Functional characteristics
Advanced settings
5.7
Advanced settings
5.7.1
Setting slope times for secondary current AMP% or pulse edges
Display
60
Setting/selection
Expert menu
Slope time tS1 (main current to secondary current)
Setting: 0.00 s to 20.0 s (factory setting 0.01 s)
Slope time tS2 (secondary current to main current)
Setting: 0.00 s to 20.0 s (factory setting 0.01 s)
Figure 5-17
Figure 5-18
Item No.: 099-000108-EWM01
