Chapter 1- Hardware Description

RMX 4000 LEDs

RMX 4000 Front Panel LEDs

1-34
The RMX includes LEDs located on the front panel and rear panel. In the
front panel, the LEDs reflect the state of the components. The LEDs on the
rear panel indicate the state of the external connections and the status of
the RTM-IP 4000 card.
The following items appear on the RMX 4000 front panel:
Table 1-11 RMX 4000 Front Panel LED's
Component LED ID
Fan Status
Power Module/ AC
Rail Status (AC
only)
DC
(OK)
DC
(FAIL)
LED Color Description
Green OK.
Red Warning - Fan or power failure.
Green OK.
Red Error - Problem with power supply.
When the power cable is
unplugged, the FAIL LED is lit 2-3
seconds before turning OFF.
Green OK.
Red Error - Problem with power supply.
When the power cable is
unplugged, the FAIL LED is lit 2-3
seconds before turning OFF.
OFF - all In case of a power failure (main/
cable/module) all 3 LED's are OFF.
3 LED's
