Installation Guide
Elise3
7.

Maintenance

7.1

Software Management

7.1.1 Installation of Software
Normally the installation of software is done from the product's web interface but it can also
be done in Boot Mode, see
7.1.2 Create Backup of Software Settings
Normally the backup is done from the product's web interface but it can also be done in
Boot Mode.
Set the product in Boot Mode, see
1 Select Software > Install software.
2 Click "Backup". All settings for last run software will be saved.
3 Click "Save" in the File Download window.
4 Select where to save the file and click "Save" again.
7.1.3 Field Upgrade of Boot Software
By using a USB memory stick with a Boot software (autoupdate.bin), the Elise3 can be
upgraded on the field.
1 Insert the USB memory stick in the upper USB connector marked 1.
2 Perform a controlled restart via the Restart button, by pressing the button and
releasing it within 4 seconds.
The Status LED indicates shutting down with quick flashing blue light
Before starting up again, the Status LED will indicate "waiting" for one minute with
flashing yellow light
3 When the Status LED indicates starting up with quick flashing blue light
press the Mode button within 3 seconds.
The Mode button should indicate by showing fixed blue light
The module now detects the memory stick and begins the upgrade process which is
indicated by the Status LED with fixed yellow light
7-8 minutes.
After the upgrade process has finished, the Elise3 will continue and start up the last used
software. The complete operation can take up to 10 minutes.
To verify a successful upgrade, you can put the USB stick back in your computer and open
the file autoupdate.log. In the end of that file, you should then see the text "Upgrade
finished successfully".
NOTE: If the USB memory stick contains faulty Boot software, the module will start up in
Boot Mode.
22 November 2013 / Ver. G
7. Maintenance
5.1.3 Install Software in Boot Mode
5.1 Set Elise3 in Boot Mode
.
TD 92679EN
on page 28.
on page 27.
.
. The upgrading process takes
.
,
