Integrators' Reference Manual for ViewStation EX, ViewStation FX, and VS4000
Indicator Lamps on the V.35/RS-449/RS-530 Network
Interface Module
112
The V.35/RS-449/RS-530 network interface module uses lamps on
both the network side and the peripheral side to provide status
indications.

Table 6-4. V.35/RS-449/RS-530 Indicator Lamps - Network Side

Lamp behavior
Amber LED on
Green LED on

Table 6-5. V.35/RS-449/RS-530 Indicator Lamps - Peripheral Side

Lamp behavior
Green and amber
LEDs flash once,
then turn on
Amber LED on
Green LED on
Meaning
Indicates that a port is properly connected to an
active DCE and is receiving a network clock
The system is in a call
Meaning
System booting
System is communicating with the network
interface module
System is communicating with the network
