Planet 802.11g Wireless ADSL 2/2+ Router ADW-4401A/Bv2 User Manual page 29

(1) Dynamic IP Address
Select this option if your ISP provides you an IP address automatically. Please enter the
Dynamic IP information accordingly.
The following table describes the labels in this screen.
LABEL
Encapsulation
NAT
Default Route
TCP MTU Option
Dynamic Route
Multicast
(2) Static IP Address
Select this option to set static IP information. You will need to enter in the
encapsulation type (1483 Bridged IP LLC, 1483 Bridged IP VC-Mux, 1483 Routed IP
LLC (IPoA), 1483 Routed IP VC-Mux), IP address, subnet mask, and gateway address
provided to you by your ISP. Each IP address entered in the fields must be in the
appropriate IP form, which is 4 IP octets separated by a dot (x.x.x.x). The Router will
not accept the IP address if it is not in this format.
Select your encapsulation type from the dropdown list.
Select whether NAT is Enabled or Disabled.
Select whether this PVC will be the default route for
Internet data.
Enter TCP MTU Value here
Select the RIP type and direction from the dropdown lists.
Select the multicast protocol you wish to use from the
dropdown list.
29
DESCRIPTION
