PM100USB
3 Operating Instruction
·
Install software from the supplied data carrier (see section Software Installa-
tion).
·
Connect a suitable sensor.
·
Connect the PM100USB to the PC using the supplied USB cable.
·
For detailed instructions, please see section Graphic User Interface.
3.1 Operating Elements
1
Connector for power / energy sensor
2
USB connector to PC
3
LED: Sensor detected and ready for operation
4
LED: USB device ready for operation
6
© 2017 Thorlabs
