Introduction
The 2260B-RMK-Series Rack Mount Kit is suited for Series 2260B Multi Range DC Power Supplies.
2260B-RMK-Series supports both the EIA (2260B-RMK-EIA) and JIS (2260B-RMK-JIS) standards for use with
standard sized rack units. Incorporating a strong frame and robust design, the 2260B-RMK-Series can fit up to six
360W models or three 720W models 2260B power supplies.
Please check to make sure all the components of the 2260B-RMK-Series rack mount kit are provided. The JIS
and EIA rack mounts have slightly different component sets.
Part lists
2260B-RMK-EIA Assembly
Description
1
Rack Screw
2
Front Bracket
3
BLANK PANEL
4
BLANK PANEL
5
BLANK PANEL
6
SR-3S
7
Middle Bracket
8
PMS-W-3*8
9
EIA BRACKET 3U
10
FMS-3*8
11
FMS-3*5
12
Right Bracket
13
Left Bracket
14
Rear Bracket
15
IMS 3*6
16
Rack HP
17
Rack HP
18
BMS-W-3*8
March 2014
2260B-RMK-Series Rack Mount Kit
Assembly and Mounting Instructions
NOTE
Part number
59CA-04017NS1
62RA-410HP201
62RA-410HP801
62RA-410HP701
62RA-410HP601
5320-00403001
62RA-410HP101
592B-W3008NS1
62RA-410HPAA1
593B-03008NS1
593B-03005NS1
62RA-410HP5B1
62RA-410HP4A1
62RA-410HP3A1
599B-03006NS1
62RA-410HP9A1
62RA-410HPD01
594B-W3008NS1
Quantity
3
1
1
1
1
4
1
3
2
4
4
1
1
1
4
5
1
5
1
