Blade Guard and Miter Gauge Parts List

No. Description
Miter Gauge Assembly
21 3/16-24NCx3/8" Pan Head Phillips Screw
22 Angle Indicator
23 Mounting Block
24 Indexing Pin
25 M5 O-Ring
26 Miter Gauge Head
28 8-32x5/8" Pan Head Phillips Screw
29 8-32 Hex Nut
30 Miter Gauge Handle
31 M8x18x3 Washer
32 Miter Gauge Bar
33 Gauge Head Mounting Screw
34 1/4-20x5/16" Flat Head Phillips Screw
35 Retaining Disc
Micro-Guard Blade Guard Assembly
36 Top Guard
37 Side Guard Front Right
38 Side Guard Middle Right
39 Side Guard Rear Right
40 Side Guard Front Left
41 Side Guard Middle Left
42 Side Guard Rear Left
43 Grooved Clevis Pin (3mm x 8mm)
44 3mm E-Style Retaining Ring
45 Front Dowel Pin (4mm x 20mm)
46 Rear Grooved Pin (4mm x 15mm)
47 Top Guard Extension Spring
48 M3x0.5x16 Socket Head Cap Screw
49 Rear Grooved Pin Spacer
50 M3x0.5 Lock Nut
51 M3x1.06x8 Pan Head Phillips Screw
52 Spreader
53 M6x1.0x30 Button Head Socket Screw
54 M6x16x1.5 Washer
55 Anti-Kickback Pawl Left
56 Pawl Bushing
57 Anti-Kickback Pawl Right
58 M6x1.0 Lock Nut
59 M4x25 Spring Pin
60 Pawl Spring
36-51 Complete Top Guard Assembly
Part No. Qty.
CNS-07-226 1
CNS-07-227 3
CNS-07-228 1
CNS-07-229 1
CNS-07-230 1
CNS-07-231 1
CNS-07-232 1
CNS-07-234 3
CNS-07-235 3
CNS-07-236 1
CNS-07-237 1
CNS-07-238 1
CNS-07-239 1
CNS-07-240 1
CNS-07-241 1
TSG-MG 1
TSG-MG-001 1
TSG-MG-002 1
TSG-MG-003 1
TSG-MG-004 1
TSG-MG-005 1
TSG-MG-006 1
TSG-MG-007 1
TSG-MG-008 6
TSG-MG-009 6
TSG-MG-010 1
TSG-MG-011 1
TSG-MG-012 2
TSG-MG-013 1
TSG-MG-014 1
TSG-MG-015 1
TSG-MG-016 1
TSG-MG-017 1
TSG-MG-018 1
TSG-MG-019 2
TSG-MG-020 1
TSG-MG-021 1
TSG-MG-022 1
TSG-MG-023 1
TSG-MG-024 1
TSG-MG-025 1
TSG-MG-026 1
SawStop 10" Contractor Saw 101
