Intel
Server System H2000WP
®
Family
Technical Product Specification
Intel order number: G52418-006
Revision 1.6
May, 2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H2000WP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Intel H2000WP

Summary of Contents for Intel H2000WP

  • Page 1 Intel Server System H2000WP ® Family Technical Product Specification Intel order number: G52418-006 Revision 1.6 May, 2014...

  • Page 2: Revision History

    ® Revision History Intel Server System H2000WP Family TPS Revision History Date Revision Number Modifications January, 2012 Initial release.  Updated Table 66 PCI Express* Slot Pinout on Riser Card.  Updated System Level Environmental Limits. April, 2012  Updated node cooling fan redundancy features.
  • Page 3 INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT. A "Mission Critical Application" is any application in which failure of the Intel Product could result, directly or indirectly, in personal injury or death. SHOULD YOU PURCHASE OR USE INTEL'S PRODUCTS FOR ANY SUCH MISSION...

  • Page 4: Table Of Contents

    ® Table of Contents Intel Server System H2000WP Family TPS Table of Contents 1. Introduction ........................1 Chapter Outline ...................... 1 Server Board Use Disclaimer ................. 2 2. Product Overview ....................... 3 System Views......................5 System Dimensions....................5 System Level Environmental Limits ................ 6 2.3.1...
  • Page 5 ® Intel Server System H2000WP Family TPS Table of Contents 3.2.10 ElectroStatic Discharge Susceptibility ..............24 3.2.11 Fast Transient/Burst ..................... 24 3.2.12 Radiated Immunity ....................24 3.2.13 Surge Immunity ....................24 3.2.14 AC Line Transient Specification ................25 3.2.15 Power recovery ....................25 3.2.16...
  • Page 6 ® Table of Contents Intel Server System H2000WP Family TPS 4. Cooling Sub-System......................36 Processor Heatsink ....................36 Node cooling Fans ....................37 Power Supply Fan ....................39 Air Duct Module ....................39 Drive Bay Population Requirement ............... 39 5. System Boards in the Node Tray ..................41 Node Docking Board ....................
  • Page 7 ® Intel Server System H2000WP Family TPS Table of Contents Reset BIOS Settings (J1D5) ................. 73 9. PCI Express* Riser Card and Assembly ................. 75 PCI Express* Riser for Slot 1 ................75 9.1.1 Overview of PCI-Express Riser ................75 9.1.2...
  • Page 8 ® List of Figures Intel Server System H2000WP Family TPS List of Figures Figure 1. System Overview (Air Duct is removed) ............... 5 Figure 2. Compute Node Scheme (Rear View) ................5 Figure 3. Fan Speed Control Structure ..................12 ®...
  • Page 9 ® Intel Server System H2000WP Family TPS List of Figures Figure 40. Hard Drive Carrier LED .................... 61 Figure 41. Front Control Panel ....................65 Figure 42. Jumper Locations and Functions ................69 Figure 43. PCI Express* Riser for Riser Slot 1 ................75 Figure 44.
  • Page 10 ® List of Tables Intel Server System H2000WP Family TPS List of Tables Table 1. System Feature Set ....................... 3 Table 2. System SKU matrix ....................... 4 Table 3. Chassis Dimension (SKU: H2312WPJR) ............... 5 Table 4. Chassis Dimension (SKU: H2216WPJR) ............... 6 Table 5.
  • Page 11 ® Intel Server System H2000WP Family TPS List of Tables Table 40. Node Fan Connector ....................42 Table 41. Main Power Output Connector .................. 43 Table 42. Card Edge Connector Pinout ..................44 Table 43. AHCI SATA0 DOM Connector Pinout ................ 45 Table 44.
  • Page 12 ® List of Tables Intel Server System H2000WP Family TPS Table 81. POST Error Beep Codes ................... 99 Intel order number: G52418-006 Revision 1.6...
  • Page 13 ® Intel Server System H2000WP Family TPS List of Tables <This page is intentionally left blank.> xiii Revision 1.6 Intel order number: G52418-006...

  • Page 15: Introduction

    ® The Intel Server System H2000WP may contain design defects or errors known as errata ® which may cause the product to deviate from published specifications. Refer to the Intel Server ® Board S2600WP/Intel Server System H2000WP Specification Update for published errata.

  • Page 16: Server Board Use Disclaimer

    ® components. It is the responsibility of the system integrator who chooses not to use Intel developed server building blocks to consult vendor datasheets and operating parameters to determine the amount of airflow required for their specific application and environmental conditions.

  • Page 17: Product Overview

    ® The Intel Server System H2000WP family includes two major SKUs: H2312WP and H2216WP, which are rack mount 2U 4-node server systems, purpose-built for high-density and lowest total cost of ownership in dense computing applications, such as HPC and IPDC. The system is ®...

  • Page 18: Table 2. System Sku Matrix

    H2216WPFKR ® ® ® The Intel Server System H2000WP family supports all Intel Xeon processor E5-2600 and E5- 2600 v2 series with TDP 130W (8-core, 6-core), or 80W (4-core) and below. You can find a full ® list of supported processors at the Intel support website: http://www.intel.com/p/en_US/support/highlights/server/sb-s2600wp.

  • Page 19: System Views

    ® Intel Server System H2000WP Family TPS Product Overview System Views Compute Node 3 Tray (upper left) Common Redundant Power Supply Compute Node 1 Tray (lower left) HDD bays with Hot Swap Backplane Compute Node 4 Tray (upper right) Upper and Lower Power Distribution Boards...

  • Page 20: System Level Environmental Limits

    ® Product Overview Intel Server System H2000WP Family TPS Table 4. Chassis Dimension (SKU: H2216WPJR) Height 87.9mm 3.46" Width 438mm 17.24" Depth 733mm 28.86" Weight Lbs. Chassis – basic configured (2 PSU, 0 drives) 63.93 Chassis – fully configured (2 PSU, 16 drives) 70.55...

  • Page 21: High Temperature Ambience (Hta) Support

    Mount BA - 2.5" HDD SKU: 6.5BA at idle and 7.07BA at active mode. Note: Intel Corporation server boards contain a number of high-density VLSI and power delivery components that ® need adequate airflow to cool. Intel ensures through its own chassis development and testing that when ®...
  • Page 22 Intel Server Board S2600WP product family Power Budget and Thermal Configuration Guidelines Tool, available as a download tool online at Intel.com.  The CPU-1 processor + CPU heatsink must be installed first. The CPU-2 heatsink must be installed at all times, with or without a processor installed.

  • Page 23: Table 6. Ambient Temperature Versus System Configuration

    ® Intel Server System H2000WP Family TPS Product Overview Table 6. Ambient Temperature Versus System Configuration Notes: 25°C is limited to elevations of 900m or less Quad Port IO Modules cannot be installed simultaneously with PCI Cards. Processor - 130W-4C and 135W-8C may have some performance impact.

  • Page 24: Set Throttling Mode

    ® Product Overview Intel Server System H2000WP Family TPS ® ® ● ● Intel Xeon processor E5-2690, 135w, 8C <-- see ® ® ● ● ● ● ● ● ● Intel Xeon processor E5-2637, 80w, 2C note 4 ® ®...

  • Page 25: Altitude

    ® Intel Server System H2000WP Family TPS Product Overview 2.3.3 Altitude This option is used to select the proper altitude that the system will be used in. Available settings include: [300m or less], [301m-900m], [901m-1500m], [Above 1500m]. Selecting an altitude range that is lower than the actual altitude the system will be operating at, can cause the fan control system to operate less efficiently, leading to higher system thermals and lower system performance.

  • Page 26: Hard Drive And Peripheral Bays

    ® Product Overview Intel Server System H2000WP Family TPS  4, 6 Chipset Temperature Sensor  4, 6 On-board Ethernet Controller Temperature Sensors  ® 4, 6 Add-In Intel SAS/IO Module Temperature Sensors  4, 9 Power Supply Thermal Sensor 4, 7 ...

  • Page 27: Server Board Overview

    ® Intel Server System H2000WP Family TPS Product Overview ® Figure 4. Intel Server System H2312WP Drive Bay Overview ® Figure 5. Intel Server System H2216WP Drive Bay Overview Server Board Overview The chassis is mechanically and functionally designed to support half-width server board, ®...

  • Page 28: Figure 6. Intel

    ® Product Overview Intel Server System H2000WP Family TPS Description Description Description Description 2x7 fan control PCH C600-A Dual port 1GbE SATA port 1 connector NIC chip CPU2 DIMM slots (8 Riser Slot 2 (PCIe NIC port 2 Storage Upgrade key...

  • Page 29: Figure 9. Light-Guided Diagnostic Led Locations

    ® Intel Server System H2000WP Family TPS Product Overview ® Note: The Intel Server System H2312WP and H2216WP requires the use of shielded LAN cable to comply with Emission/Immunity regulatory requirements. Use of non-shield cables may result in product non-compliance.

  • Page 30: Front Bezel Support

    Front Bezel Support ® Intel Server System H2000WP family provides front panel bezel. The bezel provides protection to system HDD bays with a lock to chassis. The front view of the bezel is shown as below. Figure 10. System Bezel Front View Rack and Cabinet Mounting Options The chassis was designed to support 19 inches wide by up to 30 inches deep server cabinets.

  • Page 31: Power Sub-System

    The PMBus* features included in this specification are requirements for AC ® silver rated box power supply for use in server systems based on Intel Server System H2000WP Family. This specification is based on the PMBus* Specifications part I and II, revision 1.1. 3.1.1 AC Power Supply Unit Dimension Overview The casing dimension is W 73.5mm x L 265.0mm x H 39/40mm.

  • Page 32: Ac Input Connector

    ® Power Sub-System Intel Server System H2000WP Family TPS Table 8. Specification Data for AC Power Supply Unit Wattage 1200W/1600W (Energy Smart) Voltage 90 – 264 VAC, auto-ranging, 47 Hz-63 Hz Heat Dissipation 2560 BTU/hr Maximum Inrush Current Under typical line conditions and over the entire system ambient operating...

  • Page 33: Handle Retention

    ® Intel Server System H2000WP Family TPS Power Sub-System PSU Output Connector A18 +12V +12V A19 PMBus* SDA A0* (SMBus* address) A20 PMBus* SCL A1* (SMBus* address) A21 PSON 12V STBY A22 SMBAlert# Cold Redundancy Bus* A23 Return Sense 12V load share bus...

  • Page 34: Power Cage Output Pin Assignment

    ® Power Sub-System Intel Server System H2000WP Family TPS The power system overview is shown below: Power Distribution Board 1 Power Distribution Board 2 Power Supply Unit #2 (upper) and #1 (lower) Figure 12. Power Cage Overview 3.1.9 Power Cage Output Pin Assignment The power cage provides +12V and +12V output to the system.

  • Page 35: Figure 13. Power Distribution Board

    ® Intel Server System H2000WP Family TPS Power Sub-System Main Power Output Connector P1 Power Supply Unit Connector Control Signal Connector Main Power Output Connector P2 Figure 13. Power distribution board Table 12. Pin assignment of power output connector Description...

  • Page 36: Ac Input Specification

    ® Power Sub-System Intel Server System H2000WP Family TPS Description Description PSON# 12V Load Share Bus SMBAlert# Cold Redundancy Bus Return Sense PWOK +12V Remote Sense Compatibility Bus Reserved +12VSB +12VSB Key Pin (removed) AC Input Specification 3.2.1 Input Voltage and Frequency The power supply must operate within all specified limits over the following input voltage range.

  • Page 37: Ac Line Fuse

    ® Intel Server System H2000WP Family TPS Power Sub-System Table 16. Platinum Efficiency Requirement Loading 100% of maximum 50% of maximum 20% of maximum 10% of maximum Minimum Efficiency 3.2.4 AC Line Fuse The power supply should have one line fused in the single line fuse on the line (Hot) wire of the AC input.

  • Page 38: Hot Plug

    ® Power Sub-System Intel Server System H2000WP Family TPS  The surge-withstand test must not produce damage to the power supply. The supply must meet surge-withstand test conditions under maximum and minimum DC-output load conditions. 3.2.8 Hot Plug Power supply must be designed to allow connection into and removal from the system without removing power to the system.

  • Page 39: Ac Line Transient Specification

    ® Intel Server System H2000WP Family TPS Power Sub-System 3.2.14 AC Line Transient Specification AC line transient conditions should be defined as “sag” and “surge” conditions. “Sag” conditions are also commonly referred to as “brownout”; these conditions will be defined as the AC line voltage dropping below nominal voltage conditions.

  • Page 40: Dc Output Specification

    ® Power Sub-System Intel Server System H2000WP Family TPS Cable Type Wire Size 16 AWG Temperature Rating 105ºC Amperage Rating 13 A Voltage Rating 125 V Figure 14. AC Power Cord Specification DC Output Specification 3.3.1 Output Power/Currents The following table defines the minimum power and current ratings. The power supply must meet both static and dynamic voltage regulation requirements for all conditions.

  • Page 41: Dynamic Loading

    ® Intel Server System H2000WP Family TPS Power Sub-System Parameter Unit Tolerance +12V +11.40V +12.000V +12.60V Vrms ±5% +12V +11.40V +12.000V +12.60V Vrms ±5% The combined output continuous power of all outputs should not exceed 3200W (1600W from each power supply unit). Each output has a maximum and minimum current rating shown in below table.

  • Page 42: Closed Loop Stability

    ® Power Sub-System Intel Server System H2000WP Family TPS The power supply must be provided with a reliable protective earth ground. All secondary circuits should be connected to protective earth ground. Resistance of the ground returns to chassis must not exceed 1.0 mΩ. This path may be used to carry DC current.

  • Page 43: Forced Load Sharing

    ® Intel Server System H2000WP Family TPS Power Sub-System 3.3.14 Forced Load Sharing The +12V output will have active load sharing. The output will share within 10% at full load. The failure of a power supply should not affect the load sharing or output voltages of the other supplies still operating.

  • Page 44: Power Supply Cold Redundancy Support

    ® Power Sub-System Intel Server System H2000WP Family TPS AC Input vout_holdup Vout pwok_low AC_on_delay pwok_off sb_on_delay pwok_on sb_on_delay pwok_off pwok_on PWOK pson_pwok pwok_holdup 12Vsb sb_vout 5Vsb holdup pson_on_delay PSON AC turn on/off cycle PSON turn on/off cycle Figure 15. Turn On/Off Timing (Power Supply Signals)

  • Page 45: 1200W Crps Cold Redundancy

    ® Intel Server System H2000WP Family TPS Power Sub-System 3.4.1 1200W CRPS Cold Redundancy If the output power is less than 480W (40%), the Cold redundant function is enabled. You will see one PSU working normally. The second PSU will be in CR mode. The Power Supply LED will be blinking green.

  • Page 46: Pson# Input Signal

    ® Power Sub-System Intel Server System H2000WP Family TPS 3.5.1 PSON# Input Signal The PSON signal is required to remotely turn on/off the power supply. PSON is an active low signal that turns on the +12V power rail. When this signal is not pulled low by the system, or left open, the outputs (except the +12VSB) turn off.

  • Page 47: Protection Circuits

    ® Intel Server System H2000WP Family TPS Power Sub-System Table 32. SMBAlert# Signal Characteristics Open collector/drain output from power supply. Pull- Signal Type (Active Low) up to VSB located in system. Alert# = High Alert# = Low Power Alert to system Logic level low voltage, Isink=4 mA 0.4 V...

  • Page 48: Pmbus

    ® Power Sub-System Intel Server System H2000WP Family TPS the power supply temperature drops to within specified limits, the power supply should restore power automatically, while the 12VSB remains always on. The OTP circuit must have built in margin, such that the power supply will not oscillate on and off due to temperature recovering condition.

  • Page 49: Accuracy

    ® Intel Server System H2000WP Family TPS Power Sub-System 3.7.2 Accuracy The sensor commands must meet the following accuracy requirements. The accuracies must be met over the specified ambient temperature and the full range of rated input voltage. Table 36. PMBus* Accuracy...

  • Page 50: Cooling Sub-System

    TIM (thermal interface material). ShinEtsu* G-751 or ShinEtsu* 7783D or Honeywell* PCM45F TIM is recommended. ® The mechanical performance of the heatsink must satisfy mechanical requirement of Intel ® Xeon E5-2600 and E5-2600 v2 series processors.

  • Page 51: Node Cooling Fans

    ® Intel Server System H2000WP Family TPS Cooling Sub-System Figure 18. Processor Heatsink Overview ® Note: The passive heatsink is Intel standard thermal solution for 1U/2U rack chassis. Node cooling Fans The cooling subsystem for each node consists of three 40 x 40 x 56 dual rotor fan, and CPU air duct.

  • Page 52: Figure 19. Node Fan Set And Power/Control Connection

    ® Cooling Sub-System Intel Server System H2000WP Family TPS replace the failed fan as soon as possible. However, the system design still reserves limited thermal margin to fan failure. ® The Intel Server System H2216WP Family which supports up to 16 units of 2.5" storage drives does support optimal redundant cooling.

  • Page 53: Power Supply Fan

    ® Intel Server System H2000WP Family TPS Cooling Sub-System The fan connector pin-out definition is as follows: Table 37. 8-pin Connector Pin-Out for Node Dual Rotor Fans Signal Name Description Ground P12V Power Supply +12 V Tach1 Out FAN_TACH1 signal output...
  • Page 54 ® Cooling Sub-System Intel Server System H2000WP Family TPS IMPORTANT NOTE: If the drive bay is missing or not fully populated, the system will not meet the thermal cooling requirements of the processor, which will most likely result in degraded performance as a result of throttling or thermal shutdown of the system.

  • Page 55: System Boards In The Node Tray

    ® Intel Server System H2000WP Family TPS System Boards in the Node Tray System Boards in the Node Tray The Node tray includes mother board, node docking board, bridge board, and node fan set. Node Docking Board Node Fan Set...

  • Page 56: Pinout Definition On Node Docking Board

    ® System Boards in the Node Tray Intel Server System H2000WP Family TPS The Node Docking Board implements the below features:  Main 12V hot swap connectivity between compute node and chassis power.  Current sensing of 12V main power for use with node manager.

  • Page 57: Bridge Board

    Server Board S2600WP and S2600WPQ family on board SCU supports 3Gb SAS/SATA while the bridge board and ® the HSBP of Intel Server System H2000WP family support 6Gb SAS/SATA drives.)  Two x4 lane 6Gb SAS/SATA re-drivers.  Four chassis ID signals to determine the physical location of the compute node.

  • Page 58: Pinout Definition On Bridge Board

    ® System Boards in the Node Tray Intel Server System H2000WP Family TPS  5V_AUX power generated on HSBP and provided to the compute node.  3.3V power generated on HSBP and provided to bridge board to run SAS/SATA re- drivers.

  • Page 59: Table 43. Ahci Sata0 Dom Connector Pinout

    ® Intel Server System H2000WP Family TPS System Boards in the Node Tray Signal Description Signal Description SATA0_TXP SATA0_RXN NODE_PRESENT_N (GND) SATA0_RXP ALL_NODE_OFF spare USB2_P0P USB2_P0N IPMB-Data IPMB-Clk FP HDD_ACT_LED_N FP Activity LED_N SMBUS_R1 DATA FP Health LEDA_N SMBUS_R1 CLK...

  • Page 60: 6Gbs Sas Support Option 1

    5.3.1 Overview of Bridge Board The Bridge Board is a spare board across all baseboards going into the H2000WP serials server chassis, to upgrade the system for 6Gbs SAS support. The Bridge Board provides hot swap interconnect of all electrical signals to the backplane of the server chassis (except for main 12V power).

  • Page 61: Figure 25. Sas 6Gbs Bridge Board Overview

    ® Intel Server System H2000WP Family TPS System Boards in the Node Tray Figure 25. SAS 6Gbs Bridge Board Overview This bridge board passes all electrical connectivity through a 2x40pin card edge hot swap interconnect between compute node/SAS RAID card and chassis backplane. The bridge board passes the follow features (per compute node) to the backplane of the server: ...

  • Page 62: Pinout Definition On Sas 6Gbs Bridge Board

    ® System Boards in the Node Tray Intel Server System H2000WP Family TPS 2x40 pin card edge connector (to backplane) 2x40 pin card edge connector (to baseboard bridge slot) 4-port Mini SAS Connector Figure 26. Connectors and components on Spare Bridge Board 5.3.2...

  • Page 63: 6Gbs Sas Support Option 2

    SGPIO_LOAD 6Gbs SAS Support Option 2 ® The dedicated 6Gbs SAS controller RMS25LB040 is designed for the Intel Server System H2000JF, together with a dedicated bridge board and riser card as a total solution kit. This solution leaves the PCIe slot 1 available for an additional LP PCIe base add-in card.

  • Page 64: Figure 27. Overview Of The Bridge Board

    ® System Boards in the Node Tray Intel Server System H2000WP Family TPS Figure 27. Overview of the Bridge Board The main connectors on the bridge board are defined as follows. 2x40 pin card edge connector (to backplane) SATA DOM Connector...

  • Page 65: Riser Card

    ® Intel Server System H2000WP Family TPS System Boards in the Node Tray Signal Name Signal Name Signal Name Signal Name SAS3_TX_P SAS3_RX_N SAS0_TX_P SAS0_RX_N SAS0_TX_N SAS0_RX_P SAS2_RX_N SAS2_TX_P The pin definitions for the SATA DOM and Auxiliary Power connectors are the same as defined in Table 43 and Table 45.

  • Page 66: Table 51. Card Edge Pin-Out Of Riser Card To Pcie Slot2 Of Baseboard

    ® System Boards in the Node Tray Intel Server System H2000WP Family TPS Signal Name Signal Name Signal Name Signal Name RGMII_IBMC_RMM4_T RGMII_IBMC_RMM4_RX P3E_RX_DP< XD_1 3> RGMII_IBMC_RMM4_T RGMII_IBMC_RMM4_RX P3E_RX_DN< XD_2 3> RGMII_IBMC_RMM4_T RGMII_IBMC_RMM4_RX P3E_TX_C_D XD_3 P<3> RGMII_IBMC_RMM4_RX P3E_TX_C_D _CTRL N<3>...

  • Page 67: Sas Controller Module

    ® Intel Server System H2000WP Family TPS System Boards in the Node Tray Signal Name Signal Name Signal Name Signal Name RGMII_IBMC_RMM4_T RGMII_IBMC_RMM4_RX P3E_TX_C_D XD_3 P<3> RGMII_IBMC_RMM4_RX P3E_TX_C_D _CTRL N<3> RGMII_IBMC_RMM4_T P3E_RX_DP< X_CLK 2> RGMII_IBMC_RMM4_T RGMII_IBMC_RMM4_RX P3E_RX_DN< X_CTRL _CLK 2>...

  • Page 68: Figure 30. Sas Controller Module Overview

    ® System Boards in the Node Tray Intel Server System H2000WP Family TPS RJ45 connector for 1GbE RGMII LSI* 2308 SAS Controller Riser Slot (with riser card installed) Bridge Board Slot HDD LED ACT Header Mini SAS Connector 1 (Depop)

  • Page 69: Hard Disk Drive Support

    ® Intel Server System H2000WP Family TPS Hard Disk Drive Support Hard Disk Drive Support The server system provides two SKUs to support different types of Hard Disk Drives (HDD):  H2312WP: Supports 12x 3.5" HDD  H2216WP: Supports 16x 2.5" HDD Hard Disk Drive Bays scheme The server system H2000 chassis can support up to twelve carrier-mounted SATA/SAS 3.5-inch...

  • Page 70: Hard Drive Carrier

    The passive backplane acts as an intermediate pass-through interface board, where SATA/SAS ® ports of SCU0 from server board are hard wired to the backplane. The on board Intel C600 Chipset (PCH) provides the necessary drive interface.

  • Page 71: Backplane Feature Set

    ® Intel Server System H2000WP Family TPS Hard Disk Drive Support The following sections describe the feature and connections between the backplane and server board. 6.3.1 Backplane Feature set:  Common HSBP Microcontroller Cypress* PSoC 1 part  H2312WP Family: 12x SAS/SATA 3.5" HDDs at 6Gb/s SAS/SATA or slower speeds, divided into four groups of three hot swap hard drives.

  • Page 72: Backplane Block Diagram

    ® Hard Disk Drive Support Intel Server System H2000WP Family TPS 6.3.2 Backplane Block Diagram Figure 35. Passive Backplane Block Diagram (for one node) 6.3.3 3.5” Hot Swap Backplane Connector scheme The following diagrams show the layout of major components and connectors for 3.5" Hot Swap backplane.

  • Page 73: Hot Swap Backplane Connector Scheme

    ® Intel Server System H2000WP Family TPS Hard Disk Drive Support 20-pin Front Panel cable connector for Node 2, 4 2-blade Compute Node Power connector for Node 4 2x40 pin Bridge Board connector for Node 4 2x9 pin Power supply input connector...

  • Page 74: Figure 38. 2.5" Backplane Component And Connectors (Front View)

    ® Hard Disk Drive Support Intel Server System H2000WP Family TPS SATA/SAS connectors for Node 1 SATA/SAS connectors for Node 2 SATA/SAS connectors for Node 3 SATA/SAS connectors for Node 4 Figure 38. 2.5" Backplane Component and Connectors (Front View)

  • Page 75: Backplane Led Support

    ® Intel Server System H2000WP Family TPS Hard Disk Drive Support 6.3.5 Backplane LED Support The backplanes support both HDD online and activity/fault LEDs for each of the hard drive connectors. A light duct in HDD tray is used to conduct LED light to front panel. General HDD LED functionality is displayed below: Figure 40.

  • Page 76: Table 54. Backplane Input Power Connector Pin-Out

    ® Hard Disk Drive Support Intel Server System H2000WP Family TPS Table 54. Backplane Input Power Connector Pin-out Signal Description Signal Description P12V P12V P12V P12V P12V P12V P12V P12V P12V 2. 2-Blade Compute Node Power Connector The backplane provides main power to compute node through 2-blade power connector.

  • Page 77: Table 57. Front Panel Connector Pin-Out

    ® Intel Server System H2000WP Family TPS Hard Disk Drive Support Signal Description Signal Description SMBUS_R1 DATA FP Health LEDA_N SMBUS_R1 CLK FP Health LEDG_N FP PWR LED_N SMBUS_R5 DATA FP ID LED_N SMBUS_R5 CLK FP ID BTN_N FP RST BTN_N...

  • Page 78: Table 58. Power Supply Control Connector Pin-Out

    ® Hard Disk Drive Support Intel Server System H2000WP Family TPS Signal Description FP2_PWR_BTN_N FP2_RST_BTN_N FP2_ID_BTN_N P3V3SB FP2_PWR_LED_N FP2_HEALTH_LEDG_N FP2_HEALTH_LEDA_N FP2_ACTIVITY_LED_N FP2_ID_LED_N 5. 2x7 Pin Power Supply Control Signal Connector The backplanes provide power supply control signals, together with PMBus* functionality integrated.

  • Page 79: Front Panel Control And Indicators

    ® The Intel Server System H2000WP family Front Control Panel is integrated with rack handles at the both sides of the chassis. Each control panel contains two sets of node control buttons and status LEDs. The control panel assembly is pre-assembled and fixed with the rack handles.

  • Page 80: Control Panel Button

    ® Intel Server System H2000WP Family TPS Front Panel Control and Indicators Control Panel Button The following table lists the control panel features and functions. The control panels features a system power button. Table 59. Front Control Button Function Feature Function Toggles the system power on/off.

  • Page 81: Power/Sleep Led

    ® Front Panel Control and Indicators Intel Server System H2000WP Family TPS 7.2.1 Power/Sleep LED Table 61. Power LED Operation State Power Mode Description Power Off Non-ACPI System power is off and the BIOS has not initialized the chipset. Power On...

  • Page 82: System Status Led - Bmc Initialization

    ® Intel Server System H2000WP Family TPS Front Panel Control and Indicators Color State Criticality Description Minimum number of fans to cool the system are not present or have failed. Amber Solid on Critical, non- Fatal alarm – system has failed or shutdown.

  • Page 83: Configuration Jumpers

    The following table provides a summary and description of configuration, test, and debug ® ® jumpers on the Intel Server Board S2600WP, which is used in Intel Server System H2000WP Family as Compute Node. Figure 42. Jumper Locations and Functions Revision 1.6...

  • Page 84: Force Integrated Bmc Update (J6B1)

    ® Intel Server System H2000WP FamilyTPS Configuration Jumpers Table 63. Force Integrated BMC Update Jumper Jumper Name Jumper Position Mode of Operation Note J6B1: BMC Force Normal Normal mode Update jumper Update BMC in force update mode J1E2: ME Force Update...

  • Page 85: Force Me Update (J1E2)

    ® Configuration Jumpers Intel Server System H2000WP Family TPS position. You should only use this jumper setting when the standard firmware update process fails. This jumper should remain in the default/disabled position when the server is running normally. The server board has several 3-pin jumper blocks that can be used to configure, protect, or recover specific features of the server board.

  • Page 86: Bios Recovery Mode (J1E1)

    ® Intel Server System H2000WP FamilyTPS Configuration Jumpers Steps to perform the password clear: Power down server. Do not unplug the power cord. Open the chassis. For instructions, refer to your server chassis documentation. Move the jumper (J1F2) from the default operating position, covering pins 1 and 2, to the password clear position, covering pins 2 and 3.

  • Page 87: Reset Bios Settings (J1D5)

    ® Configuration Jumpers Intel Server System H2000WP Family TPS The user should then switch the recovery jumper back to normal operation and restart the system by performing a power cycle. The following steps demonstrate this recovery process: 1. Power OFF the system.
  • Page 88 ® Intel Server System H2000WP FamilyTPS Configuration Jumpers Note: Removing AC Power before performing the BIOS settings Clear operation causes the system to automatically power up and immediately power down, after the procedure is followed and AC power is re-applied. If this happens, remove the AC power cord again, wait 30 seconds, and re-install the AC power cord.

  • Page 89: Pci Express* Riser Card And Assembly

    Server System H2000WP Family TPS PCI Express* Riser Card and Assembly ® Each compute node in Intel Server System H2000WP Family includes four PCI Express* riser slots that accept dedicated PCI Express* x16 Gen3 Risers to support low profile add-in card and ® Intel IO module.
  • Page 90 ® Intel Server System H2000WP FamilyTPS PCI Express* Riser Card and Assembly Pin Name Description Pin Name Description 3.3VAUX For wake on LAN GPU_NODE_ON can turn of 2U GPU power GPU_PWRGD Tach9 Tach11 Tach8 Tach10 Tach7 Tach6 Spare Spare Spare...

  • Page 91: Table 70. Pci Express* Slot Pinout On Riser Card

    ® PCI Express* Riser Card and Assembly Intel Server System H2000WP Family TPS Pin Name Description Pin Name Description PERxP7 Rx Lane 7+ PERxN7 Rx Lane 7- PETxP8 Tx Lane 8+ PETxN8 Tx Lane 8- PERxP8 Rx Lane 8+ PERxN8...
  • Page 92 ® Intel Server System H2000WP FamilyTPS PCI Express* Riser Card and Assembly Pin-Side B PCI Spec Signal Pin-Side A PCI Spec Signal HSON15 HSOP15 HSIN14 HSIP14 HSON14 HSOP14 HSIN13 HSIP13 HSON13 HSOP13 HSIN12 HSIP12 HSON12 HSOP12 HSIN11 HSIP11 HSON11 HSOP11...

  • Page 93: Pci Express* Riser With Iom Carrier For Slot 2 (Optional)

    ® PCI Express* Riser Card and Assembly Intel Server System H2000WP Family TPS Pin-Side B PCI Spec Signal Pin-Side A PCI Spec Signal HSOP4 RSVD RSVD PRSNT2# RSVD HSIN3 HSIP3 HSON3 HSOP3 HSIN2 HSIP2 HSON2 HSOP2 HSIN1 HSIP1 HSON1 HSOP1...

  • Page 94: Figure 44. Pci Express* Riser With Bracket For Riser Slot 2

    Graphic/GPGPU add-in card. ® Note: Riser Slot 2 on baseboard only supports Intel 1U/2U Risers. It will cause damage to any PCI-E based add-in card, which is directly plugged into the Riser Slot 2.

  • Page 95: Pinout Definition On Slot 2 Riser And Iom Carrier

    ® PCI Express* Riser Card and Assembly Intel Server System H2000WP Family TPS Color Condition Functionality Green LAN link and no access Dedicated NIC Green Blink LAN access Activity Idle 9.2.2 Pinout definition on Slot 2 Riser and IOM Carrier Below is a list of pin definition for Slot 2 Riser and IOM Carrier.
  • Page 96 ® Intel Server System H2000WP FamilyTPS PCI Express* Riser Card and Assembly Side Even Signal Side Odd Signal R04+ T04+ R04- T04- R05+ T05+ R05- T05- R06+ T06+ R06- T06- R07+ T07+ R07- T07- IB_R00+ IB_T00+ IB_R00- IB_T00- IB_R01+ IB_T01+...

  • Page 97: Table 73. Pci Express* Slot Pinout On Riser Card

    ® PCI Express* Riser Card and Assembly Intel Server System H2000WP Family TPS Side Even Signal Side Odd Signal T11+ R11- T11- R12+ T12+ R12- T12- R13+ T13+ R13- T13- R14+ T14+ R14- T14- R15+ T15+ R15- T15- Riser ID Riser ID Table 73.
  • Page 98 ® Intel Server System H2000WP FamilyTPS PCI Express* Riser Card and Assembly Pin Name Description Pin Name Description PERxN1 Rx Lane 1- PETxP2 Tx Lane 2+ PETxN2 Tx Lane 2- PERxP2 Rx Lane 2+ PERxN2 Rx Lane 2- PETxP3 Tx Lane 3+...

  • Page 99: Table 74. Io Module Slot On Carrier

    ® PCI Express* Riser Card and Assembly Intel Server System H2000WP Family TPS Pin Name Description Pin Name Description PERxP12 Rx Lane 12+ PERxN12 Rx Lane 12- PETxP13 Tx Lane 13+ PETxN13 Tx Lane 13- PERxP13 Rx Lane 13+ PERxN13...
  • Page 100 ® Intel Server System H2000WP FamilyTPS PCI Express* Riser Card and Assembly Signal Signal PCIe Gen3 Tp [5] PCIe Gen3 Rn [5] PCIe Gen3 Rp [5] PCIe Gen3 Tn [4] PCIe Gen3 Tp [4] PCIe Gen3 Rn [4] PCIe Gen3 Rp [4]...

  • Page 101: Appendix A: Integration And Usage Tips

    Management from accurately monitoring system health and may affect system ® performance. The FRUSDR utility for this server system can either be run from the Intel ® Deployment CDROM that came with your system, or can be downloaded from the Intel website referenced at the bottom of this page.

  • Page 102: Appendix B: Post Code Led Decoder

    ® Intel Server System H2000WP Family TPS Appendix B: POST Code LED Decoder Appendix B: POST Code LED Decoder During the system boot process, the BIOS executes a number of platform configuration processes, each of which is assigned a specific hex POST code number. As each configuration routine is started, the BIOS displays the POST code to the POST Code Diagnostic LEDs on the back edge of the server board.

  • Page 103: Table 76. Post Progress Code Led Example

    Appendix B: POST Code LED Decoder Intel Server System H2000WP Family TPS Each POST code is represented by the eight amber diagnostic LEDs. The POST codes are divided into two nibbles, an upper nibble and a lower nibble. The upper nibble bits are represented by diagnostic LEDs #4, #5, #6, and #7.

  • Page 104: Table 78. Mrc Progress Codes

    ® Intel Server System H2000WP Family TPS Appendix B: POST Code LED Decoder Table 78. MRC Progress Codes Progress Code Main Sequence Subsequences/Subfunctions 0xB0 Detect DIMM population —n/a— 0xB1 Set DDR3 frequency —n/a— 0xB2 Gather remaining SPD data —n/a— —n/a—...
  • Page 105 ® Appendix B: POST Code LED Decoder Intel Server System H2000WP Family TPS Progress Code Description 0x07 Early SB initialization during Sec Phase 0x08 Early NB initialization during Sec Phase 0x09 End Of Sec Phase 0x0E Microcode Not Found 0x0F...
  • Page 106 ® Intel Server System H2000WP Family TPS Appendix B: POST Code LED Decoder Progress Code Description 0x79 DXE CSM Init 0x90 DXE BDS Started 0x91 DXE BDS connect drivers 0x92 DXE PCI Bus begin 0x93 DXE PCI Bus HPC Init...
  • Page 107 ® Appendix B: POST Code LED Decoder Intel Server System H2000WP Family TPS Progress Code Description 0xB2 DXE Legacy Option ROM init 0xB3 DXE Reset system 0xB4 DXE USB Hot plug 0xB5 DXE PCI BUS Hot plug 0xB6 DXE NVRAM cleanup...

  • Page 108: Appendix C: Video Post Code Errors

    Processor core/thread count mismatch detected Fatal 0192 Processor cache size mismatch detected Fatal 0194 Processor family mismatch detected Fatal 0195 Processor Intel(R) QPI link frequencies unable to synchronize Fatal 0196 Processor model mismatch detected Fatal 0197 Processor frequencies unable to synchronize Fatal 5220...
  • Page 109 ® Appendix C: Video POST Code Errors Intel Server System H2000WP Family TPS Error Code Error Message Response 8161 Processor 02 unable to apply microcode update Major 8162 Processor 03 unable to apply microcode update Major 8163 Processor 04 unable to apply microcode update...
  • Page 110 ® Intel Server System H2000WP Family TPS Appendix C: Video POST Code Errors Error Code Error Message Response 8536 DIMM_H2 failed test/initialization Major 8537 DIMM_H3 failed test/initialization Major 8538 DIMM_J1 failed test/initialization Major 8539 DIMM_J2 failed test/initialization Major 853A DIMM_J3 failed test/initialization...
  • Page 111 ® Appendix C: Video POST Code Errors Intel Server System H2000WP Family TPS Error Code Error Message Response 8561 DIMM_A2 encountered a Serial Presence Detection (SPD) failure Major 8562 DIMM_A3 encountered a Serial Presence Detection (SPD) failure Major 8563 DIMM_B1 encountered a Serial Presence Detection (SPD) failure...
  • Page 112 ® Intel Server System H2000WP Family TPS Appendix C: Video POST Code Errors Error Code Error Message Response 85CD DIMM_T1 failed test/initialization Major 85CE DIMM_T2 failed test/initialization Major 85CF DIMM_T3 failed test/initialization Major 85D0 DIMM_L3 disabled Major 85D1 DIMM_M1 disabled...

  • Page 113: Post Error Beep Codes

    ® Appendix C: Video POST Code Errors Intel Server System H2000WP Family TPS Error Code Error Message Response A100 BIOS ACM Error Major A421 PCI component encountered a SERR error Fatal A5A0 PCI Express component encountered a PERR error Minor...

  • Page 114: Glossary

    ® Intel Server System H2000WP Family TPS Glossary Glossary Term Definition ACPI Advanced Configuration and Power Interface Application Processor APIC Advanced Programmable Interrupt Control ASIC Application Specific Integrated Circuit ASMI Advanced Server Management Interface BIOS Basic Input/Output System BIST Built-In Self Test...
  • Page 115 ® Glossary Intel Server System H2000WP Family TPS Term Definition IPMB Intelligent Platform Management Bus IPMI Intelligent Platform Management Interface Infrared In-Target Probe 1024 bytes Keyboard Controller Style Local Area Network Liquid Crystal Display Light Emitting Diode Low Pin Count...
  • Page 116 ® Intel Server System H2000WP Family TPS Glossary Term Definition Server Management Interrupt (SMI is the highest priority non-maskable interrupt.) Server Management Mode Server Management Software SNMP Simple Network Management Protocol Server System Infrastructure To Be Determined Thermal Interface Material...

  • Page 117: Reference Documents

    ® Intel Server System Integrated Baseboard Management Controller Core External Product Specification, 2007. Intel Corporation.  ® Intel Thurley Server Platform Services IPMI Commands Specification, 2007. Intel Corporation.  ® ® Intel Server Safety and Regulatory, 2011. Intel Corporation. (Intel...

Table of Contents
