Polycom RMX 4000 Hardware Guide
Table 1-11 RMX 4000 Front Panel LED's (Continued)
Component LED ID
Fabric Switch ERR
Module (FSM
4000)
RDY
ACT
MPM+/MPMx ERR
Card
RDY
ACT
HS
LED Color Description
Red ON - Major error on card.
Flashes - During card startup.
Green ON - The card has completed
startup successfully.
Flashes - During card startup.
Amber ON - At least one participant is
connected to a conference.
Flashes - During card startup.
Red ON - Major error on card.
Flashes - During card startup.
Green ON - The card has completed
startup successfully, after the ERR,
RDY & ACT LED's have stopped
flashing.
Flashes - During card startup.
Amber ON - At least one participant is
connected to a conference.
Flashes - During card startup.
Blue Flashes - Shut down process
initiated by lightly pulling the CPU
ejector levers. This LED flashes in
synchronization with the CNTL
4000's card's HS LED.
ON - Card is in a power down
mode.
Card removal Initiated - The card
can be removed safely once the
CPU ejector levers are fully open.
Card Insertion Initiated - If during
the startup phase the blue HS LED
remains lit, please ensure that the
card is properly seated in the
chassis. If this problem persists,
contact your next level of support.
1-35
