7) Output for single-ended headphones. Connect the jack of a headphones set to
each of these two outputs. It is possible to use one output or both outputs at the
same time. These two connectors should be used as alternative to the balanced
headphones connector (item 8). 6,35mm (1/4") stereo socket.
8) Output for balanced headphones. Connect the XLR connector of a headphones
set to this output. This connector should be used as alternative to the single-ended
headphones connectors (item 7). 4-pin female XLR socket.
9) Input for high-current, low-noise power supply. Connect the plug from the
dedicated high-current, low-noise power supply dedicated for the MARLEY. 4-pin, male
XLR socket.
10) Input for power from wall wart. Connect the jack from the 15V-2A wall wart
included in the package. 5.5/2.1mm jack with positive on tip.
