2. Installation
This chapter offers information about installing your router. If you are not familiar with
the hardware or software parameters presented here, please consult your service
provider for the values needed.
2.1 System Requirement
1.
Personal computer (PC)
2.
Pentium III 266 MHz processor or higher
3.
128 MB RAM minimum
4.
20 MB of free disk space minimum
5.
RJ45 Ethernet Port
2.2 Hardware Installation
This section describes how to connect and configure the ADW-4401.
Step 1. Connect the ADSL Line
Connect the router directly to the wall jack using the included ADSL cable.
Step 2. Connect a Workstation to the Router's LAN port
There are two methods to connect the router and workstation. The one use the crossover
Ethernet cable to connect directly between them. The other use straight Ethernet cable
to connect router with hub (or switch), then go to the workstation.
Step 3. Connect the Power Adapter to the Router
Connect the power adapter to the port labeled POWER on the rear panel of router.
Step 4. Connect All Cables to the Network
The procedure for connecting cables differs depending on whether or not your
To ADSL Line
To PC /Hub
10
Power Adapter
