3. is recommended by AMETEK. See example at left.  System 200 Configurator Software Navigation icon: ...
Page 23: Supplemental Information - Where Can I Find It
Signed Final QC (Quality Control) Document, which includes AMETEK Testing Quality Control information for the analyzer. Final As-Built drawings (if ordered) which are customer-specific drawings for the analyzer system. Note that these drawings are not typically included with standard-built analyzers.
Page 24 This page intentionally left blank. 1-8 | Model 933S UV Analyzer...
Page 25: Chapter 2 Specifications
SPECIFICATIONS Methodology Non-dispersive ultraviolet analysis for measurement of hydrogen sulfide S), carbonyl sulfide (COS), and methyl mercaptan (MeSH) in sales quality (pipeline quality) natural gas. Frontal elution chromatography is used to remove interfering species from the sample gas. Full-Scale Ranges The standard customer range is defined as full-scale ranges that fall with- in the minimum and maximum allowable for a given Measuring Cell.
Page 26: Response Time
Calibration gases in nitrogen or methane. Linearity ± 2.0 % full-scale of Standard Ranges to a minimum of: ± 0.25 PPM COS: ± 1 PPM MeSH: ± 0.75 PPM Stability Noise: 1.0 % of Standard Ranges (excluding cross-talk effects) 2-2 | Model 933S UV Analyzer...
Page 27: Sensitivity
Sensitivity 0.5 % of Standard Ranges Cross-Talk S concentration measurement: < 2 % of the sum of COS and MeSH concentrations.  Cross-talk adjustments should be made by factory-trained service personnel only. NOTE Temperature Drift 2 PPM / (Cell length) / °C COS: 12 PPM / (Cell length) / °C MeSH:...
Page 28: Customer Connections
, 50/60 Hz, 1.5 A Maximum CSA: 104~132 V , 50/60 Hz, 3 A Maximum 208~264 V , 50/60 Hz, 2 A Maximum Sample Gas Flow Rate Maximum 20 NLM (42.4 SCFH) for the High Pressure/Low Range Kit. 2-4 | Model 933S UV Analyzer...
Page 29: Zero Gas
Zero Gas Instrument zero purity Carbon Dioxide, UHP Nitrogen, or UHP Methane. Recommended Auto-Zero interval is once per 24 hours. More frequent Auto-Zeroing can be used to reduce temperature drift in installations with widely varying ambient temperatures. Ambient Limits Temperature From 0 °C to 50 °C (32 °F to 122 °F).
Page 30: Sample Stream Compatibility
Approximately 100 kg (220.5 lb), entire system and backpan only (may vary, depending on system). Options • Other measuring ranges • COS and methyl mercaptan measurement • Pressure compensation • Up to 4 V/I outputs 2-6 | Model 933S UV Analyzer...
Page 31: Carbon Dioxide Sensor
Carbon Dioxide Sensor Accuracy ± 5.0 % full-scale of standard ranges. Based on a full-scale of 5 % CO in pipeline application, where the sensor is in a temperature-controlled Oven. Cross-Talk No significant cross-talk from water, H S, or hydrocarbons onto the CO measurement.
Page 32: Approvals And Certifications
Approvals and Certifications The Model 933S Analyzer is certified for indoor use only, Installation Cat- egory II (local level transients, less than those found at power distribution level), and Pollution Degree 2 (normally nonconductive environmental pollution occurs with occasional condensation). Complies with all relevant European Directives.
Page 33: Atex And Iecex Certificates And Analyzer Markings
ATEX and IECEx Certificates and Analyzer Markings For installation sites with potentially explosive atmospheres that require ATEX and IECEx certification, AMETEK’s ATEX and IECEx certificates for the Model 933S Analyzer are included in the following pages. Specifications | 2-9...
Page 34 2-10 | Model 933S UV Analyzer...
Page 35 Specifications | 2-11...
Page 36 2016-12-16 2-12 | Model 933S UV Analyzer...
Page 37 Specifications | 2-13...
Page 38 2-14 | Model 933S UV Analyzer...
Page 39 Specifications | 2-15...
Page 40 ATEX- and IECEx-certified Model 933S Analyzers are marked with this label: 0344 II 2 G Western Research Model 933 Analyzer Certificate Nos.: KEMA 02ATEX2247 X, IECEx DEK12.0035X Ex db IIB+H2 T3 Gb (T amb. 0°C...50°C) Year: _______ Serial No.: __________________ Caution Do not open when an explosive gas atmosphere is present.
Page 41: Csa Certificate And Analyzer Marking
CSA Certificate and Analyzer Marking For installation sites that require CSA certification, AMETEK’s CSA certifi- cate for the Model 933S Analyzer is included in the following pages. Certificate of Compliance Certificate: Master Contract: 164369 (048179_0_000) 1031027 Project: 70097231097231 Date Issued:...
Page 42 Additional bilingual markings not covered by the product standard(s) may be required by the Authorities Having Jurisdiction. It is the responsibility of the manufacturer to provide and apply these additional markings, where applicable, in accordance with the requirements of those authorities. DQD 507 Rev. 2016-02-18 Page 2 2-18 | Model 933S UV Analyzer...
Page 43 Certificate: 1031027 Master Contract: 164369 Project: 70097231 Date Issued: 2017-02-24 The products listed are eligible to bear the CSA Mark shown with adjacent indicators 'C' and 'US' for Canada and US (indicating that products have been manufactured to the requirements of both Canadian and U.S. Standards) or with adjacent indicator 'US' for US only or without either indicator for Canada only.
Page 44 2001-04-30 Upgrade of Optical Bench PCB to eliminate potential voltage spikes. Original Certification for Process Analyzer, Model 93X for use in Hazardous 1031027 2000-03-17 Locations.Originally issued as 2500004397 DQD 507 Rev. 2016-02-18 Page 1 2-20 | Model 933S UV Analyzer...
Page 45 CSA-certified Model 933S Analyzers are marked with this label:  PROCESS INSTRUMENTS Western Research Analyzer Model: ___104-132Vac, 3A ___208-264 Vac, 2A, 50/60 Hz, <500W CLASS I, DIVISION 1 GROUPS B, C & D CLASS I ZONE 1 Ex d IIB+H2 T3, AEx d IIB+H2 T3 Tamb.
Page 46 This page intentionally left blank. 2-22 | Model 933S UV Analyzer...
Page 47: Chapter 3 Installation And Start-Up
INSTALLATION and START-UP This chapter describes how to install and start up the Model 933S Ana- lyzer, including: • Safety requirements to consider before working on the analyzer. • Uncrating, inspecting, and storing the analyzer prior to installation. • Installing the mechanical components and making the electrical con- nections.
Page 48: Safety Considerations
Recommended storage conditions include: Temperature: 0 °C to 50 °C (32 °F to 122 °F) Relative Humidity: < 70 % Failure to comply with these storage conditions will void your warranty. 3-2 | Model 933S UV Analyzer...
Page 49: Uncrating And Inspecting The Analyzer
Optical Bench appears to be damaged open the ESD packaging (follow ESD precautions to prevent ESD damage to the electronics), observe the Optical Bench, and contact AMETEK with details of the damage. Reseal the ESD-safe packaging while awaiting instructions from AMETEK.
Page 50: General Installation Information
(breaker) must be connected to and mounted near the analyzer, in an easily accessible area. The switch (breaker) must be clearly labeled (e.g., “AMETEK Model 933S Analyzer Main AC Power Disconnect Switch”). For safety reasons during maintenance, this switch allows the main AC power to be disconnected from the analyzer prior to performing service on the analyzer.
Page 51: Installing The Mechanical Components
Documentation Package. Location and Environment The Model 933S Analyzer is designed for indoor operation (Pollution Degree 2). In all cases, the analyzer system must be installed indoors to ensure it is shielded from harsh environmental elements. The entire ana- lyzer system (and its backpan) can be mounted directly on a wall inside a building, in a specially designed cabinet, or in a custom-built shelter.
Page 52 Figure 3-1. Analyzer backpan dimensions (European). 3-6 | Model 933S UV Analyzer...
Page 53: Installing The Optical Bench Assembly
Installing the Optical Bench Assembly The Optical Bench Assembly – shipped in a separate box – must be in- stalled in the analyzer’s Upper Enclosure after the analyzer has been installed. All electrical connections to the Optical Bench Assembly are made via pre- wired connector plugs.
Page 54 • Optional: If your analyzer has a Cell Heater, connect the Heater Cartridge wire (marked ‘N’) to J200 (Terminal 2) and the Overtemp Switch wire (marked ‘L’) to J200 (Terminal 1). Figure 3-2. Upper Enclosure layout and Cam Pin locations. 3-8 | Model 933S UV Analyzer...
Page 55: Installing The Sample System
WARNING Enclosure for locations of these fuses. Installing the Sample Probe If the Sample Probe is supplied by AMETEK, refer to Sample Probe draw- ings in Appendix A for important installation information. Installing the Sample and Vent Lines The Sample and Vent Lines are supplied by the customer. The tubing (Sample, 1/8”;...
Page 56 MAY NOT BE EXACTLY AS SHOWN Figure 3-3. Backpan component layout (European).  See Appendix A for a North American style drawing (or Final “As- Built” drawings, if ordered, in the analyzer Documentation Package). NOTE 3-10 | Model 933S UV Analyzer...
Page 57: Installing The Zero Gas Line
Installing the Zero Gas Line The Zero gas line is supplied by the customer. The Zero gas connection (1/4” Swagelok fitting) is located on the Solenoid Block (Figure 3-3). The recommended Zero gas is UHP Nitrogen, UHP Methane, or zero purity Carbon Dioxide.
Page 58: Electrical Connections
EMC Directive regarding NOTE techniques and wiring practices to be followed. To maintain EMC compliance in European installations, AMETEK recommends using metallic glands and shielded cable (at least 85 % coverage) for both power and signal cable connections.
Page 59: Digital Communication
D-sub connector), configured as RS-232, is located on the front of the Lower Enclosure (Figure 3-3). The port is principally intended as a tempo- rary connection for configuring and servicing the analyzer while commu- nicating with the analyzer via the AMETEK S93XS System 200 Configura- tor Software. Hazardous Locations...
Page 60 HC BOARD CUSTOMER CONNECTIONS Figure 3-4. Customer Connections wiring schematic (European).  See Appendix A for a North American style drawing (or Final “As- Built” drawings, if ordered, in the analyzer Documentation Package). NOTE 3-14 | Model 933S UV Analyzer...
Page 61 Remote Service Port/Local Service Port Configurations Set these jumpers to To configure the analyzer for: these positions: JP300 = 1-2 Local Service Port RS-232 or Modem JP301 = 1-2 JP302 = 1-2 JP300 = 2-3 Remote Service Port RS-485 JP301 = 2-3 (* See Note.) JP302 = 2-3 *Note: Requires additional configuration, discussed under “Remote...
Page 62 Use a soft, nonabrasive cloth to gently clean the joining areas (flame- path) of the Upper and Lower Enclosures before closing them. CAUTION 3-16 | Model 933S UV Analyzer...
Page 63: Multiple-Analyzer (Multi-Drop) System Configuration
2- or 4-wire line is used, and the transmission line conditions (length of cable, or termination and biasing on the other end of the cable).  Figures 3-5 and 3-6 apply only to Model 933S Analyzers with Host Controller board, Rev. B and newer. NOTE...
Page 64 Figure 3-6. Various RS-485 port terminations and bias options (Host Controller board, P/N 100-1757). 3-18 | Model 933S UV Analyzer...
Page 65: Ac Power Connection And Fusing
AC Power Connection and Fusing Both the North American and European versions of the Model 933S Analyzer require a power-disconnect switch (breaker), rated for at CAUTION least 250 V , 3 A and certified for the hazardous location (to satisfy local electrical codes, the switch must be certified by the local author- ity for the appropriate hazardous location).
Page 66: European Installation
European Installation  To maintain EMC compliance in European installations, AMETEK recommends using metallic glands and shielded cable (at least 85 % NOTE coverage) for both power and signal cable connections. To make the AC power connections in the Ex d Lower Enclosure: •...
Page 67 LOWER ENCLOSURE DETAIL A Figure 3-7. Conduit entries and AC power connection locations, Lower Enclosure (European). Installation and Start-Up | 3-21...
Page 68: S93Xs System 200 Configurator Software Installation
S93XS System 200 Configurator Software Installation AMETEK’s proprietary S93XS System 200 Configurator Software is shipped with the analyzer and must be installed on a computer to allow communi- cations with the analyzer via its Explosion-Proof Digital Communications Port. Familiarize yourself with the software operations (see Chapter 4) before using the software to work on the analyzer.
Page 69: Installing The S93Xs System 200 Configurator Software
1. Insert the System 200 Configurator Software DVD in the DVD drive. The auto-setup program will run and begin the installation. The Wel- come to the AMETEK S93XS Configurator Setup Wizard screen will appear. Choose Next to initiate installation. ...
Page 70 3. Click Next to continue. The Ready to Install screen will appear. Or, to review or change your installation settings, click Back. To begin the installation, click Install. The Installing AMETEK S93XS Configurator Version #.# screen appears, displaying the installation Status.
Page 71: Removing The Configurator Software
2. Double-click Programs and Features (or Add or Remove Programs). 3. Select AMETEK S93XS Configurator and click Uninstall (or Remove) to remove the software. 4. In the C:\Program Files (x86)\Ametek folder, delete all remaining fold- ers and files. Installation and Start-Up | 3-25...
Page 72: Start-Up And Verification
See “Examining and Car- ing for the Flamepaths” in Chapter 6. Replace parts immediately if damage or wear is apparent. Contact AMETEK if there is any doubt about the integrity of any flamepath. 3-26 | Model 933S UV Analyzer...
Page 73  IMPORTANT Performing analyzer start-up and verification procedures requires us- NOTE ing the System 200 Configurator Software. Familiarize yourself with the software before working on the analyzer. See Chapter 4 for details on how to navigate through the software. To power up the analyzer and verify it is operating properly: 1.
Page 74 LED D406 (Alarm Invalid/Zero-CAL Relay) LED D407 (Concentration Alarm1) LED D408 (Concentration Alarm2) LED D409 (Column A Solenoid) LED D410 (Column B Solenoid) LED D411 (Zero Solenoid) Figure 3-10. Customer I/O board (P/N 100-1758). D401 (Column Block Heater) 3-28 | Model 933S UV Analyzer...
Page 75 d. The green status LED (LED100) on the Host Controller board (Figure 3-5) will stay ON steady for a few seconds before pulsing at a rate of once per second. Verify this operation. The pulsing indicates that communication has been established between the Microcontroller and Host Controller boards.
Page 76 The Optical Bench heater will turn on to heat up the Optical Bench. You can verify this by observing that the red LED201 on the Micro-Interface board is ON steady or pulsing. LED201 (Optical Bench Heater) Figure 3-12. Micro-Interface board (P/N 100-2231). 3-30 | Model 933S UV Analyzer...
Page 77 g. Check the analyzer temperature zones (Optical Bench, Measuring Cell, Column Block): While working from the Configurator Software (Analyzer Data tab), view and record the current (start-up) temperature readings for each zone. These values can be used as a reference later while comparing the temperature values after the analyzer has warmed up.
Page 78 Compare the current temperatures to their respective Set- point values and their start-up values. Normal operating tempera- tures are values that are within 5 % of their Setpoint values. Figure 3-15. Status tab. 3-32 | Model 933S UV Analyzer...
Page 79 h. From the Output Setup dialog box, verify the current and voltage  output ranges and concentration alarm setpoints are configured Setup (tab) Output Setup correctly for the application: • Below each configured channel (Assignment), confirm that the Iout/Vout Low Scale and Iout/Vout High Scale are the correct minimum and maximum ranges required.
Page 80 4 before making changes. For more information about Modbus NOTE implementation on the analyzer, contact AMETEK. After configuring the Modbus Port parameters, click OK then Ap- ply. Save the changes to EEPROM. Figure 3-18. Modbus dialog box. 3-34 | Model 933S UV Analyzer...
Page 81 Upper and Lower Enclosures before closing them. CAUTION Replace the parts immediately if damage or wear is apparent. Contact AMETEK immediately if there is any doubt about the integrity of any WARNING flamepath. 6. Perform an Auto-Setup to optimize the PMT gains of the source lamps.
Page 82: Start-Up Diagnostic Checklist
Check the Over-Temp Switch on the Optical Bench Assembly (see Fig- ure 3-2). If the plunger has popped out, press it to reset it. • Check for proper wiring terminations for the appropriate temperature zone. 3-36 | Model 933S UV Analyzer...
Page 83 Corrective Action Take appropriate safety precautions and check the related RTD for a short or an open circuit. If necessary, replace the RTD with an AMETEK-approved replacement part. Contact AMETEK for assistance. Problem Encountered Alarms remain active after the analyzer has warmed up to normal operat- ing temperature, as displayed on the Status tab (under HC Scode and MC ...
Page 84: Sample System Leak Check
(outlet) side of CAUTION the Filterblock. Pressure differentials of more than 210 KPA (30 PSI) from the inlet side to the outlet side can tear the Filters and they will have to be replaced. 3-38 | Model 933S UV Analyzer...
Page 85 Close the valve on the Vent Line (or remove the Vent Line and cap the Vent Outlet). If the Sample Line is connected to the analyzer, disconnect it from the Sample Inlet fitting and connect Zero gas to the Sample Inlet fitting. 4.
Page 86 Software, power down the computer, and disconnect the serial cable from the analyzer’s Communications Port. Close the Communications Port cover and tighten the screw to secure it in place. The procedure is complete and the analyzer is ready to analyze sample gas. 3-40 | Model 933S UV Analyzer...
Page 87: Sample Conditioning System Optimization
The first UV-absorbing gas species that elute through the chromato- graphic columns are hydrogen sulfide (H S), carbonyl sulfide (COS), and methyl mercaptan (MeSH). Because the Model 933S Analyzer can mea- sure the concentrations of all three of these species, COS and MeSH do not interfere with the H S measurement.
Page 88 “ColumnSetup.dyc” file, and click Open. A graph will appear that displays the concentration signals as a function of time. From the AMETEK Configurator - 93XS main window, click the Standard Toolbar) to start data scanning (see Figure 3-22).
Page 89 Figure 3-22. Column setup graph.  If the X-axis time interval on the ColumnSetup.dyc needs to be ad- justed, right-click your mouse button on the graph, click Display and NOTE change the time period in the Minutes text field. 4. The sample gas should now be flowing through the analyzer and peri- odically, approximately every 120 seconds (default setting), should be switching the two columns.
Page 90 Step 5 is not occurring. To avoid potential interference from EtSH elution, analyzers with the MeSH output option should be set up to switch the columns as soon as a reasonably stable MeSH reading is achieved. 3-44 | Model 933S UV Analyzer...
Page 91 Figure 3-24. Column Profile. Installation and Start-Up | 3-45...
Page 92: Hold Time Optimization
Column Switching Interval has been adjusted, the MeSH Hold Time will also need to be adjusted. Take the new Switching Interval, subtract 2 seconds from it, and use that as the new MeSH Hold Time. 3-46 | Model 933S UV Analyzer...
Page 93 To change the hold times: 1. From the Status tab, click to uncheck the Conc. Alarm Soft Enable On/  Off button to temporarily Disable the Concentration Alarms. Setup (tab)Output 2. View the Column Timing dialog box (Figure 3-23) and enter the new ...
Page 94 This page intentionally left blank. 3-48 | Model 933S UV Analyzer...
Page 95: Chapter 4 Controller / User Interface
CONTROLLER / USER INTERFACE This chapter contains information about the following topics: • An overview of the Model 93XS Analyzer System 200 Configurator Software. • How to work and navigate through the software. • How to view analyzer data, configure analyzer settings, and perform analyzer functions.
Page 96: System 200 Configurator Software Overview - Getting Started
Press this butto n to navigate to the computer’s hard drive to locate files, such as the Configurator file (“93XS.dyc”). Press this button to print scanned data (such as Measure/Reference PMT signals) from the analyzer. 4-2 | Model 933S UV Analyzer...
Page 97 Log window)Setup (tab) In the example at left (and illustrated below), after the Gas Calibration (dialog box) Configurator Software is first started, the AMETEK Configurator <<Man Zero (button)>> main window will appear (Devices & Log window is active in this window). To initiate a Manual Zero, double-click Dev1 (<<Device Name>>) on the Devices &...
Page 98: Starting The Configurator Software And Establishing Communication Between The Analyzer And Computer
2. Power up the computer and start the 93XS System 200 Configurator Software using one of two methods: • Click S93xs from the Start\All Programs\AMETEK 93XS Configu- rator Version #.# menu. • Click the S93xs icon on the computer’s desktop.
Page 99  If at any time you close the 93XS Properties dialog box (by clicking OK or Cancel), the software will revert to the AMETEK Configura- NOTE tor window. To return to the 93XS Properties dialog box, double- click Dev1 on the Devices &...
Page 100: Closing The Configurator Software
1. From the 93XS Properties dialog box, click OK or Cancel at the bottom of the screen. 2. From the AMETEK Configurator window, select File\Exit. 3. Power down the computer and disconnect the serial cable from the analyzer’s Communications Port.
Page 101: Configurator Software Troubleshooting
“Wrong Device” is displayed on the Devices & Log window. Corrective Action Check the analyzer markings to ensure it is a Model 933S Analyzer (the 93XS Configurator Software cannot communicate with other analyzer models). The Communication Protocol/Settings information may be incorrect. Review the settings in the Communication Settings dialog box (Modbus Serial or Modbus TCP) and verify or change them to the proper settings.
Page 102 Corrective Action Enable Device Enabled, if necessary, to establish communication. Check the analyzer markings to ensure it is a Model 933S Analyzer (the Con- figurator Software cannot communicate with other analyzer models). 4-8 | Model 933S UV Analyzer...
Page 103: General Tab
General Tab When the analyzer is connected to the PC, the current Host Control- ler and Microcontroller Firmware Version Number and analyzer Serial Number are displayed to the right of PC Communications (Figure 4-1). Check box selected Configurator Software Version Figure 4-1.
Page 104 “DEMO Online” The PC is not connected to the analyzer (or Device Enabled is selected and Live Data is not selected). Configurator Software version Displays the version of the Configurator Software (below Status). 4-10 | Model 933S UV Analyzer...
Page 105: Modbus Serial / Modbus Tcp Communication Setup
Modbus Serial / Modbus TCP Communication Setup The PC can communicate with the analyzer through the Local Service Port or the Remote Service Port, but not both at the same time. The Local Service Port (RS-232) is located on the front of the Lower Enclosure; the Remote Service Port (RS-485) is accessed via connector J303 on the Host Controller board.
Page 106 If using the RS-485 port, enter a unique Modbus address (Slave ID) for the analyzer. For Modbus Serial communication interface: 0 = Disabled 1–255 = Enabled For Modbus TCP communication interface: 0,1 = Disabled 2–255 = Enabled 4-12 | Model 933S UV Analyzer...
Page 107 Time out (ms) Time out value (duration) that the software will use to attempt to establish communications with the analyzer. AMETEK rec- ommends a value of 1000 ms.  If unsure of the Modbus address assigned to the analyzer, use the alternate or “service”...
Page 108: User Interface
Contains icons used to save data files (not discussed in this manual). • Status Bar Displays system messages. • Devices & Log window This window is a system event log that lists all devices and their status (see “Viewing Device Activities”). 4-14 | Model 933S UV Analyzer...
Page 109: Viewing Device Activities
The Devices & Log window displays the status of all active devices (ana- lyzers), plus a system event log of all analyzer operations. This window, which is displayed within the AMETEK Configurator main window (Fig- ures 4-4 and 4-5), can help you diagnose problems with the analyzer.
Page 110: Saving Analyzer Configuration Parameters
Type (in the Windows navigation field) C:\Program Data\AM- General (tab) <<Save Configuration>> ETEK Configurator\S93xs\data and click Save (AMETEK does not recom- mend saving this file to another path). The file will be saved with a “.dev” extension. This file can be used only by the Configurator Software.
Page 111 3. View the Devices & Log window. If the file restoration is successful, the message “This new CFG has been restored successfully!” will be displayed. If the file that is being restored contains identical information as that already saved to the analyzer’s EEPROM, the message “The restored CFG is not new!”...
Page 112: Modifying Analyzer Device Settings
The analyzer settings have been configured at the factory to meet customer requirements. Changing the factory-set configuration could CAUTION cause the analyzer to operate incorrectly. Message box Figure 4-7. Setup tab, navigation (Modify) buttons. Save CFG to EEPROM button 4-18 | Model 933S UV Analyzer...
Page 113 Modify ent aspects Contains buttons that allow you to view and set up differ of the analyzer (discussed in the following pages).  Dialog boxes for each of the Setup Configuration/Calibration screens discussed in this chapter are sample screens only. Refer to the actual NOTE software screens for enabled/valid parameters for your analyzer.
Page 114 • You can make changes to multiple Modify Configuration dialog boxes before clicking Save CFG to EEPROM. 4-20 | Model 933S UV Analyzer...
Page 115: Saving Analyzer Configuration Parameters To An Ascii File
AMETEK recommends saving and storing these files in path, name the file, and click Save. The file will be saved with a “.dmp” in C:\Program Data\AMETEK extension and stored in C:\Program Data\AMETEK Configurator\S93xs\ Configurator\S93xs\data. data. Figure 4-8. Save As dialog box (Print to File button).
Page 116: Refreshing Configuration Or Calibration Parameters
Then, click Apply (under the Setup tab). The software will prompt “Would you like to save the settings to EEPROM?”. Click YES to send the new value(s) to the analyzer and save them to EEPROM. 4-22 | Model 933S UV Analyzer...
Page 117: Optical Bench
Optical Bench The Optical Bench dialog box allows Optical Bench control and data ac-  quisition parameters to be viewed and modified. Setup (tab)Optical Bench Figure 4-10. Optical Bench dialog box.  ‘**’ following the parameter names below indicates the parameter should only be modified by a trained technician.
Page 118 000 = 1-3-5, 4-6-2 (typical factory default) 001 = 3-5, 4-6-1-2 (custom applications) 010 = 1-3-4-5, 6-2 (custom applications) 011 = motorless (1-3-2) 100 = 1-3-5, 4-6-1(2) (custom applications) 4-24 | Model 933S UV Analyzer...
Page 119 Wheel Revolutions for Avg** The number of Chopper (Filter) Wheel rotations per minute (RPM) used to calculate its RPM during one measuring cycle. K Msr** Not used with Model 933S Analyzers. K Ref** Not used with Model 933S Analyzers. Key Filter** The position of the key filter, which gives the weakest signal for a given source lamp current.
Page 120 This information is also displayed on other screens. Green text = normal conditions. Red text = Warning or Fault alarm active. For details about alarms and corrective action required to reset alarms, see “Troubleshooting and Diagnostics” in Chapter 6. 4-26 | Model 933S UV Analyzer...
Page 121 Auto-Setup button Initiates the Automatic-Setup, which optimizes the PMT gains and source lamp currents. This function combines automatic signal adjust- ment with manual jumper positioning. The Auto-Setup process takes approximately three minutes. Always perform an Auto-Setup after any lamps, optical filters, or PMTs have been replaced. When this button is clicked, a pop-up message is displayed asking “Would you like to proceed with the Bench Auto Setup?”.
Page 122: Cell/Miscellaneous (Compensations) Parameters
One value of Z is used for all species. The default value for this parameter is ‘1’, but can be any value between ‘0.5’ and ‘1.5’. The correction is applied to the concentrations in the following manner: <Conc> = <Conc> corr. uncorr. 4-28 | Model 933S UV Analyzer...
Page 123 Default Cell Pres Displays the default absolute pressure for the Measuring Cell (mmHg). This value is used in place of the Measuring Cell pressure when active pressure compensation is disabled. Enter a value to place the pressure compensation into fixed mode (the approximate Measur- ing Cell pressure).
Page 124 Cell/Misc Parameters dialog box.  IMPORTANT Before changing these settings, record the values and selected options. NOTE These settings must be returned to their original state when changing the output display to its original format. 4-30 | Model 933S UV Analyzer...
Page 125: Temperature Control
Temperature Control The Temperature Control dialog box contains temperature control param-  eters for all of the temperature zones measured by the analyzer. Setup (tab)Temp Control Alarm Indicator box Figure 4-12. Temperature Control dialog box.  ‘**’ following the parameter names below indicates the parameter should only be modified by a trained technician.
Page 126 The alarm indicator box displays active temperature-related alarms. If any alarms are active, see “Troubleshooting and Diagnostics” in Chap- ter 6 for details about the alarm and corrective action to take to reset the alarm. 4-32 | Model 933S UV Analyzer...
Page 127: Optical Bench Temperature Control
Optical Bench Temperature Control The Optical Bench temperature is controlled (by an RTD and heater) to maintain a stable condition for the analysis of the target species and to en- sure that no condensation forms to obscure the light path. The Optical Bench temperature control is protected by an independent over-temperature circuit with a trip temperature of 65 °C.
Page 128: Measuring Cell (Oven) Temperature Control (Optional)
170 °C. The default Measuring Cell temperature Setpoint is factory-set, and is dependent upon the stream temperature. Confirm the Cell/Oven Setpoint for your system on the “Analyzer Programming Parameters” sheet (part of the ana- lyzer Documentation Package). 4-34 | Model 933S UV Analyzer...
Page 129 Measuring Cell Temperature Measuring Range Chart (JP300, Micro-Interface board) Temperature Range Jumper Position Measuring Range A (default) 5 °C to 65 °C  Other ranges are available but AMETEK does not recommend chang- ing the range or the jumpers. NOTE Controller / User Interface 4-35...
Page 130: Column Block Temperature Control
Column Block temperature falls below its Too Cold setpoint or exceeds its Too Hot setpoint, the “f: Column temp too low” or “w: Column temp too high” will be triggered and displayed in the software. 4-36 | Model 933S UV Analyzer...
Page 131: Output Setup
Output Setup The Output Setup dialog box contains current and voltage output assign-  ments plus concentration alarms and setting parameters. Setup (tab)Output Figure 4-13. Output Setup dialog box. There are four independent isolated 4–20 mA outputs (see Figure 3-4, Customer Connections, I/O Board) that can be either loop-powered (loop supply by customer) or self-powered.
Page 132 The voltage Low Scale setpoint corresponding to 1000 mV . Enter ‘0’ if an output is not used. High Scale (Full Scale) The voltage Full Scale setpoint corresponding to 5000 mV . Enter ‘0’ if an output is not used. 4-38 | Model 933S UV Analyzer...
Page 133 Zero (mV) The measured voltage output when the analog output is set to zero scale during the Zero calibration procedure for a voltage output. Span (mV) The measured voltage output when the analog output is set to full-scale during the Span calibration procedure for a voltage out- put.
Page 134: Sensors Setup
NOTE a certain sensor type is indicated in the following descriptions, where applicable. Figure 4-14.1. Sensors dialog box, Sensor 1 with Differential Signal Type selected. 4-40 | Model 933S UV Analyzer...
Page 135 Sensor Enabled Check this to enable the sensor assigned to this circuit (example, for CO measurement). All parameters and action buttons for a sensor are ignored if the sensor is not enabled. Species Name Enter the species being measured by the sensor. This will be dis- played in other software screens.
Page 136 Figure 4-14.2. Sensors dialog box, Sensor 1 with Voltage Signal Type selected. Figure 4-14.3. Sensors dialog box, Sensor 2. Figure 4-14.4. Sensors dialog box, Sensor 3 with Differential Signal Type selected. 4-42 | Model 933S UV Analyzer...
Page 137 Figure 4-14.5. Sensors dialog box, Sensor 3 with Voltage Signal Type selected. Span-Cal Span Concentration The concentration of the component (%) in the calibration gas mixture, for each sensor (entered in decimal notation). Enter ‘0’ if a calibration gas is not used. Span Factor The Span (calibration) Factor for the calculated result (component concentration), for each sensor (adjusted automatically at the...
Page 138 These val- ues are also displayed on the Analog Inputs dialog box (External Sensor Input Offset). This parameter is ignored by Sensor1 with Voltage Signal Type selected. 4-44 | Model 933S UV Analyzer...
Page 139 Interference Compensation Interference Gas #1 and #2 The analyzer can statically compensate the concentration measure- ment from the sensor for up to two interfering gases in the sample stream. % in Process Gas Stream The concentration in % of the interfering gas, Gas #1 or Gas #2, in the sample stream.
Page 140: Modbus Settings
The suggested filename will be predetermined based on coded information from that analyzer (example, m933-YY-933S-JJJJ-N). This file can then be imported and opened us- ing MS Excel. The field at the bottom of this dialog box (that is, RTU 9600 N 8 1 in Figure 4-15) represents the current settings.
Page 141: Matrix
Matrix The Matrix dialog box displays information that is responsible for partially  calculating the concentration output and negating the effects of cross-talk Setup (tab)Matrix by interfering gas species. Figure 4-16. Matrix dialog box. ‘**’ following the parameter names below indicates the parameter ...
Page 142: Analytical Parameters
UV Species 3 Correction Factors to Species 1 Effects of Species 3 on Species 1 are mathematically negated. For a standard Model 933S Analyzer, Species 3 is MeSH and Species 1 is S. Species 2 is COS. to Species 2 Effects of Species 3 on Species 2 are mathematically negated.
Page 143: Analog Inputs
Analog Inputs The Analog Inputs dialog box allows you to configure various parameters  for the analog inputs associated with the analyzer. Setup (tab)Analog Inputs Figure 4-18. Analog Inputs dialog box.  ‘**’ following the parameter names below indicates the parameter should only be modified by a trained technician.
Page 144 Auto-Zero. After entering a value, click Apply to save the changes. Refresh button Reverts the changes made on this screen back to their original settings, but only before you click OK to exit this screen. 4-50 | Model 933S UV Analyzer...
Page 145: Setting Gas Calibration Parameters
Setting Gas Calibration Parameters The Gas Calibration dialog box contains gas species information and  sample system control parameters that are used to Span and Zero the Setup (tab)Gas Calibration analyzer. Figure 4-19. Gas Calibration dialog box. Result Code Each of these factory-set Result Codes corresponds to a specific spe- cies.
Page 146 25 percent of the AZ-0 timer (Timer0) duration.  An Auto-Zero sequence initiated on a timed basis or by a remote con- tact will not be performed if there is an active Fault alarm. NOTE 4-52 | Model 933S UV Analyzer...
Page 147 Cancel Calibration button Cancels the calibration sequence (Manual Zero, Auto-Zero, Span). Calibration Timers Allows you to set up the timers used during calibration. Manual Calibration Enter a time value (default = 60 seconds) for the Integration Timer(sec), during which the concentration reading for each of the species is averaged.
Page 148 Manually forces the flow of sample gas through Column B. 3 = zero Manually forces the analyzer to continuously Zero its sample system with Zero gas. 4 = shut-in/shut-off Manually shuts off the flow of sample gas through the sample system. 4-54 | Model 933S UV Analyzer...
Page 149 5 = sample Manually forces the analyzer to continuously sample. The analyzer is under user control and sample gas is continuously switched through Column A and Column B respectively. Apply button Applies the changes made to the Flow Con- trol mode. Controller / User Interface 4-55...
Page 150: Alarm Setting And Stream Switch Parameters
Gas Calibration dialog box. Span 1 The available options will vary, depending on the application. Span 2 The available options will vary, depending on the application. 4-56 | Model 933S UV Analyzer...
Page 151 Alarm Settings Defines the parameters for the concentration alarms that are displayed on the Status tab. Concentration Alarm 1 is user defined. Concentration Alarm 2 is for concentration alarms. These are both for concentration alarms and both are user defined. Result Assignment Defines a species for each concentration alarm.
Page 152 Stream Switching  For Model 933S Analyzers, this function will default to Single Stream; the stream switching parameters do not apply to Model NOTE 933S Analyzers. Single Stream The Switching Interval (sec) must be set to ‘0’. Two Streams (Not used by Model 933S Analyzers)
Page 153: Analyzer Information
Analyzer Information The Information dialog box displays information about the analyzer and  allows you to reset the analyzer’s Host Controller board. Setup (tab)Analyzer Info Before proceeding, test the area around the analyzer for explosive gases and proceed only when the area is found to be safe. WARNING Do not reset the analyzer if there is an explosive gas atmosphere pres- ent.
Page 154 Parameters” in this chapter). Model ID Displays a code (see Analyzer Legend, below) that the software uses to define the AMETEK analyzer model the software is currently com- municating with (not user adjustable). Analyzer models include: 151 = M931S (Model 931S Analyzer)
Page 155: Column Timing
Column Timing The Column Timing dialog box contains Column operational parameters.  Setup (tab)Column Timing Figure 4-22. Column Timing dialog box. Switching Interval The time in seconds (3–1200 seconds) between column switches. Hold Time This is the duration (seconds) in which the output is held for each Species after Column switching occurs, which allows the output signal to appear steady.
Page 156: Viewing Analyzer Data
Analyzer Status Displays the communication status between the analyzer and the Configurator Software. Messages that can appear here include: Online, OFFLINE, DISABLED, Wrong Device (if the analyzer can- not be recognized), or DEMO. 4-62 | Model 933S UV Analyzer...
Page 157 Host Runtime The length of time the Host Controller board has been operational since the last analyzer reset. Micro Runtime The length of time the Microcontroller board has been operational since the last analyzer reset. Host Controller Board software version Displayed next to Host Runtime (HC/93x Vx.xx), only if the Con- figurator Software is communicating with the analyzer.
Page 158 An analyzer calibration is being performed; the calibration time remaining is displayed on the Analyzer Data tab (Time to end of cal). Stabilizing concentration readings The analyzer is stabilizing (prior to opera- tion), following power-up or a reset. 4-64 | Model 933S UV Analyzer...
Page 159 Calibration Status The status of the calibration functions is dis- played on this display. Depending on which calibration function is in progress, one of the following messages is displayed: Auto-Zero, Manual-zero, Manual-span1, Manual-span2. If no calibration is in prog- ress, this line will be blank. Solenoids This displays the current status of the solenoids.
Page 160 Whenever a Fault alarm condition exists, the text on the Display mes- sage lines on the Optical Bench, Sensors, Gas Calibration, and Infor- mation dialog boxes will turn Red to indicate a fault status. 4-66 | Model 933S UV Analyzer...
Page 161 Conc. Alarm Valid (Relay) Indicates whether the Concentration Alarm is Valid or not (Invalid). When the status is Invalid, this field has a Red background. When the Conc. Alarm relays are configured as Stream Indicators rather than as Concentration Alarm Indicators: Concentration Alarm 1 relay indicates StreamA selected for analysis.
Page 162: Analyzer Data Tab
Bench, Gas Calibration, and Info dialog boxes, and Status tab. Temperature Zones Displays the real-time Temperature (°C) and Duty Cycle (%) of each temperature zone: • Bench (Optical Bench) • Cell (Measuring Cell)/Oven (optional) • Column (Column Block) 4-68 | Model 933S UV Analyzer...
Page 163 Countdown timers Time to next auto-zero(min) The amount of time until the next Auto-Zero starts. Minus 1 (-1) indicates timed Auto-Zero is disabled. Time to end of cal(sec) The amount of time left in the Calibration Integration Timer (see Integration Timer on the Gas Calibration dialog box). A “CAL in progress”...
Page 164: Optical Bench Data Tab
Transmittance The transmittance value for each filter location. Tzero The real-time PMT signal transmittance value for each filter, with Zero gas in the sample system. It is adjusted automatically whenever the analyzer is zeroed. 4-70 | Model 933S UV Analyzer...
Page 165: Chapter 5 Calibration
This procedure describes calibrating the analyzer and the various optional infrared (IR) and thermal conductivity (TC) sensors that can be used with the Model 933S Analyzer. The procedure is generally the same for each of the sensors, except where noted. To verify range and output gas type requirements for the sensor(s) used in your application, refer to the Final “As-Built”...
Page 166: Calibrating The Analyzer And Gas Sensors
Type selected on the Sensor 1 screen. Depending on how the sensor is NOTE configured for your application, data for the sensor will be displayed on either the Sensor 1, Sensor 2, or Sensor 3 screen. 5-2 | Model 933S UV Analyzer...
Page 167 Figure 5-1. Gas Calibration dialog box. Figure 5-2. Analyzer Data tab. Figure 5-3. Sensor 1 with Differential Signal Type selected. Calibration...
Page 168 “auto” for the calibration procedure. Setup (tab)Gas Calibration d. Isolate the Zero gas from the analyzer. e. For approximately 5 minutes, observe the pressure gauges. Loss in pressure must not exceed 0.5 PSI during this time. 5-4 | Model 933S UV Analyzer...
Page 169 Allow the sample system pressure to bleed down to atmospheric pressure (check the pressure gauge). If there is an isolation valve on the Vent Line, close it (or cap the Vent Line outlet). If the sample system does not have an isolation valve, Zero gas may continue to flow.
Page 170 Connect the span gas cylinder (for the species being measured by Sensor3, for example) to the analyzer. Span the analyzer, as described in Step 4-a, then bleed down the span gas and disconnect it from the analyzer. Continue with Step 5. 5-6 | Model 933S UV Analyzer...
Page 171 5. Change the Interference Gas values (#1 and #2) back to their original values, and click Apply. 6. Replace and tighten the Swagelok cap on the analyzer’s Span Gas Connection inlet. 7. Turn on the Zero gas, and adjust it to its original pressure, or as per recommended pressure listed on the Final “As-Built”...
Page 172: Analog Output Calibration
Repeat this step for Output 2 (Pins 3 and 4), Output 3 (Pins 5 and 6), and Output 4 (Pins 7 and 8), recording the value for each output in the corresponding field. 5-8 | Model 933S UV Analyzer...
Page 173 c. Click Apply to save the changes. d. To test the accuracy of the output channels, click Mid-Scale to turn On this function. Verify the current outputs are 12 mA, ± 0.03 mA. e. Click Zero Cal to change its status to Off. 2.
Page 174: Voltage Calibration
Repeat this step for Output 2 (Pins 3 and 4), Output 3 (Pins 5 and 6), and Output 4 (Pins 7 and 8), recording the value for each output in the corresponding field. c. Click Apply to save the changes. 5-10 | Model 933S UV Analyzer...
Page 175 d. To test the accuracy of the output channels, click Mid-Scale to turn On this function. Verify the voltage outputs are 3000 mV, ± 5 mV. e. Click the Span Cal button to change its status to Off. 3. Click Normal to change its status to On, which activates the outputs. The outputs will now track the concentration readings.
Page 176 This page intentionally left blank. 5-12 | Model 933S UV Analyzer...
Page 177: Chapter 6 Maintenance And Troubleshooting
MAINTENANCE and TROUBLESHOOTING This chapter discusses preventive maintenance to keep the analyzer sample system operating at peak efficiency, how to check for plugging in the analyzer sample system, and how to replace internal parts. This chap- ter also discusses how to view alarms (errors) that can be used to diagnose and troubleshoot problems with the analyzer.
Page 178 If a wrist strap is not available, you should at the very least touch the metal chassis to ground yourself before handling the boards. 6-2 | Model 933S UV Analyzer...
Page 179: Preventive Maintenance
For complex maintenance procedures not discussed in this manual, such as replacing heaters, RTDs, or electronic boards, contact AMETEK. Or, review Chapter 7 and then contact AMETEK for assistance with returning the assembly/analyzer to the factory for repair. Maintenance and Troubleshooting...
Page 180: Analyzer Preventive Maintenance Schedule
Clean the interior surfaces of each section to remove contaminants. The Column Assemblies need to be replaced only if they are damaged due to liquids or severe contamination. See “Column Block Maintenance” in this chapter. 6-4 | Model 933S UV Analyzer...
Page 181 The gap must not exceed the listed gap for each location; if the gap exceeds this value, contact AMETEK for advice. See “Examining and Caring For the Flamepaths” in this chapter, for more information.
Page 182: Preventing, Detecting, And Locating A Plug In The Sample System
If the Pressure Compensation option is installed, observe the Cell Pres(sure) reading on the Analyzer Data tab, and if the reading ap- proaches the Zero gas supply pressure, a plug is present somewhere in the sample inlet. 6-6 | Model 933S UV Analyzer...
Page 183 Locating a plug in the sample system: If analyzer problems occur, they are most likely related to improper sam- ple system operation, such as a plug or leak. A plug in the sample system can cause problems in analyzer response time, either to changing process conditions or to Zero gas.
Page 184: Changing Out Replaceable Parts
System 200 Configurator Software. Familiarize yourself with the software before working on the analyzer. See Chapter 4 for details on how to navigate through the software. Figure 6-1. Cell Window Housing and Overtemp switch location, Upper Enclosure. 6-8 | Model 933S UV Analyzer...
Page 185: Measuring Cell Maintenance
Measuring Cell Maintenance This procedure discusses a Standard Range Measuring Cell (40 cm or smaller, Figure 6-3.1) and a Low Range/White Cell (81.2 cm, Figure 6-3.2). See also Figure 6-2 to locate and identify parts. Other types of Measuring Cells are discussed in Manual Supplements shipped with the analyzer. Replace/clean parts in the Measuring Cell: •...
Page 186 Grasp the edge of the Window and carefully remove it. Remove the o-ring. Low Range Remove the Aperture Plate from the Measuring Cell. Grasp the edge of the Window/Mirror Combination and carefully remove it. Remove both o-rings. 6-10 | Model 933S UV Analyzer...
Page 187 Figure 6-2. Optical Bench Assembly, with Standard Range Measuring Cell. Maintenance and Troubleshooting 6-11...
Page 188 Inspect the interior of the Measuring Cell for particulate and clean it with a nonabrasive detergent and water solution, Isopropanol, or reagent-grade acetone followed by a rinse with pharmaceutical- grade distilled water. Allow all components to dry thoroughly before reassembling. 6-12 | Model 933S UV Analyzer...
Page 189 8. Replace parts in the Measuring Cell: It is critical to reassemble the Reflector Block in the exact orientation as it was assembled at the factory. CAUTION If the Cell Windows (or Window/Mirror Combination) are found to be scratched, cracked, or chipped, replace them during reassembly. Do CAUTION not operate the analyzer with faulty parts.
Page 190 Figure 6-3.1. Standard Range Cell, 40 cm or smaller. 6-14 | Model 933S UV Analyzer...
Page 191 Figure 6-3.2. Low Range/White Cell, 81.2 cm (P/N 100-1780-1A). Maintenance and Troubleshooting 6-15...
Page 192 15. If the analyzer uses Measured Pressure Compensation (optional), return the setting to Measured mode. To do this, view the Cell/Misc Parameters dialog box and enter ‘0’ in the Default Cell Pres (pressure compensation) field. 6-16 | Model 933S UV Analyzer...
Page 193 16. Open the valves isolating the analyzer from the sample stream and/or remove the cap from the Vent Line outlet. If using the Rotameter to set the sample gas flow rate, the arrow on the three-way valve must be facing downward while setting the flow rate. CAUTION After the flow rate has been set, switch the Bypass Valve to the “BYPASS”...
Page 194: Column Block Maintenance
Temp Switch, and RTD) requires disconnecting wiring and removing NOTE the entire Column Block Assembly from the analyzer backpan. Instructions to remove the Column Block and replace these parts are not included in this manual. Contact AMETEK for assistance. 6-18 | Model 933S UV Analyzer...
Page 195  “P/N” refers to Part Number. NOTE To clean and replace parts in the Column Block (see Figure 6-4): Hazardous Locations Before proceeding, test the area around the analyzer for explosive WARNING gases and proceed only when the area is found to be safe. Do not remove the cover of the Explosion-Proof Digital Communica- tions Port on the front of the Lower Enclosure, do not connect a serial cable to the Communications Port, do not open the Upper/Lower En-...
Page 196 For each Filter Spool assembly, install (1) new #113 o-ring (P/N 300-9147), (1) Filter (P/N 300-6217), and (1) #010 o-ring (P/N 300-2375). Reassemble the Filter Spool parts and tighten the M6 nut by hand. 6-20 | Model 933S UV Analyzer...
Page 197 Figure 6-4. Column Block assembly. Maintenance and Troubleshooting 6-21...
Page 198 If the entire Column Block Assembly was removed from the analyzer backpan take care not to pinch the wires while securing the Column NOTE Block body to the Column Block Flange. Reconnect the wiring at J107 on the Customer I/O board. 6-22 | Model 933S UV Analyzer...
Page 199 9. Reconnect the tubing to the Column Block. 10. Power up the analyzer and computer. 11. Allow the analyzer to warm up then perform a leak check on the sample system fittings that were disconnected. See “Sample System Leak Check” in Chapter 3. Analyzers without Heated Cells: If the leak check passes, continue with Step 12.
Page 200 18. Using a soft, nonabrasive cloth, gently clean the joining areas (flame- path) of the Upper Enclosure and its door and replace the (24) M10 screws. Tighten the M10 screws to 9.0 Nm, ±1.0 Nm (80 in.-lb, ±9 in.- lb). The procedure is complete. 6-24 | Model 933S UV Analyzer...
Page 201: Source Lamp Replacement
Source Lamp Replacement The typical life span of the source lamps is approximately 9–12 months of continuous operation. However, a source lamp can exhibit signs of degra- dation after 5–6 months. When Do Source Lamps Need to be Replaced? Possible signs of degradation or indications of Source Lamp failures are: •...
Page 202: About The Source Lamps
(After replacing the source lamps, it’s normal for the ana- lyzer results to drift over the first 24 hours of operation.) • This procedure is based on the standard Model 933S Analyzer, bench code 8. Do not interchange the source lamps. Lamp 1 must be cadmium (Cd) –...
Page 203 2. If the analyzer uses Measured Pressure Compensation (optional), change it to Fixed mode so that a “f: Sample gas pressure too low” alarm does not occur. To do this, view the Cell/Misc Parameters dialog  box and enter a value in the Default Cell Pres (pressure compensa- Setup (tab)Cell/Misc tion) field that is the same as, or approximately, the Measuring Cell pressure.
Page 204  Control) to set the analyzer into zero Flow Control mode and then Setup (tab)Gas Calibration click OK. Do not save the changes to EEPROM. Allow the Zero gas to flow for 2–3 minutes. 6-28 | Model 933S UV Analyzer...
Page 205 c. Perform an Auto-Setup. See “The Auto-Setup Sequence” in this  chapter. Setup (tab)Optical Bench<<Auto-Setup>> Figure 6-7. Gas Calibration dialog box. If the Auto-Setup fails after installing new lamps (“Warning Auto Setup” is displayed on the Status tab), it may be necessary to in- crease the Lamp Max from its default value of 7000 mV to 7500 mV and decrease the Signal Max from 8500 mV to 8000 mV and then repeat the Auto-Setup.
Page 206 “M933S.dyc” file to open it and display two Trend graphs, Figure 6-9): • One for Msr (Measure) PMT Signals. • One for Ref (Reference) PMT Signals. Figure 6-9. Configurator window after opening the M933S.dyc file. 6-30 | Model 933S UV Analyzer...
Page 207 The inputs are typically assigned to the channels at the factory. If they  are set up as described in Step a through Step g, continue with Step NOTE 11; if they are not set up, or they need to be modified, follow these steps.
Page 208 14. Change the Flow Control to ‘3’ (zero). Click Apply (next to Flow Con- trol) to set the analyzer into zero Flow Control mode and then click OK. Do not save the changes to EEPROM. Allow the Zero gas to flow for 2–3 minutes. 6-32 | Model 933S UV Analyzer...
Page 209 15. From the Status tab, click Conc. Alarm Soft Enable On/Off to Enable the Concentration Alarms then click OK. Change the Flow Control back to ‘0’ (auto). Click OK then Apply (next to Flow Control). Click OK then save this parameter change to EEPROM by clicking the Save CFG to EEPROM button on the Setup tab.
Page 210: When Is An Auto-Setup Required / Not Required
As a temporary fix, decrease the Signal Max (Optical Bench dialog box) to complete the Auto-Setup until the lamps are replaced. An Auto-Setup is not required as part of a preventive maintenance sched- ule (that is, do not perform an Auto-Setup every month). 6-34 | Model 933S UV Analyzer...
Page 211: Pmt Level And Pmt Balance
• Have there been any leaks from the Measuring Cell? If so, check the condition of the Optical Filters, Beam Splitter, Mirrors, Windows, Lenses, and o-rings in the Optical Bench and in the Measuring Cell (including Reflector Block). Contact AMETEK for procedures not dis- cussed in this manual. ...
Page 212: Auto-Setup Fault Message And Corrective Action
Bench Auto Setup?”. This message also lists conditions that need to be met before proceeding. If the conditions have been met and you wish to proceed with the Auto-Setup, click Yes. If not, click No. The Auto-Setup takes about 3 minutes to complete. 6-36 | Model 933S UV Analyzer...
Page 213: Cancel Auto-Setup
Observe the top line of the Display readout. The following messages are displayed during the Auto-Setup sequence: • Adjusting PMT Level • Adjusting Lamp Pulses • Adjusting PMT Balance • Adjusting PMT Level • Adjusting Lamp Pulses • Setting Up ALC •...
Page 214: Manipulating The Pmt Level And Pmt Balance
3. After the Zero is complete, change the Flow Control back to ‘0’ (auto). Click OK then Apply. Save the changes to EEPROM. 4. From the Status tab, click Conc. Alarm Soft Enable On/Off to Enable the Concentration Alarms then click OK. 6-38 | Model 933S UV Analyzer...
Page 215 Jumper Positions P300 P301 Higher PMT Balance Figure 6-11. Optical Bench board P300 Lower PMT jumper position vs PMT Balance balance.  When changing jumpers, at least one must be present in one of the six positions at all times. NOTE Maintenance and Troubleshooting 6-39...
Page 216: Source Lamp Alignment
7. If the other lamp was also replaced, repeat Steps 4–6. 8. Tighten the Lamp Locking Screw. 9. Tighten the Lamp Clamping Screw to secure the lamps. Do not over- tighten; the spring should not be collapsed. 6-40 | Model 933S UV Analyzer...
Page 217 10. Tighten the Lamp Retaining Screw to secure the Lamp Socket. Do not overtighten; the spring should not be collapsed. 11. Swing the Microcontroller/Micro-Interface board assembly back to its original position and tighten the (2) M3 X 8 screws on its mounting bracket.
Page 218: Natural Gas Filterblock Maintenance
The Natural Gas Filterblock Assembly is designed to filter natural gas in the most critical instrumentation applications. The assembly has three filtration stages. Each stage has its own drain/fast loop. The Filterblock As- sembly is shown in Figure 6-11. 6-42 | Model 933S UV Analyzer...
Page 219: Filtration Stages
Vent Flow • The total vent flow in the Model 933S Analyzer is the sum of the flow through the analyzer plus the flow from the drain Flow Restrictors in the three filter stages.
Page 220: Replacing Parts In The Filterblock
Measuring Cell pressure. Refer to “Cell/Miscellaneous (Compensation) Parameters” in Chapter 4. Close the sample inlet valve. Backpurge the analyzer sample system with Zero gas for 2–3 minutes. 6-44 | Model 933S UV Analyzer...
Page 221 3. Change the Flow Control to ‘4’ (shut-in/shut-off). Click Apply (next to Flow Control) and then click OK. Bleed down the sample system to atmospheric pressure (check gauge). Close the valve on the Vent Line (or cap the Vent outlet). To avoid tearing the Membrane Filters in the Filterblock, always bleed down the sample system pressure on the downstream (outlet) side of CAUTION...
Page 222 15. In each Filterblock section, ensure that the o-rings are still in place and stack the three sections together while aligning the screw holes. Install the (6) M6 X 50 screws and tighten them in a cross-pattern. 6-46 | Model 933S UV Analyzer...
Page 223 Figure 6-12. Filterblock Assembly (100-1782). Maintenance and Troubleshooting 6-47...
Page 224 24. Using a soft, nonabrasive cloth, gently clean the joining areas (flame- path) of the Upper Enclosure and its door and replace the (24) M10 screws. Tighten the M10 screws to 9.0 Nm, ±1.0 Nm (80 in.-lb, ±9 in.- lb). The procedure is complete. 6-48 | Model 933S UV Analyzer...
Page 225: Chopper Assembly Maintenance
Chopper Assembly Maintenance Replace the Chopper Motor Drive Belt and Bearings in the Chopper As-  sembly every 2 years. See Chapter 7 for spare part ordering numbers. When the Ex d Upper/Lower Enclosure is opened for maintenance or repair, take extreme care to avoid scratching or damaging its flame- CAUTION paths.
Page 226 • DC power line from J103. • Optional: If your analyzer has a Cell Heater, disconnect the Heater Cartridge wire (marked ‘N’) at J200 (Terminal 2) and the Overtemp Switch wire (marked ‘L’) at J200 (Terminal 1). 6-50 | Model 933S UV Analyzer...
Page 227 J104 J300 J200 J103 Figure 6-13. Micro-Interface board (100-2231). c. Disconnect the terminals of the green/yellow ground wire that runs from the interior bottom of the Upper Enclosure to the Opti- cal Bench. d. Optional: If your analyzer uses the Optical Bench Purge, discon- nect the purge line (black tube) from the Optical Bench Purge Fitting (Figure 6-14).
Page 228 Replace one Bushing on the Chopper Shaft, followed by a new Bearing (P/N 300-9437), the Chopper Wheel, another new Bearing and the other Bushing. Replace the Spring Washer and the Snap Ring on the Chopper Shaft. 6-52 | Model 933S UV Analyzer...
Page 229 Figure 6-14. Optical Bench Chopper Assembly Maintenance diagram (100-2313-1A). Maintenance and Troubleshooting 6-53...
Page 230 Connect the following wiring connectors to the Micro-Interface board: • Measuring Cell RTD line to J300. • RS-422 communication line to J104. • Micro-Interface AC power line to J200. • DC power line to J103. 6-54 | Model 933S UV Analyzer...
Page 231 • Optional: If your analyzer has a Cell Heater, connect the Heater Cartridge wire (marked ‘N’) to J200 (Terminal 2) and the Overtemp Switch wire (marked ‘L’) to J200 (Terminal 1). d. Optional: If using, connect the purge line (black tube) to the Opti- cal Bench Purge Fitting.
Page 232 15. Using a soft, nonabrasive cloth, gently clean the joining areas (flame- path) of the Upper Enclosure and its door and replace the (24) M10 screws. Tighten the M10 screws to 9.0 Nm, ±1.0 Nm (80 in.-lb, ±9 in.- lb). The procedure is complete. 6-56 | Model 933S UV Analyzer...
Page 233: Examining And Caring For The Flamepaths
The flamepath gap must not exceed 0.1 mm (Group IIB) or 0.04 mm (Group IIB+H2); if the gap exceeds this value, contact AMETEK for advice. See Warning below. For the dimensions of other flamepaths not mentioned here, contact AMETEK.
Page 234 Replace the parts immediately if damage or wear is apparent. Contact AMETEK immediately if there is any doubt about the integrity of any flamepath. 6-58 | Model 933S UV Analyzer...
Page 235: Upper/Lower Electronics Enclosure Flamepaths (Joining Surfaces)
Upper/Lower Electronics Enclosure Flamepaths (Joining Surfaces) Any time either Ex d (Upper or Lower) Electronics Enclosure is opened for maintenance, inspect the enclosure flamepaths for scratches, indentations, or other damage. Carefully clean the flamepaths (joining surfaces) with a soft, nonabrasive cloth before closing it. Before opening the analyzer’s Ex d Upper/Lower Enclosure, follow all necessary safety procedures to ensure the area is nonhazardous (main WARNING...
Page 236: Troubleshooting And Diagnostics
The Model 933S Analyzer has a built-in alarm detection system that continuously monitors the operation of key parameters. An alarm can be detected by either the Host Controller or the Microcontroller and can be of two types: Fault and Warning.
Page 237 A Warning indicates the analyzer may require service and the data may be suspect. Though all Warning alarms cause the Warning Status relay to de- energize, the Warning Status relay can also indicate one of these analyzer operating conditions: • Performing a gas calibration (Auto-Zero, Zero, Span).
Page 238: Host Controller Board Alarm Conditions And Corrective Action
(95 % used). Corrective Action: • Replace the EEPROM as soon as possible. Contact AMETEK to verify operation before removing the EEPROM and for information about installing the new EEPROM to ensure your analyzer will operate the same as it did prior to replacing the EEPROM.
Page 239 • Check the Column Block RTD for a short or an open circuit. • Replace the Customer I/O board. Contact AMETEK to verify operation before removing this board. w: Excessive zero drift...
Page 240 • Confirm the Measuring Cell pressure transducer jumpers on the Customer I/O board are configured correctly (see “Compensations” in Chapter 4). • Replace the Customer I/O board. Contact AMETEK to verify operation before removing this board. w: Sample gas pressure too high Warning The sample gas pressure is above 99 % of the full-scale range.
Page 241 • Check the pressure transducer. • Inspect the Check Valves in the Column Block Assembly for signs of wear (see “Column Block Maintenance” in this chapter). • Replace the Customer I/O board. Contact AMETEK to verify operation before removing this board. Warning w: Low flow detected A low sample gas flow has been detected.
Page 242 • Check the connections of the cable between the Host Controller (J300) and Micro-Interface (J104) boards. Inspect it for damage (cuts, nicks, burn marks, etc.). • Replace the Microcontroller, Host Controller, and/or Micro-Interface boards. Contact AMETEK to verify operation before removing any of these boards. f: Analytical data not received Fault This serious system Fault condition indicates the Host Controller board is not receiving analytical data from the Microcontroller board.
Page 243 • Inspect the Check Valves in the Column Block Assembly for signs of wear (see “Column Block Maintenance” in this chapter). • Replace the Customer I/O board. Contact AMETEK to verify operation before removing this board. f: On-Chip A/D not responding Fault The Host Controller board’s internal analog-to-digital converter (A/D) is not...
Page 244 6-1). If the plunger has popped out, press it to reset it. • Check the Column Block RTD for a short or an open circuit (see “Column Block Maintenance” in this chapter). Replace the RTD, if necessary. Contact AMETEK to verify operation before removing this component. Fault f: Low flow detected A low sample gas flow has been detected.
Page 245 Figure 6-16. AC Distribution board (P/N 100-1771). SW100 Figure 6-17. Host Controller board (P/N 100-1757). Maintenance and Troubleshooting 6-69...
Page 246 SW400 Figure 6-18. Microcontroller board (P/N 100-1781). 6-70 | Model 933S UV Analyzer...
Page 247: Microcontroller Board Alarm Conditions And Corrective Action
• Replace the lamp(s), if necessary (see “Source Lamp Replacement” in this chapter to determine if the lamps need to be replaced and how to replace them). • Replace the Optical Bench and/or PMT Buffer board. Contact AMETEK to verify operation before removing these boards. Maintenance and Troubleshooting...
Page 248 Eventually, a “f: Lamp Failure” alarm will be activated. Refer to the description of this alarm for more details. As a temporary solution, initiate an Auto-Setup to increase the ALC Gain to compensate for the reduced light levels (see “The Auto-Setup Sequence” in this chapter). 6-72 | Model 933S UV Analyzer...
Page 249 (jumpers 1-2). See “Temperature Control” in Chapter 4. • Check the Measuring Cell RTD (Upper Enclosure, see Figure 6-1) for a short or open circuit. Replace the RTD, if necessary. Contact AMETEK to verify operation before removing this component. • Replace the Micro-Interface board. Contact AMETEK to verify operation before removing this board.
Page 250 (jumpers 2-3). See “Temperature Control” in Chapter 4. • Check the Optical Bench RTD (Upper Enclosure, Figure 6-1) for a short or open circuit. Replace the RTD, if necessary. Contact AMETEK to verify operation before removing this part. • Check the heater control circuit: - Check fuse F4 on the AC Distribution board (Figure 6-16) in the Lower Enclosure.
Page 251 • Ensure the Measuring Cell and its Windows are clean and not damaged. • Check and clean, if necessary, the Mirror in the PMT Block. Contact AMETEK to verify operation before checking. Maintenance and Troubleshooting...
Page 252 Final “As-Built” Analyzer Customer Connections drawing in the Analyzer Documentation Package. If the sensor is faulty, replace the sensor. Contact AMETEK to verify sensor operation, to order a new sensor, and/or to remove and replace the sensor.
Page 253 (A/D) is not responding. Corrective Action: Take appropriate safety precautions, open the Upper Enclosure, and: • Replace one or both of the A/D converters. Contact AMETEK to verify operation before removing these components. • Replace the Microcontroller board. Contact AMETEK to verify operation before removing this board.
Page 254 Micro-Interface (J104) boards. Also, inspect it for damage (cuts, nicks, burn marks, etc.). • Replace the Microcontroller, Host Controller, and/or Micro-Interface boards. Contact AMETEK to verify operation before removing any of these boards. f: Cell temperature out of range Fault...
Page 255 Decimal Alarm Value Type Alarm Condition / Description and Suggested Corrective Action Fault f: Lamp Failure If a PMT Reference signal falls below 750 mV for 5 minutes, it indicates the lamp has failed and requires replacement. Corrective Action: • From the Optical Bench Data tab, check the PMT Reference value for each filter.
Page 256: Analyzer Reset
Host Controller CAUTION or Microcontroller boards have been replaced. In this case, it is neces- sary to shut down the analyzer. The analyzer will reset upon normal power-up. 6-80 | Model 933S UV Analyzer...
Page 257: Chapter 7 Service And Parts
SERVICE AND PARTS This chapter discusses what to do if you need technical support from AMETEK, or if you are returning parts for service. This chapter also lists the recommended spare parts to have on hand to ensure preventive maintenance is performed according to the schedule in Chapter 6.
Page 258: Returning Equipment
Material Authorization (RMA) number. This will ensure your equip- ment is serviced and returned to you in a prompt and efficient manner. To obtain a RMA number, contact your local or nearest AMETEK Service Centre and have the following information available: •...
Page 259: Ametek Service And Aftermarket Sales Support
• START UPS all of the AMETEK process analyzers at your facility. Your decision to buy an AMETEK analyzer is greatly • AFTERMARKET SALES appreciated. After the time and money spent on your analyzer, wouldn’t you expect a fast and successful...
Page 260: Recommended Preventive Maintenance Spare Parts
300-8707 Copper (Cu) Source Lamp (Lamp 2, Optical Bench, Upper Enclosure) 300-1528 O-Ring, PUR (Chopper Motor Drive Belt in Optical Bench, Upper Enclosure) 300-9437 Bearing, Chopper Wheel (Chopper Assembly in Optical Bench, Upper Enclosure) 7-4 | Model 933S UV Analyzer...
Page 261 Note 1A: Replace the Flow Restrictors if system flow rates have decreased to unacceptable levels. Note 1B: These o-rings are required only if the Column Assemblies are not damaged and can be reused. New Columns come with o-rings. Note 2: To order new Column Assemblies, contact AMETEK. Service and Parts...
Page 262: Spare Analyzer Fuses
Assembly. Order the Kit or individual spare parts as required. Spare Analyzer Fuses AMETEK recommends having on-site spare fuses used in the analyzer. These fuses do not need to be changed out at regular intervals, but are necessary in the event that a fuse has blown and a replacement is re- quired.
Page 263: Replacement Boards
Ordering a Hard Copy of the Analyzer Operator’s Guide To order a hard copy of the Operator’s Guide and the entire Documentation Package, use the Part Number below: Part No. Description 903-8798 Model 933S UV Analyzer Operator’s Guide Service and Parts...
Page 264 This page intentionally left blank. 7-8 | Model 933S UV Analyzer...
Page 265: Appendix A - Drawings
APPENDIX A – DRAWINGS This appendix contains drawings that are not included in the main body of this manual.  If your Documentation Package includes Final “As-Built” (optional, job-specific) drawings, use those for installation and maintenance/ NOTE diagnostic purposes in place of the installation/maintenance drawings in this manual.
Page 266: Block Diagram, European Style (Wx-933Atex-1
Block Diagram, European Style (WX-933ATEX-1) A-2 | Model 933S UV Analyzer...
Page 267: Block Diagram, North American Style
Block Diagram, North American Style (WX-933NA-1) Appendix A – Drawings...
Page 268: Sample Flow Diagram (Plumbing Schematic), North American Style
Sample Flow Diagram (Plumbing Schematic), North American Style (WX-933NA-2) A-4 | Model 933S UV Analyzer...
Page 269: Backpan Component Layout, North American Style (Wx-933Na-3A
Backpan Component Layout, North American Style (WX-933NA-3A) PROCESS INSTRUMENTS OPTIONAL 81.2cm CELL PLUMBING CONFIGURATION 62.78 SERIAL COMMUNICATIONS PORT DO NOT OPEN IF A HAZARDOUS GAS ATMOSPHERE IS PRESENT MAY NOT BE EXACTLY AS SHOWN REFERENCE CERTIFICATION NO: CSA CERTIFICATE 1031027 (LR48179) Appendix A –...
Page 270: Backpan Dimensions, North American Style
PROCESS INSTRUMENTS OPTIONAL WHITE CELL PLUMBING CONFIGURATION 62.78 SERIAL COMMUNICATIONS PORT DO NOT OPEN IF A HAZARDOUS GAS ATMOSPHERE IS PRESENT MAY NOT BE EXACTLY AS SHOWN REFERENCE CERTIFICATION NO: CSA CERTIFICATE 1031027 (LR48179) A-6 | Model 933S UV Analyzer...
Page 271: Conduit Entries, I/O And Ac Power Connection Locations, North American Style (Wx-933Na-3B
Conduit Entries, I/O and AC Power Connection Locations, North American Style (WX-933NA-3B) LOWER ENCLOSURE DETAIL A REFERENCE CERTIFICATION NO: CSA CERTIFICATE 1031027 (LR48179) Appendix A – Drawings...
Page 272: Lower Enclosure Layout (Wx-14838
Lower Enclosure Layout (WX-14838) A-8 | Model 933S UV Analyzer...
Page 273: Customer Connections Wiring Schematic, North American Style/120 Vac
Customer Connections Wiring Schematic, North American Style/120 VAC I/O BOARD CUSTOMER CONNECTIONS 120VAC POWER TERMINATIONS ISOLATED DIGITAL INPUTS NOTES: FACTORY DEFAULT HC BOARD CUSTOMER CONNECTIONS REFERENCE: CERTIFICATE NO: CSA CERTIFICATE 1031027 (LR48179) Appendix A – Drawings...
Page 274: Communications Cable Connections (300-9480
RS-232 Communications Cable Connections (300-9480) A-10 | Model 933S UV Analyzer...
Page 275: Analyzer Wiring Diagram (Wx-102860-1
Analyzer Wiring Diagram (WX-102860-1) Appendix A – Drawings A-11...
Page 276: Tc Sensor Wiring Diagram (Wx-102860-2
TC Sensor Wiring Diagram (WX-102860-2) A-12 | Model 933S UV Analyzer...
Page 277: Ir Sensor Wiring Diagram (Wx-102860-3
IR Sensor Wiring Diagram (WX-102860-3) Appendix A – Drawings A-13...
Page 278: Optional Hmi And Ethernet Gateway Wiring Diagram (Wx-102860-4
GATEWAY POWER RS232 HOST CONTROL Chassis GND J302 +24VDC TxD- DC GND TxD+ Relay RxD+ HOST 18AWG Relay WIRES RxD- CONTROLLER 301-4183 J302 COM1 CABLE 22AWG 100-1757 100-2712 DCPWR 4-COND (300-0473) (JP303 at 2-3) A-14 | Model 933S UV Analyzer...
Page 279: Optical Bench Board (P/N 100-1662
Optical Bench Board (P/N 100-1662) Appendix A – Drawings A-15...
Page 280: Pmt Buffer Board (100-0140
PMT Buffer Board (100-0140) A-16 | Model 933S UV Analyzer...
Page 281: Sample Probe - North American/European Style
Sample Probe – North American/European Style REFERENCE CERTIFICATION NO: CSA CERTIFICATE 1031027 (LR48179) Appendix A – Drawings A-17...
Page 282: Sample Probe, Recommended Mounting Details - North American (Csa)/ European (Zone 1/Atex
Sample Probe, Recommended Mounting Details – North American (CSA)/European (Zone 1/ATEX) A-18 | Model 933S UV Analyzer...
Page 283: Solenoid Block, North American Style (100-1791-1A
Solenoid Block, North American Style (100-1791-1A)  Do not perform maintenance on this assembly without first contact- ing AMETEK to verify operation and for assistance. NOTE Appendix A – Drawings A-19...
Page 284: Solenoid Block, European Style (100-1917-1A
Solenoid Block, European Style (100-1917-1A) Do not perform maintenance on this assembly without first contact-  ing AMETEK to verify operation and for assistance. NOTE A-20 | Model 933S UV Analyzer...
Page 285: Inlet And Vent Flame Arrestor Locations, Environmental Purge Option (100-1783-1A
Inlet and Vent Flame Arrestor Locations, Environmental Purge Option (100-1783-1A) Appendix A – Drawings A-21...
Page 286: Backpan Component Layout, Division 2 Analyzer With Sensor (Example
OPTICAL BENCH REMOVAL/INSTALLATION LAYOUT MAY NOT BE EXACTLY AS SHOWN  Refer to the Final “As-Built” drawings for analyzer models similar to this. These drawings are located in the Documentation Package NOTE shipped with the analyzer. A-22 | Model 933S UV Analyzer...
Page 287: Supplemental Information
• Signed Final QC (Quality Control) Document • Final As-Built drawings (if ordered). Note that these drawings are not typically included with standard-built Model 933S Analyzers. • Other customer-specific information may also be included (if applicable), such as Product Data Sheets, a Custom Spare Parts list, or analyzer Certificates.
Page 288 This page intentionally left blank. S-2 | Model 933S UV Analyzer...
