Planet WDRT-1202AC Quick Installation Manual

Quick Installation Guide
WDRT-1202AC
1200Mbps 802.11ac Dual Band
Wireless Gigabit Router

1. Package Contents

Thank you for choosing PLANET WDRT-1202AC. Before installing the
router, please verify the contents inside the package box.
WDRT-1202AC Quick Guide
If there is any item missing or damaged, please contact the
seller immediately.
Note

3. Hardware Installation

Step 1: Locate the WDRT-1202AC in an optimum place, and adjust the
antenna for the best coverage.
Step 2: Connect the Power Adapter provided in the package to the
WDRT-1202AC. The Power LED on the front panel will turn on
accordingly.
Power
Power
Adapter
Ethernet Cable Power Adapter
– 1 –
– 3 –

2. Physical Introduction

Front Panel of WDRT-1202AC
USB
5GHz
2.4GHz
Rear Panel of WDRT-1202AC
ON/OFF
Power
Reset (press 10 seconds)
USB
Step 3: Follow the figure below to connect the network devices. It
depends on your network environment to connect the WAN
port to a Cable/xDSL modem, or the Ethernet directly in your
place.
Power
Power
Adapter
Power
Internet
WPS
(press >5 seconds)
WLAN ON/OFF
(press 1~5 seconds)
LAN1~4 WAN
– 2 –
WAN Port
LAN Ports
RJ45
RJ11
RJ45
Cable/xDSL Modem
PC
– 4 –
Phone
Jack
