gofanco HDMIExtSplit Manual page 7

IR Extenders
Figure 5: IR Blaster
(Connect to Transmitter TX)
• IR Blaster: Plug into the Transmitter's IR 3.5 socket to
emit IR signals.
• IR Receiver: Plug into the Receiver's IR 3.5 socket to
receive IR signals from a remote control (for the HDMI
device connected to the Transmitter).
Note: Incorrect placement of the IR Blaster and IR
Receiver may result in failure of these cables. Please
check carefully before plugging in the IR cables to
proper IR sockets.
Figure 6: IR Receiver
(Connect to Receiver RX)
7
