Installation Guide
Elise3
7.2

Restarting the Elise3

7.2.1 Controlled Restart using Restart Button
When a controlled restart is performed via the Restart button, all ongoing jobs on the Elise3
ends in a controlled way and everything is logged. When the Elise3 has shut down, the user
can unplug the power cable or wait one minute for the Elise3 to automatically start up
again. During startup, there is a delay for three seconds where the user is able to interact
with the Elise3 and change to Boot Mode.
Use a paper clip or similar and press the Restart button and release it within 4 seconds. The
Status LED indicates shutting down with quick flashing blue light
up again, the Status LED will indicate "waiting" for one minute with yellow light
Here the power cable can be detached.
If the power cable is not detached the module starts up automatically after one minute. The
Status LED indicates starting up with quick flashing blue light
Another form of a controlled restart can be performed via the GUI, but then the Elise3 will
immediately start up again without the one minute delay and will not give you enough time
to unplug the power cable.
7.2.2 Forced Restart
Forced restart is used as a last resort when the Elise3 does not respond at all.
When a Forced restart is performed, ongoing jobs are not finished (as in a controlled
restart).
The Elise3 detects that a forced restart has been made and a voltage restart is performed.
During startup, there is a delay for three seconds where the user is able to interact with the
Elise3 to change to Boot Mode.
Use a paper clip or similar and press the Restart button for at least 5 seconds.
The power LED will turn off for a short time (3 seconds) and when it turns on again the
Status LED indicates starting up with quick flashing blue light
7.3

Factory Reset

Resetting the Elise3's software back to factory default settings can be done from the
product's web interface on the Configuration page under Software. Either by switching
software or reinstalling software and selecting factory default settings.
Factory default settings can also be chosen from the Boot Mode's web interface when new
software is installed or when returning to Normal Operation from Boot Mode, see
Install Software in Boot Mode
NOTE: Network settings (IP address, Host name, etc.) are not changed.
22 November 2013 / Ver. G
7. Maintenance
on page 28.
TD 92679EN
. Before starting
.
.
.
5.1.3
32
