Security Mode
Encryption Type for
Open/Shared
Encryption Type for
WPA/PSK and
WPA2/PSK
Security Key
Use the same SSID
and Security Key as
Above
channel is under serious interference.
There are several modes provided for you to choose. Each mode
will bring up different parameters (e.g., WEP keys, Pass Phrase)
for you to configure.
This option is available when Open/Shared is selected as
Security Mode.
Choose None to disable the WEP Encryption. Data sent to the
AP will not be encrypted. To enable WEP encryption for data
transmission, please choose WEP.
WEP Keys - Four keys can be entered here, but only one key
can be selected at a time. The format of WEP Key is restricted to
5 ASCII characters or 10 hexadecimal values in 64-bit
encryption level, or restricted to 13 ASCII characters or 26
hexadecimal values in 128-bit encryption level. The allowed
content is the ASCII characters from 33(!) to 126(~) except '#'
and ','.
This option is available when WPA/PSK or WPA2/PSK is
selected as Security Mode.
Select TKIP or AES as the algorithm for WPA.
Type 8~63 ASCII characters, such as 012345678..(or 64
Hexadecimal digits leading by 0x, such as "0x321253abcde...").
Such feature is available for WPA/PSK or WPA2/PSK mode.
In general, under the network environment, same SSID and
security key can be used for the host (wireless client) and the
repeater (VigorAP 902) in Universal Repeater mode. Check it to
use the same SSID and security key configured as above.
SSID - SSID can be any text numbers or various special
characters. For VigorAP 902 is set as "Repeater", the purpose of
the device is to extend the Wi-Fi service. Therefore, the
characters set here will be regarded as "main SSID". Other
wireless client can receive the wireless signal from VigorAP902
by using the SSID configured here.
