THORLABS PM200 Operation Manual page 43

Left Sub Display
Right Sub Display
Bargraph indicator
Statistics screen
Data logging screen
Histogram Power /
Energy histogram
Chart display
Range button
Wavelength /
Response button
Measurement configuration button
© 2012 Thorlabs
'T' indicator and green light.
The display has the following configurable items:
- no display
- maximum value - sampling until reset
- ratio max/min value - sampling until reset
- power or energy density
- alternate unit depending on connected sensor
Available choices depend on the connected sensor
The display has the following configurable items, the
possible choices depend on the connected sensor:
- no display
- minimum value - sampling until reset
- frequency or repetition rate
- temperature
- resistance of temperature sensor
The bargraph indicator shows the incidence or the used
measurement range.
Statistical values in linear and logarithmic representation
Shows the logging history data
- displays histogram data
Power/Energy Chart
Press to open a dialog box for setting the measurement
range.
The indicator in the button shows the currently used
measurement range in the chosen unit. A green light
indicates 'auto-ranging'
Shortcut: [Shift + F1]
Press this button to open a dialog box for setting the
correction wavelength, or in adapter mode to enter the
responsivity value in A/W or V/W. The currently used
parameter is indicated in the button label.
Shortcut: [Shift + F2]
Depending on the connected sensor the following
parameters can be set in the dialog box:
4 Computer Interface
41
