Installation Guide
Elise3
2 Enter the IP address "192.5.36.229" in a web browser on your computer to access
the product's web interface.
3 Continue in
Install the Port Driver on Windows XP/Vista
NOTE: When switching between mass storage mode and network mode, it takes about 30
seconds before the Elise3 can be accessed with the 192.5.36.229 address.
1 Connect a mini-USB type B cable between the USB port on your computer and the
management port on the Elise3.
The Found new hardware wizard opens but at this stage there is no valid port driver
so close the wizard and continue to install the driver.
2 Press the Mode button twice to change the mode to mass storage.
The module will now turn up as a mass storage device on your computer. This is
indicated by slow flashing blue light
3 Locate the required "elise3.inf" driver and save it on your computer.
4 Press the Mode button twice again to change the mode to network access.
The Found new hardware.... dialog window opens.
5 Select "No, not this time" and click "Next".
6 Select "Install from a list or specific location (Advanced)" and click "Next".
7 Select "Search for the best driver in these locations".
8 Select the "Include this location in the search:" check box.
9 Browse to the folder where the port driver is saved.
10 Click "Next". The installation of the port driver begins. If a message opens, saying the
software has not passed Windows Logo testing, click "Continue Anyway".
11 Click "Finish".
22 November 2013 / Ver. G
4. Installation and Configuration
4.6 Basic Configuration on page 24.
TD 92679EN
on the Mode button LED.
