2. Front Panel

1) Display. It shows the operation information (sampling frequency, selected input, etc.).
Moreover, it shows all active options (See Chap. 8).
2) Clip indicator. It lits when the input analog signal reaches the preset level (See Chap.
7).
3) Remote control IR receiver. Aim the remote at this point to send command to the
device.
NOTE: the remote control provided with the EVO PHONODAC TWO
for the Evo DAC Two Evo DAC Two and EVO DAC TWO PLUS
Evo DAC Two Evo DAC Two
owns both units, it may happen that a command sent to one of them will also affect
the other. To avoid interferences, place the two units apart each other or keep the
unused unit off.
M2TECH
EVO P DAC Two
HONO
DXD-DSD A/D-D/A CONVERTER
PHONO PREAMP
CLIP
1 2
Figure 1
EVO DAC TWO PLUS. For this reason, whenever the user
EVO DAC TWO PLUS EVO DAC TWO PLUS
9
3
EVO PHONODAC TWO is the same used EVO PHONODAC TWO EVO PHONODAC TWO
