1.

Introduction

This document helps customers procure power cords for the Intel
S7000FC4UR.
This information is available for each power cord by geographical region:
Component description and function
Part numbers and revision levels
Vendor contact information
2.

Power Cord Specifications

®
The Intel Server System S7000FC4UR does not include power cordsets for the two 1570-watt
power supplies because of the unique requirements and differing AC services in regions where
the system may be shipped.
The maximum input/output power expectations of the server system are:
System power input: 80% efficiency at 90-240 VAC
System power output: 1570 Watt
2.1

1570 Watt Power Supply Specifications

The AC input specifications of the 1570-watt power supply are:
Parameter
Input Voltage (Low Line)
Input Voltage (High Line)
Input Current (90VAC)
Input Current (103.5VAC)
Input Current (180VAC)
The AC inlet connector is an IEC320 C14 receptacle (rated for 15A, 250VAC).
Revision 1.0
Minimum Nominal
90 100-127
180 200-240
®
Server System
Maximum Unit
140 VAC
rms
264 VAC
rms
14.4 A
rms
14.4 A
rms
11.1 A
rms
