Hardware Installation

Note: To achieve optimal performance, a CAT6 cable is
recommended.
1. Power off all devices including your HDMI source and
display.
2. Connect your HDMI source to the Transmitter's HDMI
IN connector.
3. Optional: Connect the IR Blaster extension cable to the
Transmitter's IR Out. Face the eye towards your HDMI
device's IR window.
4. Connect your HDMI display to the Receiver's HDMI OUT
connector with an HDMI cable (not included).
5. Optional: Connect the IR Receiver extension cable to the
Receiver's IR In.
6. Switch the EDID according to your desired HDMI signal
format. Refer to page 4 for details.
7. Connect and link the Transmitter and Receivers by
CAT5e/6 cables.
8. Plug the included power adapters into the Transmitter's
and Receivers' Power Jacks, then plug three power
adapters into reliable power outlets.
9. Power on your HDMI device and HDMI displays.
10. The HDMI Extender is ready for use.
8
