Encryption Type for
WPA/PSK and
WPA2/PSK
Security Key
Use the same SSID
and Security Key as
above
Enable Guest
Wireless
VigorAP 902 User's Guide
transmission, please choose WEP.
WEP Keys - Four keys can be entered here, but only one key
can be selected at a time. The format of WEP Key is restricted to
5 ASCII characters or 10 hexadecimal values in 64-bit
encryption level, or restricted to 13 ASCII characters or 26
hexadecimal values in 128-bit encryption level. The allowed
content is the ASCII characters from 33(!) to 126(~) except '#'
and ','.
This option is available when WPA/PSK or WPA2/PSK is
selected as Security Mode.
Select TKIP or AES as the algorithm for WPA.
Type 8~63 ASCII characters, such as 012345678..(or 64
Hexadecimal digits leading by 0x, such as "0x321253abcde...").
Such feature is available for WPA/PSK or WPA2/PSK mode.
In general, under the network environment, same SSID and
security key can be used for the host (wireless client) and the
repeater (VigorAP 902) in Universal Repeater mode. Check it to
use the same SSID and security key configured as above.
SSID - SSID can be any text numbers or various special
characters. For VigorAP 902 is set as "Repeater", the purpose of
the device is to extend the Wi-Fi service. Therefore, the
characters set here will be regarded as "main SSID". Other
wireless client can receive the wireless signal from VigorAP 902
by using the SSID configured here.
Security - Set 8~63 ASCII characters or 64 Hexadecimal digits
which can be used for logging into VigorAP 902 by other
wireless client.
Check the box to enable the guest wireless setting.
SSID – Set a name for VigorAP 902. Wireless guest is allowed
to access into Internet via VigorAP 902 with the SSID
configured here.
Security Key – Set 8~63 ASCII characters or 64 Hexadecimal
digits which can be used for logging into VigorAP 902 by
wireless guest.
Enable Bandwidth Limit – Check the box to define the
maximum speed of the data uploading/downloading which will
be used for the guest connecting to Vigor device with the same
