The following table gives camera and display information.

Table 2-7. Cameras and Displays

Parameter
Main camera
Main camera
features
Main camera presets
Far camera presets
Tracking
Auto-PIP system
The following table gives electrical specifications for the audio
inputs and outputs.

Table 2-8. Audio Input/Output Electrical Characteristics

Parameter
Impedance
Signal amplitude
Coupling
Impedance
Signal amplitude
Coupling
ViewStation EX and FX
Integrated Sony EVI-10
65° field of view
12 x Zoom; f=4.2 to 42 mm
F=1.85 to 2.9 mm
Auto focus
Automatic white balance
Voice tracking
Track to presets
Auto-on, auto-swap, auto-off
Value/format
Input
10 K minimum
1.0 V full-scale (expected)
pp
AC
Output
800 maximum
1.0 V full-scale (typical)
pp
AC
VS4000
External Sony
EVI-D10
10
10
