Danfoss VLT AutomationDrive FC 301 Operating Instructions Manual page 17

Electrical Installation
1
9
10
L1
L2
L3
PE
1 PLC
2 Frequency converter
3 Output contactor
4 Cable clamp
5 Cable insulation (stripped)
6 Cable gland
Illustration 4.2 EMC-compliant Electrical Connection
For more information about EMC, see chapter 4.2 EMC-compliant Installation
MG33AQ02
Operating Instructions
2
11
8
6
7 Motor, 3-phase and PE (screened)
8 Mains, 3-phase and reinforced PE (not screened)
9 Control wiring (screened)
10
Potential equalisation minimum 16 mm
Clearance between control cable, motor cable and mains cable:
11
Minimum 200 mm (7.9 in)
Danfoss A/S © 07/2015 All rights reserved.
3
4
5
u
v
w
PE
7
2 (0.025 in 2 )
15
4 4
