The following table describes the labels in this screen.
LABEL
Encapsulation
Static IP Address
IP Subnet Mask
Gateway
NAT
Default Route
Dynamic Route
Multicast
(3) PPPoA / PPPoE
Select this option if your ISP requires you to use a PPPoE connection. This option is
typically used for DSL service. Select Dynamic PPPoE to obtain an IP address
automatically for your PPPoE connection. Selection Static PPPoE to use static IP
address for your PPPoE connection. Please enter the information accordingly.
Select your encapsulation type from the dropdown list.
Enter the static IP Address here.
Enter the IP Subnet Mask here.
Enter the Gateway address here.
Select whether NAT is Enabled or Disabled.
Select whether this PVC will be the default route for
Internet data.
Select the RIP type and direction from the dropdown lists.
Select the multicast protocol you wish to use from the
dropdown list.
30
DESCRIPTION
