Planet 802.11g Wireless ADSL 2/2+ Router ADW-4401A/Bv2 User Manual page 31

LABEL
Username
Password
Encapsulation
Bridge Interface
Connection
TCP MSS Option
Get IP Address
Static IP Address
IP Subnet Mask
Gateway
NAT
Default Route
TCP MTU Option
Dynamic Route
Multicast
Enter your username for your PPPoE/PPPoA connection.
Enter your password for your PPPoE/PPPoA connection.
Select your encapsulation type from the dropdown list.
Select whether the Interface will be Activated or Deactivated.
Select whether your connection is always on or if it connects on
demand. If on demand, specify how many minutes the
connection may be idle before it disconnects.
Enter the TCP MSS you wish to use here.
Choose whether the ROUTER obtains the IP address statically
or dynamically.
Enter the static IP address here. Only if you chose Static above.
Enter the IP subnet mask here. Only if you chose Static above.
Enter the gateway here. Only if you chose Static above.
Select whether NAT is Enabled or Disabled.
Select whether this PVC will be the default route for Internet
data.
Enter TCP MTU Value here.
Select the RIP type and direction from the dropdown lists.
Select the multicast protocol you wish to use from the dropdown
list.
31
DESCRIPTION
