Installation and Configuration

The Elise3 can be mounted vertically on a wall or be placed horizontally in a 19" rack. It must
be fixed by screws or other fixtures to the wall or rack, and must not be easily movable.
Figure 5. Recommended installation and configuration procedure
Mount the
hardware
4.1

Mounting

4.1.1 Environmental
The Elise3 shall be placed in an environment with an ambient temperature between 0°C to
+40°C (32°F to 104°F). Relative humidity: 30 - 85% RH (non condensing).
4.1.2 Installations Requiring Seismetic Considerations
When installing the Elise3 in geographic regions with seismic conditions and special
considerations, check regional codes and regulations to determine if any requirements exist
and apply for securely mounting ITE equipment.
After the desired rack or cabinet is installed, install the Elise3 in accordance with the
instructions in
4.1.3 Wall Mounting
Four screws size 3.5×40 mm (0.14×1.6 in) together with four wall plugs and four screws
size M3×6 mm (0.12×0.24 in), are delivered with the product. The M3×6 screws are used
for attaching the assembly brackets to the module. Use the 3.5×40 mm (0.14×1.6 in)
screws for walls made of wood. For walls made of concrete and bricks use them together
with the wall plugs. For other types of walls use suitable screws and plugs according to wall
material.
IMPORTANT: When mounted on a wall, it is of great importance that the connections are
1 Fasten the supplied assembly brackets on the bottom side of the Elise3.
2 Use the supplied screws and wall plugs (or other suitable screws and plugs
dependent on wall material) and mount the Elise3 as shown in
22 November 2013 / Ver. G
4. Installation and Configuration
Connect the Access the
supply voltage application
4.1.3 Wall Mounting and
located in a vertical plane.
Basic
configuration
4.1.4 Rack Mounting on page 11.
TD 92679EN
Connect
to required
equipment
figure 6.
