Optical power and energy
Hide thumbs Also See for PM200:
Table of Contents

Advertisement

Connector
Units
Measurement Ranges
Display Resolution
AD Converter
Accuracy
Trigger Threshold
Max. Repetition Rate
Wavelength Correction
Beam Area Setting
Analog Output
Connector
Signal
Voltage Range
Accuracy
Bandwidth
Auxiliary In-/Output
Connector
Function
Sensor Temperature Control
Supported Temperature Sensor
Temperature Measurement Range
Sound
Type
Function
Memory
Type
Size
Interfaces
Type
Connector (Host)
Connector (Device)

Power Management

Battery
Charger / DC Input
Power Connector
© 2012 Thorlabs
DB9F, Left Side
J, J/cm², W, W/cm², V
4 Decades; 200 mV - 2V - 20 V - 100 V
Ranges Selectable in J, Sensor Dependent
100 µV / Responsivity Value (V/J)
16 bit
± 0.5% f.s.
0.1% - 99.9% f.s.
3 kHz
Sensor Dependent [nm, V/J]
Diameter 1/e² or Rectangular x,y
Audio 3.5 mm, Left Side
Amplified Input Signal - Not Corrected
0 to 2 V
±3%
up to 100 kHz, Dependent on Sensor and Settings
2 x 6 Pins, 0.1" Socket, Top Side
External Trigger Input
4 x GPIO
2 x 10 bit ADC
Thermistor
-10 °C to +80 °C
Speaker 300 Hz - 5 kHz
Laser Tuning Support, Console Function Support
Nand Flash
128 MB
USB2.0
Mini USB, Top Side
USB Type A, Left Side
LiPo 3.7 V 2600 mAh
5 V / 2 A
Center Hole
6 Appendix
