Planet 802.11g Wireless ADSL 2/2+ Router ADW-4401A/Bv2 User Manual

802.11g wireless adsl 2/2+ router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
802.11g Wireless
ADSL 2/2+ Router
ADW-4401A/Bv2
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 802.11g Wireless ADSL 2/2+ Router ADW-4401A/Bv2 and is the answer not in the manual?

Questions and answers

Related Manuals for Planet 802.11g Wireless ADSL 2/2+ Router ADW-4401A/Bv2

Summary of Contents for Planet 802.11g Wireless ADSL 2/2+ Router ADW-4401A/Bv2

  • Page 1 802.11g Wireless ADSL 2/2+ Router ADW-4401A/Bv2 User's Manual...
  • Page 2 Copyright Copyright 2007 by PLANET Technology Corp. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of PLANET.
  • Page 3 FCC Caution To assure continued compliance (example-use only shielded interface cables when connecting to computer or peripheral devices). Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules.
  • Page 4 Revision User’s Manual for 802.11g Wireless ADSL 2/2+ Router Model: ADW-4401 A/Bv2 Rev: 1.0 (Dec. 2006) Part No. EM-ADW4401v2_v1...

  • Page 5: Table Of Contents

    1. Introduction…………………………………………………………………………7 1.1 Feature…………………………………………………………………….…….7 1.2 Package Contents………………………………………………………………..8 1.3 Physical Details…………………………………………………………………8 2. Installation…………………………………………………………………………10 2.1 System Requirement…………………………………………………………...10 2.2 Hardware Installation…………………………………………………………..10 2.3 Configuring the Network Properties…………………………………………...11 3. Configuration………………………………………………………………………16 3.1 Determine your connection settings……………………………………………16 3.2 Connecting the ADSL Router to your network……………………….………..16 3.3 Configuring with Web Browser………………………………………………..16 3.3.1 Quick Setup Guide…………………………...17 3.4 Maintenance………………………….………………………………………..20 3.4.1 System Time...20...
  • Page 6 3.7.1.4 DNS Relay……………………………………………………...36 3.8 Wireless Configuration……………………………………………………...36 3.8.1 Wireless Settings……………………………………….……………...36 3.8.1.1 Wireless Security………………………….……………….…...37 3.8.1.2 Advanced Setting…………………………….….…………..….38 3.8.1.3 MAC Address………………………………….………...39 3.9 Access Management ...…….39 3.9.1 ACL…….…………………………………………………………...39 3.9.2 IP Filtering……………………………………………………………….40 3.9.3 SNMP……………………………………………………………….…...42 3.9.4 UPNP...…...43 3.9.5 DDNS……………………………………………………………….…...44 3.10 Advanced Setup...…...45 3.10.1 NAT Setting…………………………………………………………...45 3.10.1.1 Virtual Server……………………………………………...…49 3.10.1.2 DMZ……………………………………………………...50 3.10.1.3 IP Address Mapping...…...51 3.10.2 ADSL Type Setting……………………………………………...52...

  • Page 7: Introduction

    1. Introduction The PLANET 802.11g Wireless ADSL 2/2+ Router, ADW-4401v2, provides office and residential users the ideal solution for sharing a high-speed ADSL 2/2+ broadband Internet connection on a 54Mbps wireless network and a 10/100Mbps Fast Ethernet backbone. It can support downstream transmission rates of up to 24Mbps and upstream transmission rates of up to 3.5Mbps.

  • Page 8: Package Contents

    VPN Pass through Support. PCs with VPN (Virtual Private Networking) software using PPTP, L2TP and IPSec are transparently supported - no configuration is required. RIP1/2 Routing. It supports RIP1/2 routing protocol for routing capability. Simple Network Management Protocol (SNMP). It is an easy way to remotely manage the router via SNMP.
  • Page 9 Front Panel LED definition State When the router is powered on and in ready state When the router is powered off. WLAN Flashing When wireless AP is ready Successful connection between ADSL modem and telecom' s network ADSL Flashing Modem is trying to establish a connection to telecom’s network Link Flashing TX or RX activity No Link...

  • Page 10: Installation

    2. Installation This chapter offers information about installing your router. If you are not familiar with the hardware or software parameters presented here, please consult your service provider for the values needed. 2.1 System Requirement Personal computer (PC) Pentium III 266 MHz processor or higher 128 MB RAM minimum 20 MB of free disk space minimum RJ45 Ethernet Port...

  • Page 11: Configuring The Network Properties

    telephone equipment is connected to a POTS splitter. 2.3 Configuring the Network Properties Configuring PC in Windows XP 1. Go to Start / Control Panel (in Classic View). In the Control Panel, double-click on Network Connections 2. Double-click Local Area Connection. 3.

  • Page 12: Configuring Pc In Windows 2000

    4. Select Internet Protocol (TCP/IP) and click Properties. 5. Select the Obtain an IP address automatically and the Obtain DNS server address automatically radio buttons. 6. Click OK to finish the configuration. Configuring PC in Windows 2000 Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and Dial-up Connections.
  • Page 13 Double-click Local Area Connection. In the Local Area Connection Status window click Properties. Select Internet Protocol (TCP/IP) and click Properties. Select the Obtain an IP address automatically and the Obtain DNS server address automatically radio buttons. Click OK to finish the configuration.

  • Page 14: Configuring Pc In Windows 98/Me

    Configuring PC in Windows 98/Me 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Configuration tab. 2. Select TCP/IP -> NE2000 Compatible, or the name of your Network Interface Card (NIC) in your 3.
  • Page 15 Configuring PC in Windows NT4.0 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Protocols tab. 2. Select TCP/IP Protocol and click Properties. 3. Select the Obtain an IP address from a DHCP server radio button and click OK.

  • Page 16: Configuration

    3 Configuration 3.1 Determine your connection settings Before you configure the router, you need to know the connection information supplied by your ADSL service provider. 3.2 Connecting the ADSL Router to your network Unlike a simple hub or switch, the setup of the ADSL Router consists of more than simply plugging everything together.

  • Page 17: Quick Setup Guide

    3.3.1 Quick Setup Guide You can use "Quick Setup" to setup the router as follows, and the router will connect to the Internet via ADSL line. Click "Quick Start" to get into the quick setup procedures.
  • Page 18 Click "RUN WIZARD" to start up this procedure. Step 1 - Click "Next" to setup your new administrator' s password.
  • Page 19 Step 2 - Click "Next" to setup your time zone. Step 3 - Click "Next" to setup your Internet connection type. You can have this information from your Internet Service Provider. Enter the connection information provided by your ISP.

  • Page 20: Maintenance

    3.4 Maintenance 3.4.1 System Time Go to Maintenance->Time Zone and select system time as you wish. The system time is the time used by the device for scheduling services. You can manually set the time or connect to a NTP (Network Time Protocol) server. If an NTP...
  • Page 21 server is set, you will only need to set the time zone. If you manually set the time, you may also set Daylight Saving dates and the system time will automatically adjust on those dates. Current Date/Time: This field displays an updated Date and Time when you reenter this menu.

  • Page 22: Admin Setting

    3.4.2 Admin Setting Go to Maintenance-> Administration to set a new user' s name and password to restrict management access to the router. The default is admin (User's name) and admin (Password) New Password: Type the new password in this field. Confirm Password: Type the new password again in this field.

  • Page 23: Sysrestart

    Current Firmware Version: This filed displays the current firmware version. New Firmware Location: Type in the location of the file you want to upload in this field or click Browse… to find it. UPGRADE: Click UPGRADE to begin the upload process. 3.4.4 SysRestart Go to Maintenance->SysRestart to do system restart.

  • Page 24: Status

    3.5 Status 3.5.1 Device Info Go to Status->Device Info to check system information. The Device Info screen is a tool that you use to monitor your ADSL Router. It shows the Firmware Version, WAN, LAN, and MAC address information. Note that these fields are read-only and are not meant for diagnostic purposes.

  • Page 25: System Log

    [WAN] Virtual Circuit: Click the drop-down list and select the name of the Virtual Circuit on which the system status is to be shown. Status: Connected or Not Connected Connection Type: The WAN Connection Type. IP Address: The WAN port IP address Subnet Address: The WAN port IP subnet mask.

  • Page 26: Statistics

    3.5.3 Statistics Go to Status-> Statistics and select ADSL or Ethernet interface. The ADSL Router keeps statistic of traffic that passes through it. You are able to view the amount of packets that passes through the Router on both the WAN port & the LAN port.

  • Page 27: Wan Configuration

    [ADSL] The ADSL screen gives you information about how much data your router has transmitted or received across the ADSL connection. Click on REFRESH to update the screen. 3.6 WAN Configuration 3.6.1 VC Configuration Go to Interface Setup -> Internet. To add or delete ADSL VC configuration, these information provide by ISP.

  • Page 28: Wan Configuration

    MBS: Maximum Burst Size (MBS) is the maximum number of cells that can be sent at the PCR. After MBS is reached, cell rates fall below SCR until cell rate averages to the SCR again. At this time, more cells (up to the MBS) can be sent at the PCR again. CBR is for connections that support constant rates of data transfer.
  • Page 29 (1) Dynamic IP Address Select this option if your ISP provides you an IP address automatically. Please enter the Dynamic IP information accordingly. The following table describes the labels in this screen. LABEL Encapsulation Select your encapsulation type from the dropdown list. Select whether NAT is Enabled or Disabled.
  • Page 30 The following table describes the labels in this screen. LABEL Encapsulation Select your encapsulation type from the dropdown list. Static IP Address Enter the static IP Address here. IP Subnet Mask Enter the IP Subnet Mask here. Gateway Enter the Gateway address here. Select whether NAT is Enabled or Disabled.
  • Page 31 LABEL Username Enter your username for your PPPoE/PPPoA connection. Password Enter your password for your PPPoE/PPPoA connection. Encapsulation Select your encapsulation type from the dropdown list. Bridge Interface Select whether the Interface will be Activated or Deactivated. Connection Select whether your connection is always on or if it connects on demand.
  • Page 32 Connection Setting: For PPPoE/PPPoA connection, you can select Always on or Connect on-demand. Connect on demand is dependent on the traffic. If there is no traffic (or Idle) for a pre-specified period of time, the connection will tear down automatically. And once there is traffic send or receive, the connection will be automatically on.

  • Page 33: Lan Configuration

    (4) Bridge Mode The modem can be configured to act as a bridging device between your LAN and your ISP. Bridges are devices that enable 2 or more networks to communicate as if they are 2 segments of the same physical LAN. Please set the Connection type. The following table describes the labels in this screen.

  • Page 34: Router Local Ip

    3.7.1.1 Router Local IP IP Address: Enter the IP address of your ADSL router in dotted decimal notation, for example, 192.168.1.1 (default setting). IP Subnet Mask: Your ADSL router will automatically calculate the subnet mask based on the IP address that you assign. Unless you are implementing sub netting, use the subnet mask computed by the ADSL router.

  • Page 35: Dhcp Relay

    LABEL Starting IP Address Enter the starting IP address you wish to use as the DHCP server' s IP assignment. IP Pool Count Enter the maximum user pool size you wish to allow. Lease Time Enter the amount of time you wish to lease out a given IP address.

  • Page 36: Dns Relay

    3.7.1.4 DNS Relay The DNS Configuration allows the user to set the configuration of DNS. DNS Rely Selection: If user wants to disable this feature, he just needs to set both Primary & Secondary DNS to 0.0.0.0. Using DNS relay, users can setup DNS server IP to 192.168.1.1 on their computer.

  • Page 37: Wireless Security

    3.8.1.1 Wireless Security (Wired Equivalent Privacy) encrypts data frames before transmitting over the wireless network. Select Disable to allow all wireless computers to communicate with the access points without any data encryption. Select 64-bit WEP or 128-bit WEP to use data encryption. Key#1~Key#4 The WEP keys are used to encrypt data.

  • Page 38: Advanced Setting

    3.8.1.2 Advanced Setting Beacon Interval: The Beacon Interval value indicates the frequency interval of the beacon. Enter a value between 20 and 1000. A beacon is a packet broadcast by the Router to synchronize the wireless network. RTS Threshold: The RTS (Request To Send) threshold (number of bytes) for enabling RTS/CTS handshake.

  • Page 39: Mac Address

    DTIM: This value is between 1 and 255, indicates the interval of the Delivery Traffic Indication Message (DTIM). 3.8.1.3 MAC Address Filter You can allow or deny a lust of MAC addresses associated with the wireless stations access to the ADSL Router. Status: Use the drop down list box to enable or disable MAC address filtering.

  • Page 40: Ip Filtering

    ACL: There has Activated & Deactivated option. The default setting is Deactivated which means all IP can access via router. If you choose Activated, you only can access via router by listed IP addresses. ACL Rule Index: Index number from 1 and up to 16. Active: Once you choose Yes then you can access the IP via router.
  • Page 41 IP Filter Set Index: The IP Filter Set Index from 1 to 12 and each index can set up to 6 IP Filter. Interface: Choices from PVC0 to PVC7 and LAN. Direction: Choices are Both, Incoming and Outgoing. Select which direction of data Note that Incoming and Outgoing are from the flow you wish to apply the filters to.

  • Page 42: Snmp

    3.9.3 SNMP Go to Access Management -> SNMP to set SNMP. The Simple Network Management Protocol (SNMP) is used for exchanging information between network devices. It enables a host computer to access configuration, performance, and other system data that resides in a database on the modem.

  • Page 43: Upnp

    Get Community: Select to set the password for incoming Get- and GetNext request from management station. Set Community: Select to set the password for incoming Set request from management station. The default password is ‘public’. When you are done making changes, click on SAVE to save your changes.

  • Page 44: Ddns

    UPnP (Universal Plug and Play): You can choose “Activated” or “Deactivated” option from this session. Auto-Configured (by UPnP Application): UPnP network devices can automatically configure network addressing, announce their presence in the network to other UPnP devices and enable exchange of simple product and service descriptions. Choose “Activated”...

  • Page 45: Advanced Setup

    Dynamic DNS: Choose the option for Activated or Deactivated DDNS. Service Provider: The default Dynamic DNS service provider is My Host Name: Type the domain name assigned to your ADSL by your Dynamic DNS provider. E-mail Address: Type your e-mail address. Username: Type your user name.
  • Page 46 Virtual Circuit (VC): The Virtual Circuit (VC) properties of the ATM VC interface identify a unique path that your ADSL/Ethernet router uses to communicate via the ATM-based network with the telephone company central office equipment. NAT Status: This filed shows the current status of the NAT function for the current Number of IPs: This field is to specify how many IPs are provided by your ISP for current VC.
  • Page 47 from probing your network. For more information on IP address translation, refer to RFC 1631, The IP Network Address Translator (NAT). Inside/outside indicates where a host is located relative to the ROUTER. The computers hosts of your LAN are inside, while the Web servers on the Internet are outside.
  • Page 48 NAT Application The following figure illustrates a possible NAT application, where three inside LANs (logical LANs using IP Alias) behind the router can communicate with three distinct WAN networks. More examples follow at the end of this chapter. NAT Mapping Types NAT supports five types of IP/port mapping.

  • Page 49: Virtual Server

    c. Many-to-Many Overload: In Many-to-Many Overload mode, the TC3162 EVM maps multiple local IP addresses to shared global IP addresses. d. Many-to-Many No Overload: In Many-to-Many No Overload mode, the TC3162 EVM maps each local IP address to a unique global IP address. e.

  • Page 50: Dmz

    number. For example, set the FTP Virtual server, you can set the start and end port number to 21. Local IP Address: Enter the IP Address for the Virtual Server in LAN side. Virtual Server Listing: This is a listing of all virtual servers your have set. When you are done making changes, click on SAVE to save your changes, DELETE to delete the rule with the parameters you set, BACK to return to the previous screen or CANCEL to exit without saving.

  • Page 51: Ip Address Mapping

    When you are done making changes, click on SAVE to save your changes or on BACK to return to the previous screen. 3.10.1.3 IP Address Mapping Go to Advanced Setup ->NAT -> Multiple ->IP Address mapping to set IP Address mapping parameters. The IP Address Mapping is for those VCs that with multiple IPs.

  • Page 52: Adsl Type Setting

    Many-to Many No-Overload. Local Start & End IP: Enter the local IP address you plan to map to. Local Start IP is the starting local IP address & Local End IP is the ending local IP address. If the rule is for all local IPs, then the Start IP is 0.0.0.0 and the End IP is 255.255.255.255. Public Start &...

  • Page 53: Routing

    3.10.3 Routing 3.10.3.1 Static Routing Go to Advance Setup-> Routing to see the Routing Table Routing Table List This table lists IP address of Internet destinations commonly accessed by your network. When a computer requests to send data to a listed destination, the device uses the Gateway IP to identify the first Internet router it should contact to route the data most efficiently.

  • Page 54: Dynamic Routing

    IP Subnet Mask: Enter the subnet mask for this destination. Gateway IP Address: Enter the IP address of the gateway. A gateway does the actual forwarding of the packets. Enter the gateway’s IP address in the field or select which PVC you wish to act as a gateway.

  • Page 55: Firewall

    RIP-1 is universally supported, but RIP-2 carries more information. RIP-1 is adequate for most networks. Only consider RIP-2 if your network has unusual topology. Both RIP-2B and RIP-2M sends the routing data in RIP-2 format. RIP-2B uses subnet broadcasting while RIP-2M uses multicasting. Direction: Select the RIP direction from None, Both, In Only and Out Only.

  • Page 56: Appendix A: Glossary

    Firewall: Select this option can automatically detect and block Denial of Service (DoS) attacks, such as Ping of Death, SYN Flood, Port Scan and Land Attack. SPI: Select this option to Enabled or Disabled the SPI feature. (NOTE: If you enable SPI, all traffics initiate from WAN would be blocked, including DMZ, Virtual Server, and ACL WAN side) Appendix A: Glossary Address mask...
  • Page 57 American Wire Gauge - The measurement of thickness of a wire Bridge A device connects two or more physical networks and forward packets between them. Bridges can usually be made to filter packets, that is, to forward only certain traffic. Related devices are repeaters which simply forward electrical signals from one cable to the other and full-fledged routers which make routing decisions based on several criteria.
  • Page 58 Dynamic IP Addresses A dynamic IP address is an IP address that is automatically assigned to a client station (computer, printer, etc.) in a TCP/IP network. Dynamic IP addresses are typically assigned by a DHCP server, which can be a computer on the network or another piece of hardware, such as the Router.
  • Page 59 ICMP Internet Control Message Protocol - The protocol handle errors and control messages at the IP layer. ICMP is actually part of the IP protocol. Internet address An IP address is assigned in blocks of numbers to user organizations accessing the Internet.
  • Page 60 Password Authentication Protocol PORT The abstraction used in Internet transport protocols to distinguish among multiple simultaneous connections to a single destination host. POTS Plain Old Telephone Service - This is the term describe basic telephone service. Point-to-Point-Protocol - The successor to SLIP, PPP provides router-to-router and host-to-network connections over both synchronous and asynchronous circuits.
  • Page 61 Information stored within a router that contains network path and status information. It is used to select the most appropriate route to forward information along. Routing Information Protocol Routers periodically exchange information with one another so that they can determine minimum distance paths between sources and destinations. SNMP Simple Network Management Protocol - The network management protocol of choice for TCP/IP-based Internet.
  • Page 62 during your Router' s configuration. Subnet For routing purposes, IP networks can be divided into logical subnets by using a subnet mask. Values below those of the mask are valid addresses on the subnet. Transmission Control Protocol - The major transport protocol in the Internet suite of protocols provides reliable, connection-oriented full-duplex streams.
  • Page 63 reality, the data is delivered across a network via the most appropriate route. The sending and receiving devices do not have to be aware of the options and the route is chosen only when a message is sent. There is no pre-arrangement, so each virtual connection exists only for the duration of that one transmission.
