1. Pin Configurations

Figure 1-1. Pinout of ATtiny13A
(PCINT5/RESET/ADC0/dW) PB5
(PCINT3/CLKI/ADC3) PB3
(PCINT5/RESET/ADC0/dW) PB5
(PCINT3/CLKI/ADC3) PB3
(PCINT4/ADC2) PB4
(PCINT5/RESET/ADC0/dW) PB5
(PCINT3/CLKI/ADC3) PB3
(PCINT4/ADC2) PB4
ATtiny13A
2
8-PDIP/SOIC
1
2
(PCINT4/ADC2) PB4 3
GND 4
20-QFN/MLF
1
2
DNC
3
DNC
4
5
NOTE: Bottom pad should be soldered to ground.
DNC: Do Not Connect
10-QFN/MLF
1
2
DNC 3
4
GND
5
NOTE: Bottom pad should be soldered to ground.
DNC: Do Not Connect
8 VCC
7 PB2 (SCK/ADC1/T0/PCINT2)
6 PB1 (MISO/AIN1/OC0B/INT0/PCINT1)
5 PB0 (MOSI/AIN0/OC0A/PCINT0)
15
VCC
14
PB2 (SCK/ADC1/T0/PCINT2)
13 DNC
12 PB1 (MISO/AIN1/OC0B/INT0/PCINT1)
11
PB0 (MOSI/AIN0/OC0A/PCINT0)
10 VCC
9
PB2 (SCK/ADC1/T0/PCINT2)
8
DNC
7
PB1 (MISO/AIN1/OC0B/INT0/PCINT1)
6 PB0 (MOSI/AIN0/OC0A/PCINT0)
8126F–AVR–05/12
