Appendix

9 Appendix
9.1 Symbols, Abbreviations, and Conventions
°C
AC
AEO
AWG
AMA
DC
EMC
ETR
f
M,N
FC
I
INV
I
LIM
I
M,N
I
VLT,MAX
I
VLT,N
IP
LCP
MCT
n
s
P
M,N
PELV
PCB
PM Motor
PWM
RPM
Regen
T
LIM
U
M,N
Table 9.1 Symbols and Abbreviations
Conventions
Numbered lists indicate procedures.
Bullet lists indicate other information.
Italicised text indicates:
•
Cross reference.
•
Link.
•
Parameter name.
•
Parameter group name.
•
Parameter option.
•
Footnote.
All dimensions are in [mm] (in).
9.2 Parameter Menu Structure
MG33AQ02
Operating Instructions
Degrees celsius
Alternating current
Automatic energy optimisation
American wire gauge
Automatic motor adaptation
Direct current
Electro magnetic compatibility
Electronic thermal relay
Nominal motor frequency
Frequency converter
Rated inverter output current
Current limit
Nominal motor current
Maximum output current
Rated output current supplied by the frequency converter
Ingress protection
Local control panel
Motion control tool
Synchronous motor speed
Nominal motor power
Protective extra low voltage
Printed circuit board
Permanent magnet motor
Pulse width modulation
Revolutions per minute
Regenerative terminals
Torque limit
Nominal motor voltage
