Parts
June 2017
Figure 7‐2. FIELDVUE DVC6005 HW2 Base Unit Assembly (continued)
OUTPUT B
SUPPLY
WALL MOUNTING
APPLY LUB, SEALANT
NOTES:
1 SEE FIGURE 7‐3 FOR GAUGE CONFIGURATIONS
2. APPLY LUBRICANT KEY 65 TO ALL O-RINGS UNLESS OTHERWISE SPECIFIED
49B3261-C SHT 2 & 3
90
E
OUTPUT A
1
E
OUTPUT B
SUPPLY
Instruction Manual
SECTION E-E
OUTPUT A
PIPESTAND MOUNTING
D103785X012
