After finishing this web page configuration, please click Next to continue.
S e t t i n g s f o r A P B r
S e t t i n g s f o r A P B
After finished the configuration for wireless LAN (2.4GHz) and click Next, you will need to
configure the following page if you choose AP Bridge-WDS as the operation mode for
wireless LAN (5GHz).
Available settings are explained as follows:
Item
AP Discovery
Phy Mode
Security
Peer MAC Address
value you want.

Download Limit –Scroll the radio button to choose
the value you want.
Enable Station Control – Check the box to set the duration for
the guest connecting /reconnecting to Vigor device.

Connection Time –Scroll the radio button to choose
the value you want.

Reconnection Time –Scroll the radio button to
choose the value you want.
i d g e - W D S
r i d g e - W D S
Description
Click this button to open the AP Discovery dialog. VigorAP 902
can scan all regulatory channels and find working APs in the
neighborhood.
Data will be transmitted via HTMIX mode.
Each access point should be setup to the same Phy Mode for
connecting with each other.
Select WEP, TKIP or AES as the encryption algorithm. Type the
key number if required.
Type the peer MAC address for the access point that VigorAP
902 connects to.
25
VigorAP 902 User's Guide
