Front Panel - M2TECH MARLEY User Manual

M2Tech
marley
DUAL-DRIVE CLASS-A HEADPHONES AMPLIFIER
REVISION P .A – OCTOBER 2013 www.m2tech.biz
R

2. Front Panel

Figure 1
1) On/off/mute/menu escape button. Push this button to turn the MARLEY on when
it's off. When the MARLEY is on, a short push will toggle muting, unless the menu has
been previously accessed: in the latter, a short push will cause immediate menu
escape and configuration changes discard. A prolonged button push while the MARLEY
is on will cause its switch-off.
2) Display. Multi-function LCD display. During normal operation, it indicates the
listening level for the active outputs, the selected source and the mute status. When
Copyright © 2013, M2Tech Srl
11
