FAULT ISOLATION and CORRECTION

If the Media Converter fails, isolate and correct the fault by determining the
answers to the following questions and then taking the indicated action:
1. Is the Power LED on the Media Converter illuminated?
NO
• Is the power adapter the proper type of voltage and cycle frequency
for the AC outlet?
• Is the power adapter properly installed in the Media Converter and in
the outlet?
• Contact Tech Support: 800-260-1312, Int'l: 00-1-952-941-7600.
YES
• Proceed to step 2.
2. Is the SDC LED on the Media Converter illuminated?
NO
• Check the twisted-pair cables for proper connection.
• Contact Tech Support: 800-260-1312, Int'l: 00-1-952-941-7600.
YES
• Proceed to step 3.
3. Is the SDF LED on the Media Converter illuminated?
NO
• Check the fiber cables for proper connection.
• Verify that the TX and RX cables on the Media Converter are
connected to the RX and TX ports, respectively, on the other device.
• Contact Tech Support: 800-260-1312, Int'l: 00-1-952-941-7600.
YES
• Proceed to step 4.
4. Is the RXC LED on the Media Converter flashing?
NO
• If there is no activity on the UTP/STP port, proceed to step 5.
• If there is activity on the UTP/STP port, disconnect and reconnect the
twisted-pair cable to restart the initialization process.
• Restart the workstation to restart the initialization process.
• Contact Tech Support: 800-260-1312, Int'l: 00-1-952-941-7600.
YES
• Proceed to step 5.
5. Is the RXF LED on the Media Converter flashing?
NO
• If there is no activity on the fiber port, contact Tech Support.
• If there is activity on the fiber port, disconnect and reconnect the
fiber cable to restart the initialization process.
• Restart the workstation to restart the initialization process.
• Contact Tech Support: 800-260-1312, Int'l: 00-1-952-941-7600.
YES
• Contact Tech Support: 800-260-1312, Int'l: 00-1-952-941-7600.
10 Tech Support: 800-260-1312 International: 952-941-7600 7am-6pm CST (GMT-6:00)
CONTACT US
Technical Support
Technical support is avialable 7:00 AM - 6:00 PM CST (GMT -6:00)
US and Canada: 1-800-260-1312
International: 00-1-952-941-7600
Transition Now
Chat live via the Web with Transition Networks Technical Support.
Log onto www.transition.com and click the Transition Now link.
Web-Based Seminars
Transition Networks provides seminars via live web-based training.
Log onto www.transition.com and click the Learning Center link.
E-Mail
Ask a question anytime by sending an e-mail to our technical support staff.
techsupport@transition.com
Address
Transition Networks
6475 City West Parkway
Minneapolis, MN 55344, USA
telephone: 952-941-7600
toll free: 800-526-9267
fax: 952-941-2322

DECLARATION OF CONFORMITY

Name of Mfg: Transition Networks
6475 City West Parkway, Minneapolis MN 55344 USA
Model: E-100BTX-FX-05(xxxx) Series Media Converters
Part Number(s): E-100BTX-FX-05, E-100BTX-FX-05(SC), E-100BTX-FX-05(MT),
E-100BTX-FX-05(SM), E-100BTX-FX-05(SMLC), E-100BTX-FX-05(LH),
E-100BTX-FX-05(XL), E-100BTX-FX-05(LW), E-100BTX-FX-05(SMHT),
E-100BTX-FX-05(HT), E-100BTX-FX-05(LHHT), E-100BTX-FX-05(XLHT),
E-100BTX-FX-05(LWHT), E-100BTX-FX-05(SCHT)
Regulation: EMC Directive 89/336/EEC
Purpose: To declare that the E-100BTX-FX-05 to which this declaration refers is in
conformity with the following standards.
EN 55022: 1994 Class A; EN 55024:1998; UL 1950, 3rd Edition; 21CFR subpart J
I, the undersigned, hereby declare that the equipment specified above conforms to the above Directive(s)
and Standard(s).
Stephen Anderson, Vice-President of Engineering
techsupport@transition.com -- Select the "Transition Now" Link for a Live Web Chat
_February 17, 2003_____
Date
