5.3.2.2

Hotstart time

Operating
element
5.3.3

Arcforce

Shortly before the electrode threatens to stick, the arcforcing device sets an increased current designed
to prevent the electrode sticking.
Operating
element
5.3.4

Antistick

5.4

Key switch

These accessory components can be retrofitted as an option, see Accessories chapter.
To protect against unauthorised or unintentional adjustment of the welding parameters on the machine,
the control input can be locked with the aid of a key switch.
Key position 1 =
Key position 0 =
Item No.: 099-000108-EWM01
Action
Result
Select hotstart time welding parameter
Press until hotstart time light
Set hotstart time
Action
Result
Select arcforcing welding parameter
1 x
The
Set arcforcing
-40
= low current increase > soft arc
0
= default setting
+40
= high current increase > aggressive arc
All parameters can be set
The following operating elements/functions cannot be changed:
"Welding process" button
"Welding current polarity" button
Parameter values in the function sequence can be displayed but not
changed
Functional characteristics
sec
comes on
signal light lights up in red
Anti-stick prevents the electrode from annealing.
If the electrode sticks in spite of the Arcforce device, the
machine automatically switches over to the minimum
current within about 1 second to prevent the electrode
from overheating. Check the welding current setting
and correct according to the welding task!
NOTE
Key switch
Displays
Displays
55
