Integrators' Reference Manual for ViewStation EX, ViewStation FX, and VS4000
28
Indicator lamps on the peripheral side of the PRI network interface
module have the same meanings for both the T1 and E1 models.

Table 2-18. PRI Peripheral Side Indicator Lamps

Indication Meaning
Amber LED The PRI network interface module is in boot mode.
on
Amber and New software is being burned into flash.
green LEDs
on
Green LED on The PRI network interface module is fully booted.
a. If this LED stays on for more than a minute, new microcode is
being uploaded from the system to DRAM.
b. If the PRI network interface module is connected to an external
power source, the green LED turns on after several seconds, even
if the peripheral link cable is not connected.
a
b
