Application Set-up Examples

6 Application Set-up Examples
The examples in this section are intended as a quick
reference for common applications.
•
Parameter settings are the regional default values
unless otherwise indicated (selected in
parameter 0-03 Regional Settings).
•
Parameters associated with the terminals and
their settings are shown next to the drawings.
•
Required switch settings for analog terminals A53
or A54 are also shown.
NOTICE
When using the optional STO feature, a jumper wire may
be required between terminal 12 (or 13) and terminal 37
for the frequency converter to operate with factory
default programming values.
6.1 Application Examples
6.1.1 AMA
FC
+24 V 12
+24 V 13
D IN 18
D IN 19
COM 20
D IN 27
D IN 29
D IN 32
D IN 33
D IN
37
+10 V 50
A IN
53
A IN
54
COM
55
A OUT
42
COM
39
Table 6.1 AMA with T27 Connected
MG33AQ02
Operating Instructions
Parameters
Function Setting
Parameter 1-29 A [1] Enable
utomatic Motor complete
Adaptation AMA
(AMA)
Parameter 5-12 T [2] Coast
erminal 27 inverse
Digital Input
Notes/comments:
Set parameter group 1-2* Motor
Data according to the motor.
D IN 37 is an option.
Danfoss A/S © 07/2015 All rights reserved.
FC
+24 V 12
+24 V 13
D IN 18
D IN 19
COM 20
D IN 27
D IN 29
32
D IN
D IN 33
D IN
37
+10 V 50
A IN
53
A IN
54
COM
55
A OUT
42
COM
39
Table 6.2 AMA without T27 Connected
6.1.2 Speed
FC
+24 V 12
+24 V 13
D IN 18
D IN 19
COM 20
D IN 27
D IN 29
D IN 32
D IN 33
D IN
37
+10 V 50
+
A IN
53
A IN
54
COM
55
-
A OUT
42
-10 - +10V
COM
39
U - I
A53
Table 6.3 Analog Speed Reference (Voltage)
Parameters
Function Setting
Parameter 1-29 A [1] Enable
utomatic Motor complete
Adaptation AMA
(AMA)
Parameter 5-12 T [0] No
erminal 27 operation
Digital Input
Notes/comments:
Set parameter group 1-2* Motor
Data according to the motor.
D IN 37 is an option.
Parameters
Function Setting
Parameter 6-10 T 0.07 V*
erminal 53 Low
Voltage
Parameter 6-11 T 10 V*
erminal 53 High
Voltage
Parameter 6-14 T 0 Hz
erminal 53 Low
Ref./Feedb. Value
Parameter 6-15 T 50 Hz
erminal 53 High
Ref./Feedb. Value
* = Default value
Notes/comments:
D IN 37 is an option.
