Field Communicator Menu Trees
June 2017
Figure B‐6. Manual Setup > Mode and Protection (2-2-1) and Manual Setup > Instrument (2-2-2)
Manual Setup
1 Mode and Protection
2 Instrument
3 Travel/Pressure Control
4 Tuning
5 Valve and Actuator
6 Partial Stroke Test (PST)
7 Outputs
2-2-2-6-5
Accessories
1 Volume Booster
2 Quick Release
3 Solenoid Valve
4 Position Transmitter
5 Limit Switch Valve Open
6 Limit Switch Valve Close
NOTES:
1 HART LONG TAG IS AVAILABLE WITH HART 7.
2 PARTIAL STROKE TEST IS AVAILABLE FOR INSTRUMENT LEVEL ODV.
3 AUXILIARY TERMINAL ACTION AND EDIT AUXILIARY TERMINAL ACTION ARE AVAILABLE FOR INSTRUMENT LEVEL ODV.
102
2-2-1
Mode and Protection
1 Instrument Mode
2 Change Instrument Mode
3 Write Protection
4 Change Write Protection
2-2-2
Instrument
1 Identification
2 Serial Numbers
3 Units
2
4 Terminal Box
5 Analog Input Range
6 Spec Sheet
7 Edit Instrument Time
2-2-2-6
Spec Sheet
1 Units
2 Valve
3 Trim
4 Actuator
2-2-2-6-3
5 Accessories
2-2-2-6-4
Actuator
1 Actuator Manufacturer
2 Actuator Model
3 Actuator Size
4 Actuator Selection
5 Lever Style
6 Lever Arm Length
7 Effective Area
8 Spring Rate
9 Air
Trim
1 Seat Type
2 Leak Class
3 Port Diameter
4 Port Type
5 Flow Direction
6 Push Down To
7 Flow Tends To
8 Unbalanced Area
2-2-2-6-2
Valve
1 Valve Manufacturer
2 Valve Model
3 Valve Size
4 Valve Class
5 Stem Diameter
6 Packing Type
7 Valve Travel
8 Inlet/Outlet Pressures
9 Torque
2-2-2-6-2-9
Torque
1 Dynamic Torque
2 Breakout Torque
Instruction Manual
2-2-2-1
Identification
1 HART Tag
2 HART Long Tag
3 Description
4 Message
5 Polling Address
2-2-2-2
Serial Numbers
1 Instrument Serial Number
2 Valve Serial Number
2-2-2-3
Units
1 Pressure Units
2 Temperature Units
3 Analog Input Units
2-2-2-4
Terminal Box
1 Calibration Button
2 Auxiliary Terminal Action
3 Edit Auxiliary Terminal Action
2-2-2-5
Analog Input Range
1 Input Range Hi
2 Input Range Lo
2-2-2-6-1
Units
1 Travel Units
2 Length Units
3 Area Units
4 Spring Rate Units
5 Torque Units
2-2-2-6-2-7
Valve Travel
1 Rated Travel
2 Actual Travel
2-2-2-6-2-8
Inlet/Outlet Pressures
1 Inlet Pressure
2 Outlet Pressure
