Shelf Installation; Mounting Hardware - Altronix NetWay4ES Installation Manual

Fig. 9

Shelf Installation

1- Position and affix rubber pads (included) at each
corner on the bottom of the unit (Fig. 10).
2- Place unit in desired location.
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056
website: www.altronix.com, e-mail: info@altronix.com. Lifetime Warranty, Made in U.S.A.
IINetWay4ES
- 12 -
NetWay4ES Chassis Mechanical Drawing & Dimensions
1.7" x 5.23" x 8.42" (43.18mm x 132.84mm x 213.87mm)
8.42"
(213.87mm)
A
B

Mounting Hardware

Four (4) rubber pads C
(H x W x D approx.)
Fig. 10
(Included):
L20P
:
1.7"
(43.18mm)
Left side
C
Rubber Feet
NetWay4ES/NetWay4ESK
