Rate
Extension Channel
Enable 2 Subnet
(Simulate 2 APs)
Hide SSID
SSID
Subnet
Isolate LAN
Isolate Member
VLAN ID
MAC Clone
After finishing this web page configuration, please click OK to save the settings.
switch channel if the selected channel is under serious
interference. If you have no idea of choosing the frequency,
please select AutoSelect to let system determine for you.
If you choose 11g Only or 11b Only, such feature will be
available for you to set data transmission rate.
With 802.11n, there is one option to double the bandwidth per
channel. The available extension channel options will be varied
according to the Channel selected above. Configure the
extension channel you want.
Check the box to enable the function for two independent
subnets. Once you enable this function, LAN-A and LAN-B
would be independent. Next, you can connect one router in
LAN-A, and another router in LAN-B. Such mechanism can
make you feeling that you have two independent AP/subnet
functions in one VigorAP 902.
If you disable this function, LAN-A and LAN-B ports are in
the same domain. You could only connect one router (no
matter connecting to LAN-A or LAN-B) in this environment.
Check it to prevent from wireless sniffing and make it harder
for unauthorized clients or STAs to join your wireless LAN.
Depending on the wireless utility, the user may only see the
information except SSID or just cannot see any thing about
VigorAP 902 while site surveying. The system allows you to
set four sets of SSID for different usage.
Set a name for VigorAP 902 to be identified. Default settings
are DrayTek-LAN-A and DrayTek-LAN-B. When Enable 2
Subnet is enabled, you can specify subnet interface (LAN-A
or LAN-B) for each SSID by using the drop down menu.
Choose LAN-A or LAN-B for each SSID. If you choose
LAN-A, the wireless clients connecting to this SSID could
only communicate with LAN-A.
Check this box to make the wireless clients (stations) with the
same SSID not accessing for wired PC in LAN.
Check this box to make the wireless clients (stations) with the
same SSID not accessing for each other.
Type the value for such SSID. Packets transferred from such
SSID to LAN will be tagged with the number.
If your network uses VLANs, you can assign the SSID to a
VLAN on your network. Client devices that associate using the
SSID are grouped into this VLAN. The VLAN ID range is
from 3 to 4095. The VLAN ID is 0 by default, it means
disabling the VLAN function for the SSID.
Check this box and manually enter the MAC address of the
device with SSD 1. The MAC address of other SSIDs will
change based on this MAC address.
