Parts
June 2017
Kit Description
8* I/P Converter Kit
Standard
For Extreme Temperature option
(fluorosilicone elastomers)
9 Adjustment Arm Kit
(includes washer, nut and adjustment arm)
10* Spare Module Base Assembly Kit
[kit contains module base (key 2); drive screws, qty. 2,
(key 11); shield/label (key 19); hex socket cap screw, qty. 3,
(key 38); self tapping screw, qty. 2 (key 49); pipe plug, qty. 3
(key 61); retaining ring, qty. 3 (key 154); screen (key 236);
and flame arrestors, qty. 3 (key 243)]
11* Spare Shroud Kit
12 Remote Travel Sensor Assembly
Note
Contact your Emerson sales office
Travel Sensor Assembly ordering information.
13 Remote Terminal Box Kit
14 Feedback Unit
DVC6015
DVC6025 long arm
DVC6025 Short Arm
DVC6035
DVC6035 (for GX actuator)
15 Feedback Unit Termination Strip Kit
16 Pipestand/Wall Mounting Kit

Parts List

Note
Contact your Emerson sales office or Local Business Partner for Part
Ordering information.
Note
Parts with footnote numbers shown are available in parts kits; see
footnote information at the bottom of the page.
86
Part Number
38B6041X152
38B6041X132
14B5072X132
GE18654X012
GE29183X012
or Local Business Partner for Remote
GE00418X012
49B7986X012
49B7987X012
49B7987X022
49B7988X012
49B7988X022
GE00419X012
GE00420X012
Kit Description
DVC6005 HW2 Base Unit
(see figure 7‐2)
Housing
1 Housing
11 Drive Screw (2 req'd)
20 Shield
(2)
52 Vent, plastic
(16)
74 Mounting Bracket
(16)
248 Screw, hex head (4 req'd)
(16)
249 Screw, hex head (4 req'd)
(16)
250 Spacer (4 req'd)
(16)
267 Standoff (2 req'd)
271 Screen
Common Parts
(1)
16* O-ring (3 req'd)
29 Warning label, for use only with LCIE hazardous area
classifications
33 Mach Screw, pan hd, SST
38 Cap Screw, hex socket, SST
43* Cover Assembly (includes cover screws)
Standard
Extreme temperature option
(fluorosilicone elastomers)
48 Nameplate
49 Screw, self tapping (2 req'd)
63 Lithium grease (not furnished with the instrument)
64 Pipe thread sealant (not furnished with the instrument)
65 Lubricant, silicone sealant (not furnished with the instrument)
(2)
154 Retaining Ring (3 req'd)
(1)
237 Module Base Seal
Module Base
(10)
2 Module Base
(10)
11 Drive Screw (2 req'd)
(1)
12 O-ring
(10)
19 Shield Assembly
(10)
61 Pipe Plug, hex socket
236 Screen, for single-acting direct units only
243 Flame Arrestor Assembly
I/P Converter Assembly
23 Cap Screw, hex socket, SST
(1,8)
39* O-ring
(8)
41 I/P Converter
(8, 11)
169 Shroud
(1,8)
210* Boot, nitrile (2 req'd) (also see figure 6‐4)
(1,6,8)
231* Seal Screen
*Recommended spare
1. Available in the Elastomer Spare Parts Kit
2. Available in the Small Hardware Spare Parts Kit
6. Available in the Seal Screen Kit
8. Available in the I/P Converter Kit
10. Available in the Spare Module Base Assembly Kit
11. Available in the Spare Shroud Kit
16. Available in the Pipestand/Wall Mounting Kit
Instruction Manual
D103785X012
Part Number
(2)
(3 req'd)
(2,10)
(3 req'd)
38B9580X022
38B9580X032
(10)
(3 req'd)
(10)
(10)
(3 req'd)
(2,11)
(4 req'd)
