Operating Instruction

The PM200 supports all Thorlabs 'C-Series' photodiode, thermal and
pyroelectric sensors. These can easily identified against older versions of
Thorlabs power or energy sensors by their red connector housing. The console
will not recognize sensors from the 'A' and 'B' series. Please contact Thorlabs
for upgrading of old sensors with 'C-Series' connectors.
To plug or remove a sensor slightly press the two bolts in the connector housing.
Sensors can be 'hot-swapped' to the console, after recognizing a new valid
sensor the type and download of the calibration data, the console is ready to
operate with the new sensor.
The PM200 also supports custom detectors, please refer to chapter Photodiode
Sensors , Thermal Sensors
27
pin-out .
63
From the main menu all functions can be reached by clicking to the appropriate
icon:
Console Info (Type and serial number)
Opens external USB memory (File manager
Battery status
Measurement Views
Zooms In the actual display
Delta
23
© 2012 Thorlabs
or Pyroelectric Sensors
30
26
15
measurement mode
and to the connector
32
)
22
2 Installation
