V.35/RS-449/RS-530 Network Interface Module

Indicators on the V.35/RS-449/RS-530 Network Interface Module

© Polycom, Inc.
The following paragraphs provide technical information about the
V.35/RS-449/RS-530 network interface module available with the
ViewStation EX, ViewStation FX, and VS4000.
The system's V.35/RS-449/RS-530 network interface module is not
interchangeable with the previous V.35 network interface module.
The new module uses HD-44F connectors for ports 1 and 2, and uses
a keyed RJ-45 connector for the serial link to the back panel of the
ViewStation FX or VS4000. The cable used with the
V.35/RS-449/RS-530 network interface module is the same as is
used for the PRI network interface module. It is shown in Figure 2-5.
An HD-44M to DB-25F adapter cable is available to connect existing
ViewStation DB-25 interface module V.35 network cables.
"Common speeds" are divisible by both 56 and 64. The
V.35/RS-449/RS-530 network interface module supports the
following common speeds:
448 Kbps
896 Kbps
1344 Kbps (E1 only)
The following tables describe the behavior of the indicator lamps on
the V.35/RS-449/RS-530 network interface module.

Table 2-19. V.35/RS-449/RS-530 Peripheral Side Indicators

Indication
Amber LED and
green LED flash once
Amber LED off
Amber LED on
Amber LED and
green LED on
Chapter 2 - Technical Information
Meaning
Power-up test
No communication between endpoint and
network interface module
Communication established between endpoint
and network interface module
Communication established with network
31
